Overview - ADJ Startec RAYZER User Instructions

Rayzer
US Version
5
1. Display: Used to show the various menus and the selected functions.
2．Buttons:
MENU
UP
DOWN
ENTER
3. DMX IN/OUT: DMX512 Connections. Use 3-Pin XLR cables to link the units together, or
4. POWER IN/FUSE (2Amp) : The Power In socket is used to connect to a power source.
5. Microphone:
6. Key for Laser : This key is used to turn the Laser diode On/O . (EU verion only)
ADJ Products, LLC - www.adj.com - Rayzer User Manual Page 11
1 2
4
3
To select the programming functions
To go forward in the selected functions
To go backwardin the selected functions
To con rm the selected functions
to connect a unit to a DMX controller.
The fuse protects the unit from any damage from over current.
Receives music output while in Sound Active mode.
Europe Version
6
5

Overview

1 2
4 3
