Specifications - Yamaha Jupiter Fi T115FS-5 Owner's Manual

Specifications

Dimensions:
Overall length:
1935 mm (76.2 in)
Overall width:
680 mm (26.8 in)
Overall height:
1065 mm (41.9 in)
Seat height:
765 mm (30.1 in)
Wheelbase:
1240 mm (48.8 in)
Ground clearance:
125 mm (4.92 in)
Minimum turning radius:
1860 mm (73.2 in)
Weight:
Curb weight:
104 kg (229 lb)
Engine:
Engine type:
Air cooled 4-stroke, SOHC
Cylinder arrangement:
Single cylinder
9 Displacement:
114 cm3
Bore × stroke:
50.0 × 57.9 mm (1.97 × 2.28 in)
Compression ratio:
9.3 : 1
Starting system:
Electric starter and kickstarter
Lubrication system:
Wet sump
Engine oil:
Recommended brand:
YAMALUBE
Type:
SAE 10W-40
Recommended engine oil grade:
API service SG type or higher, JASO
standard MA
Engine oil quantity:
Without oil filter element replacement:
0.80 L (0.85 US qt, 0.70 Imp.qt)
With oil filter element replacement:
0.85 L (0.90 US qt, 0.75 Imp.qt)
Air filter:
Air filter element:
Oil-coated paper element
Fuel:
Recommended fuel:
Regular unleaded gasoline (Gasohol (E10)
acceptable)
Fuel tank capacity:
4.0 L (1.06 US gal, 0.88 Imp.gal)
Fuel injection:
Throttle body:
ID mark:
2SU1 00
Spark plug(s):
Manufacturer/model:
NGK/CR6HSA
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Transmission:
Primary reduction ratio:
2.900 (58/20)
9-1
Final drive:
Chain
Secondary reduction ratio:
3.154 (41/13)
Transmission type:
Constant mesh 4-speed
Operation:
Left foot operation
Gear ratio:
1st:
2.833 (34/12)
2nd:
1.875 (30/16)
3rd:
1.353 (23/17)
4th:
1.045 (23/22)
Chassis:
Frame type:
Backbone
Caster angle:
26.5 °
Trail:
76 mm (3.0 in)
Front tire:
Type:
With tube
Size:
70/90-17 38P
Manufacturer/model:
INOUE/NR53
Rear tire:
Type:
With tube
