V-ZUG 51028 Installation Instructions

Installation instructions
Noblesse KNi Refrigerator
Built-in SMS

Validity

These installation instructions apply to the model: 51028

General notes

The appliance should be installed by qualified personnel only. Each step must be carried out and checked in full in the order
specified.
If installing into combustible material, the guidelines and safety standards for low voltage installations and fire protection must
be strictly observed.

Electrical connections

Electrical connections must be carried out by suitably qualified personnel in accordance with the guidelines and safety
standards for low voltage installations and the specifications of the local electricity supply companies.
A plug-in appliance may only be connected to a socket outlet with earthing contact, installed according to specifications. A
mains isolating device with 3 mm contact opening should be provided in the house wiring system. Switches, plug and socket
devices, circuit breakers and fusible cut-outs which are accessible after installation and which have all-poles switching are
permissible as isolating devices. Effective earthing and separately installed neutral and earth conductors ensure safe and fault-
free operation.
After installation, live parts and cables with basic insulation must not be accessible.
Check old installations.
Information on the necessary mains voltage, type of current and fuse protection can be taken from the identification plate.
➤

Installation

The door opening can be changed from right to left up until the point when the appliance is installed in the niche.
Push the appliance into the niche. Secure to the cabinet with 1 screw (included in the scope of delivery) through each hinge. Then
➤
secure the appliance to the cabinet at the top with 2 chipboard screws each (included in the scope of delivery) through the fixing bar.
Operate the appliance in accordance with the operating instructions supplied.
➤
Ensure that the appliance is switched off if it is not intended that the appliance be used immediately after installation.
➤
1
J51028.113-0
7.9.12
