Summary of Contents for Biamp Vocia VFOM-1
- Page 1 VFOM-1 OPERATION MANUAL May 2019 585.0317.90B...
- Page 2 VFOM-1 Setup and Installation Installation and Use Install the unit away from heat sources, such as vents and radiators, and in rooms with adequate ventilation. Ensure that air can circulate freely behind, beside, and above the unit. Do not exceed the maximum ambient operating temperature of 18°-108°...
- Page 3 VFOM-1 Rear Rear Panel Connections The rear panel of the VFOM-1 has four 4–way connectors, each of which provides connections for two speaker circuits. The connector numbers correspond to the AM-600 amplifier channel of that number (refer to the amplifier channel numbers printed above the AM-600 amplifier modules on the VA-8600 rear panel).
