SES Installation & Operations Manual
d. Quartz Tube Removal and Cleaning
CAUTION: wear proper eye and skin protection for servicing
glass components.
i. Make sure the spa is shut down and the UV Lamp and
Quartz Tube have cooled before performing maintenance on
the Quartz Tube.
ii. Remove the Upper Enclosure Assembly and UV Lamp as
described in Section A and set aside in a safe place.
iii. Remove the plastic Compression Nut. If there is any water
remaining in the plumbing, it will start to leak after the
Compression Nut is removed.
iv. Grasp the inside of the Quartz Tube and pull it out of the
housing. Make sure the Sealing Rings and Compression
Washers do not get lost during Quartz Tube removal.
v. Inspect the Sealing Ring for nicks or hardness and the
Compression Washers for cracks, replace if necessary.
vi. Clean the Quartz Tube exterior with a mild solution of
muriatic acid and water in a ratio of four parts water to one
part acid (4:1). DO NOT USE ABRASIVE CLEANERS as
they can scratch the high quality quartz glass.
CAUTION: Follow the directions for safe use and handling of
muriatic acid on the acid bottle label.
vii. After cleaning the Quartz Tube, wash it off with water and
wipe dry with a soft towel. Inspect the Quartz Tube for cracks
and replace if cracks are found.
viii. Make sure the inside of the Quartz Tube is dry before
replacing the UV Lamp(s).
NOTE: Damage caused by broken quartz tubes is not covered under the
Spa Solar Eclipse Limited Warranty.
CAUTION: If broken glass is trapped in the spa system, do not
operate the spa. contact a service professional to have the glass
removed.
