ALLEN & HEATH M-ES-V1-BASE Instructions

Part number M-ES-V1-BASE-A
V1.5
Note For firmware
not supported in the iLive Surface RAB2
module Port B. The only option
supported in Surface Port B is the MMO
module (ADAT, iDR link).
RAB module
This is the original audio network
module fitted to the modular
iDR10 MixRack and standard
iLive Surfaces. Up to two
Auvitran AVD card options
could be fitted internally to
provide the ESA and ESB
EtherSound interface ports.
M-ETH-M ES card kit
iDR10 MixRack
A
B
iLive ES1 Base Instructions AP7759 issue 1
iLive ES1 Base kit for RAB2
Instructions
M-ES-V1-BASE is a carrier frame that lets you re-use the original
Auvitran AVD
Audio (RAB) module when upgrading to the more recent Remote
Audio 2 (RAB2) module.
The RAB2 module is available as an upgrade for existing users who
want to benefit from the wide range of audio interface options now
available for iLive.
option using the smaller
the original card can be fitted using this carrier kit so providing a
lower cost upgrade for users wishing to continue with EtherSound
as the Port A Surface to MixRack link or to re-use the card for audio
expansion in Port B (MixRack only).
The original M-ETH-M card and the more recent M-ES2 option are
this option is
compatible with each other and the EtherSound network standard.
Note
module. It is not compatible with the iDR-32 and iDR-48 Port B slot.
iLive-80, iLive-112, iLive-144, iLive-176 Surface
Port A = Surface to MixRack link
Port B = System expand, mic split, record
EtherSound card option from the earlier Remote
While the new M-ES-V2 EtherSound module
Auvitran AVDM
This carrier kit option is available only for use with the RAB2
RAB2 module
This is the more recent audio
network module fitted to the iDR10
MixRack and standard iLive
Surfaces. Provides slots to fit up to
two from a range of audio
networking and digital interface
option cards.
Option cards available:
M-ES-V1-BASE
M-ES-V2
M-ACE
M-MMO
M-MADI
A B
Surface Port B M-MMO option only
AP7759
card is available for RAB2,
Carrier for earlier AVD card
ES using newer AVDM card
Dual port ACE link
ADAT, Aviom, iDR ports
64 channel dual port MADI
iDR0 MixRack
A B
1
