PowerWalker VFI RT HID Series Quick Manual page 2

ENGLISH
Output frequency and
voltage
Output plug indicator
UPS status/user setting
display String
Warning indication
Settings
Battery volume
display
Load Power level display
IV. Rear Panels
VFI 1000-1500-2000 RT
VFI 3000 RT
1 AC Output
Indicates the value of output frequency and voltage
The UPS has two groups of outlets. The output plug
indicator will light on if there is output power
respectively.
Strings Indicate the UPS status( see Table 4)
Strings Indicate user setting options( see Table 5)
Lights on when the UPS is failure or alarm.
Lights on when the UPS under settings mode.
Indicates the amount of battery volume remaining.
level
Each battery volume level bar indicates approximately
20% of total battery volume
Indicates the load level of the UPS. Each level bar
indicates approximately 20% of the total UPS output
Power.
DRY IN
EPO
DRY OUT
AC INPUT
