Zephyr Modena Island ZMD-M90AS Use, Care And Installation Manual page 11

!
WARNING: Electrical wiring must be done by a qualified person(s) in
accordance with all applicable codes and standards. This range hood must be
properly grounded. Turn off electrical power at service entrance before wiring.
Ceiling Joists
Wood Blocking
Top Support Frame
Bottom Support Frame
Hood Body/Canopy
1. Ceiling Preparation:
1-
1/2
approx. 1/4" exposed.
2. Hood Preparation: Remove screws securing top and bottom support frames together. Adjust support frame to
1
3
2
4
FIG. A
PAPER TEMPLATE
A
9
Front of Hood
C L
Cut-Out Shaded Area
B
FIG. B
