Primex XR Levo Series Install Manual

Digital clocks, 72mhz synchronized time solution
Hide thumbs Also See for XR Levo Series:
Table of Contents

Advertisement

Quick Links

See also: Troubleshooting Manual
Primex XR 72MHz Synchronized Time Solution
XR Levo Series Digital Clocks/Timers
Install Guide
©2018 Primex. All Rights Reserved. The Primex logo is a registered trademark of Primex. All other trademarks are the property of their respective owners. 12/7/2018. Primex, Inc. |
965 Wells Street | Lake Geneva, WI 53147 | www.primexinc.com | Ph: 1-262-729-4853

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR Levo Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Primex XR Levo Series

Summary of Contents for Primex XR Levo Series

  • Page 1 Install Guide ©2018 Primex. All Rights Reserved. The Primex logo is a registered trademark of Primex. All other trademarks are the property of their respective owners. 12/7/2018. Primex, Inc. | 965 Wells Street | Lake Geneva, WI 53147 | www.primexinc.com | Ph: 1-262-729-4853...
  • Page 2 Primex, Inc. Primex, Inc. Primex is a leading provider of synchronized time and environmental monitoring solutions. Our solutions automate and maintain facility compliance, increase efficiencies, enhance safety and reduce risk for organizations in the healthcare, education, manufacturing and government vertical markets.
  • Page 3 Regulatory Compliance FCC/IC Product Compliance This device complies with part 15 of the FCC rules as well as with Industry Canada. Operation of this device is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference that may cause undesired operation.
  • Page 4 Important Safety Instructions READ ALL INSTRUCTIONS BEFORE INSTALLATION, OPERATION, OR MAINTENANCE OF PRODUCT. Important Safety Instructions READ ALL INSTRUCTIONS BEFORE INSTALLATION, OPERATION, OR MAINTENANCE OF PRODUCT. Some of the following information may not apply to your particular product model; however, as with any electronic product, precautions should be observed during installation, operation, and maintenance.
  • Page 5 About this Guide Purpose This guide is intended to provide the instructions and information required to install and operate Primex Levo Series Digital Clocks/Timers. Typographical Conventions This guide includes notes, cautions, and warnings content that highlights important messages. Typeface Indicates Note Indicates something important or useful.

  • Page 6: Table Of Contents

    Specifications Timer Switch Control Specifications Configure Display Settings Install Levo Series Digital Clock/Timer Installation Requirements 120 VAC Wiring & Power Specifications 24 VAC Wiring & Power Specifications Tilt-Bracket and Surface Mount Mounting Dimensions Surface Mount Installation Tilt Bracket Installation Remove Clock/Timer from Bracket Dual Mount Installation Dual Mount Dimension Specifications Remove Digital Clock/Timer from Dual Mount Bracket...
  • Page 7 Elapsed Timer Operation Programmable Timer Operation Support Five Year Limited Warranty...

  • Page 9: Specifications

    2.5" model: 2.5” (6.4 cm) diagonal (hours and minutes), 1.4" (3.6 cm) diagonal (seconds) 4" model: 4.6” (11.7 cm) diagonal (hours and minutes), 2.5” (6.4 cm) diagonal (seconds) LED Display Dimmer 100%, 75%, 50%, 25% XR Levo Series Digital Clocks/Timers Install Guide...

  • Page 10: Timer Switch Control Specifications

    Timer Switch Control Specifications The Primex 3 button Timer Switch Control provides the method manage events for both the Elapsed and Code Blue Timer. Elapsed Timer count down or count up events are triggered manually by a user from the timer switch control buttons. Code Blue Timer...
  • Page 11 If the count event is stopped/paused, pressing If the count event is stopped/paused, pressing and releasing the STOP/START button resumes and releasing the STOP/START button resumes the event. the event. XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 12 Pressing the Clock Mode Count Up Mode Count Down Mode button... RESET Ignored Pressing and releasing the RESET button once Pressing and releasing the RESET button once automatically stops and resets the count event automatically stops and resets the count event SET/CHANGE to its preset start time.
  • Page 13 Holding down DISPLAY for a minimum of four seconds shows the last code blue time. RESET Ignored Ignored SET/CHANGE STOP/START Halts the code blue event count at the moment the button is Ignored pressed. INCREMENT XR Levo Series Digital Clocks/Timers Install Guide...

  • Page 14: Configure Display Settings

    Configure Display Settings Levo Series Digital Clocks and Timers have a dip switch control panel that sets its display settings. How to access setting panel To change the factory default settings, from the back side of the clock remove the small rectangular access panel. Setting changes can be made while the clock/timer is ON and changes will take effect within a few seconds.
  • Page 15 To enable the PM dot indicator, set the OPTIONS - PM DP switch (6) to the ON position, as illustrated below. Set offset hours The Clock/Timer displays the time received from the Transmitter. The hour offset is for application use when the clock/timer is to display the time for another Time Zone. XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 16 Set Programmable Timer mode (programmable timer only) For Programmable Timer models, the timer schedule is configured in the Primex Event Scheduler Pro software to the schedule ID controller 24. The schedule is downloaded from the Event Scheduler Pro to the system Transmitter, allowing the Transmitter to broadcast the schedule.

  • Page 17: Install Levo Series Digital Clock/Timer

    Verify the clock's settings have been configured before the clock is installed. Any damage to the clock due to improper wiring voids the warranty. It is at Primex discretion as to whether damage to the clock was caused by improper wiring.

  • Page 18: 120 Vac Wiring & Power Specifications

    3.9 lbs. (1.8 kg) 240 mA 8.0" (20.3 cm) 17.9" (45.5 cm) 2.4" (6.1 cm) 4" (10.16 cm), 6-digit 4.6 lbs (2.1 kg) 260 mA 8.0" (20.3 cm) 2.3" (59.3 cm) 2.4" (6.1 cm) XR Levo Series Digital Clocks/Timers Install Guide...

  • Page 19: 24 Vac Wiring & Power Specifications

    24 VAC Wiring & Power Specifications Follow all National and Local Building Codes when installing clocks. 24 VAC Wiring Requirements All clocks should be connected to a single power source. If multiple power sources are needed to accommodate the load of the clocks, all of the power sources should have the same rating and be installed on separate branch circuits.

  • Page 20: Tilt-Bracket And Surface Mount Mounting Dimensions

    4.8” 13.6” 2.1" 6.0” 0.38” – 0.63” 8.0” 2.5” 10.6" 6.0" 2.1" 2.5" 2.5” 4-digit - 18° bracket 4.6" 2.2" 9.5" 13.6" 6.0" 2.1" 2.5" 2.5” 6-digit - 18° bracket 4.6" 2.1" 9.5" XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 21 Clock/Model 4” 4-digit wall mount 8.0” 17.9” 2.4” 14” 0.4 – 0.9” 12.0” 4.0” 4” 6-digit wall mount 8.0” 23.3” 2.4" 14” 0.4 – 0.9” 12.0” 4.0”...

  • Page 22: Surface Mount Installation

    3. Once the clock/timer receives a signal from the Transmitter, the LED segments display the time received from the Transmitter’s time source and a flashing red dot appears at the bottom right of the second hour digit for three minutes. XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 23 Surface Mount illustration...

  • Page 24: Tilt Bracket Installation

    3. Once the clock/timer receives a signal from the Transmitter, the LED segments display the time received from the Transmitter’s time source and a flashing red dot appears at the bottom right of the second hour digit for three minutes. XR Levo Series Digital Clocks/Timers Install Guide...

  • Page 26: Remove Clock/Timer From Bracket

    4” x 4 and 4” x 6: from the top of the bracket, insert a thin screwdriver into each notch and gently move the screwdriver sideways to unlock the clock. Then pull clock forward and up to unsnap. Lift out. Remove clock from bracket illustration XR Levo Series Digital Clocks/Timers Install Guide...

  • Page 27: Dual Mount Installation

    Dual Mount Installation A Dual Mount Digital Clock/Timer consists of two single-sided digital clocks and a bracket kit. The kit contains a flange (piece that mounts to ceiling or wall), a bracket (piece that bolts to flange and to which two clocks are mounted), and the hardware necessary to complete the installation.
  • Page 28 3. Once the clock/timer receives a signal from the Transmitter, the LED segments display the time received from the Transmitter’s time source and a flashing red dot appears at the bottom right of the second hour digit for three minutes. Dual Digital Bracket Kit flange dimension XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 29 Dual Digital Clock mounting illustration...

  • Page 30: Dual Mount Dimension Specifications

    Dual Mount Dimension Specifications Clock Type No. Digits Width from Wall (A) Height from Ceiling (B) Depth of Two Clocks (C) 6-digit Dual 2.5" (6.4 cm) 16.8" (42.7 cm) 8.0" (20.3 cm) 5.9" (15 cm) 4 digit Dual 2.5" (6.4 cm) 13.8"...

  • Page 31: Remove Digital Clock/Timer From Dual Mount Bracket

    4” x 4 and 4” x 6 - from the top of the bracket, insert a thin screwdriver into each notch and gently move the screwdriver sideways to unlock the clock. Then pull clock forward and up to unsnap. Lift out. XR Levo Series Digital Clocks/Timers Install Guide...

  • Page 32: Flush Mount Installation

    Flush Mount Installation Complete the steps below to install a Flush Mount Digital Clock/Timer to either a new or existing wall surface. Supplied materials (1) Flush Mount Junction Box. Material: ABS plastic, Color: black; UL listed (UL 50E 1st Ed; listing number E469550) (1) Bezel: material - ABS plastic, color - black (4) #10 Phillips Flat Head Screw (4) Drywall Anchors...
  • Page 33 Transmitter’s time source and a flashing red dot appears at the bottom right of the second hour digit for three minutes. New wall surface- flush mount assembly illustration Existing wall surface - flush mount assembly illustration XR Levo Series Digital Clocks/Timers Install Guide...

  • Page 35: Flush Mount Dimension Specifications

    Flush Mount Dimension Specifications Clock Type Weight Max. Current Draw Width from Wall (A) Height (B) Depth (C) 2.5" (6.4 cm), 6-Digit 2.0 lbs. (0.9 kg) 230 mA 16.8" (42.7 cm) 6.5" (16.5 cm) 3.4" (8.6 cm) Flush mount dimension illustration...

  • Page 36: Remote Antenna Installation

    (13.7 meter). The cable can be placed in any position, but the antenna must be mounted vertically and away from metal objects. Unless it is very close to the Transmitter, the powered clock will not set to the correct time without the remote antenna connected. XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 37 If the remote antenna is to be mounted above the clock and if the antenna cable is to be concealed behind the wall, use a single gang electrical box to be mounted horizontally behind the clock. For a straight vertical cable run, a minimum of 0.5 inch (1.27 cm) electrical conduit should be used, coupled with the top side of the electrical box.

  • Page 38: Timer Switch Control Installation

    The timer control switch membrane and wall plate may be cleaned with water or most common disinfectants. Be sure to test any cleaning solutions on a small area. Timer Switch Control wiring specifications XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 39 Timer Switch Control installation illustration...

  • Page 40: Code Blue Timer Operation

    Code Blue Timer Operation A Digital Code Blue Timer is a multifunction digital clock and timer that integrates with an existing code blue system to effectively time each event. When a code blue event is invoked a relay/pulse is sent from the code blue system to the timer, which triggers it to begin counting up.

  • Page 41: Timer Switch Control Specifications

    Timer Switch Control Specifications The Primex 3 button Timer Switch Control provides the method manage events for both the Elapsed and Code Blue Timer. Elapsed Timer count down or count up events are triggered manually by a user from the timer switch control buttons. Code Blue Timer events are triggered by the input of the wired connection to the code blue system and the timer switch control allows a user to pause a code blue event.
  • Page 42 Pressing the Clock Mode Count Up Mode Count Down Mode button... DISPLAY Pressing and releasing the DISPLAY button scrolls through the various modes in the following order: EXIT 1. Clock Mode 2. Count Up Mode 3. Count Down Mode STOP/START Ignored Controls the count up event while in count up Controls the count down event while in count...
  • Page 43 Holding down DISPLAY for a minimum of four seconds shows the last code blue time. RESET Ignored Ignored SET/CHANGE STOP/START Halts the code blue event count at the moment the button is Ignored pressed. INCREMENT XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 44 Elapsed Timer Operation A Primex Elapsed Timer is a multi-function device that can operate as digital clock displaying its synchronized time, and a timer with both count up and count down options. When in a count mode, it accurately counts up or counts down to a maximum of 99 hours, 59 minutes, and 59 seconds.
  • Page 45 5. To automatically stop the current count event and reset the count to its start time, press and release the RESET button once. To return to Clock Mode, which displays its synchronized time, press and release the DISPLAY button until the current time is displayed. XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 46 Set Count Up start time You can set the start time using the 3 button Timer Switch Control. For a count up event, the default start time is 0.0:00 00. NOTE In this state the red text labeled on the bottom of the switch control button sets the start time - EXIT, SET/CHANGE, and INCREMENT, the dash, colon, and decimal points are not displayed, and the digit currently being set is flashing.
  • Page 47 4. When the start time is set, press and release the EXIT button to return to Count Down mode. Now, you can press and release the STOP/START button to start, stop or pause the count event. XR Levo Series Digital Clocks/Timers Install Guide...
  • Page 48 A timer begins counting down at each preset time on a schedule. When each countdown function is complete, the timer automatically displays its synchronized time. The countdown schedule and events are configured and managed using the Primex Event Scheduler Pro software and the schedule is downloaded to the system Transmitter.
  • Page 49 Ensuring our customers experience excellent service is of utmost importance to Primex. Our network of Certified Sales and Service Partners offer technical support services for Primex products. If you have purchased Primex products or have a service agreement with a Primex Partner, they are your primary contact for all Technical Support inquires.
  • Page 50 All merchandise returned must be shipped to Primex, Inc. Attn: Returns Dept., N3211 County Road H, Lake Geneva, WI 53147. Primex, Inc. retains the exclusive right to repair or replace the unit at its sole discretion. Such shall be your sole exclusive remedy for any breach of warranty.
