INSTALLATION INSTRUCTIONS AND USER'S MANUAL
HB0019
SIGNATURE SERIES
RESIDENTIAL USE ONLY
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL TO HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGE 7.
Venmar Ventilation Inc., 550 Lemire Blvd., Drummondville, Qc., Canada J2C 7W9
Tel: 1-800-567-3855 Fax: 1-819-475-2660
www.venmar-ventilation.com
04521 rev A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Venmar Signature S1 Series
Summary of Contents for Venmar Signature S1 Series
- Page 1 RESIDENTIAL USE ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL TO HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGE 7. Venmar Ventilation Inc., 550 Lemire Blvd., Drummondville, Qc., Canada J2C 7W9 Tel: 1-800-567-3855 Fax: 1-819-475-2660 www.venmar-ventilation.com 04521 rev A...
- Page 2 WARNING WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR TO REDUCE THE RISK OF INJURY TO PERSON(S) INJURY TO PERSON(S) OBSERVE THE FOLLOWING: IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING*: Use this unit only in the manner intended by the manufacturer.
-
Page 3: About This Manual
ABOUT THIS MANUAL Your new Signature Series range hood can be installed either with an exterior outlet or not. In this last case, you must install your hood with a charcoal filter module (sold separately). Because of the large amount of models covered by this publication, the illustrations are typical ones. -
Page 4: Measure Installation
2. MEASURE INSTALLATION Dimensions for the most common installations are shown below. We recommend to install the hood at a minimum of 20” (508 mm) from an electric range and at 24” (610 mm) from a gas range. For optimal performance, the hood should not be installed more than 30” (762 mm) from cooktop. -
Page 5: Install The Adapter
Remove the filters. Remove the screw located at the bottom of the hood and remove the cover (A) and the adapter/damper assembly (B) from the inside of hood. HO0010 4. CHOOSE THE OPENING Remove the knockouts for the chosen opening (vertical (A) or horizontal (B)) at the back or on top of the hood and for electric connection. -
Page 6: Install The Hood
6. INSTALL THE HOOD Run power cable to installation location. Place the hood at its location. Mark the position of the screws (smaller part of the embossed key holes) with a pen. Remove the hood and install the (4) 1/2” double thread screws leaving a 1/8”... - Page 7 10. USE AND CARE Filters and impeller The filters, impeller and the intake ring should be cleaned frequently. Use a warm detergent solution. The intake ring and impeller are dishwasher safe. To remove the impeller, first take off the intake ring. Then remove the impeller by pulling it down smoothly.
-
Page 8: Operation
11. OPERATION Always turn ON your hood before you begin cooking in order to establish an air flow in the kitchen. Let the blower run for a few minutes to clear the air after you turn off the range. This will help keep the whole kitchen cleaner and brighter. ELECTRONIC CONTROL HC0001 1) Delay switch... -
Page 9: Warranty
Venmar Ventilation inc, or c) a faulty installation or installation contrary to recommended installation instructions. -
Page 10: Service Parts
SERVICE PARTS HL0015 - 10 -... -
Page 11: Technical Specifications
SERVICE PARTS Ref.# Qty. Description Part Number Light Diffuser 01752 30” clear glass 01832 36” clear glass 02049 30” tinted glass 01874 36” tinted glass 02050 White glass holder (the pair) 01991 Almond / Biscuit glass holder (the pair) 01993 Black glass holder (the pair) (also for s/s) 01992 Mesh filters for 30”... -
Page 12: Wiring Diagrams
WIRING DIAGRAMS Signature S1x and S2x Models BULB 40W CONTROL BOARD BULB 40W J1-3 MOTOR J2-5 120W CAPACITOR AUTO- 120 VAC TRANSFORMER LINE 120 VAC NEUTRAL BULB 40W Signature S3x and S4x Models CONTROL BOARD BULB 40W J1-3 LOGIC MOTOR J2-5 LOGIC REFERENCE K1 NO...
