Gree Cozy Series Service Manual page 9

Model
Function
Rated Voltage
Rated Frequency
Total Capacity (W/Btu/h)
Power Input (W)
Rated Input (W)
Rated Current (A)
3
Air Flow Volume (m /h) (H/M/L)**
Dehumidifying Volume (l/h)
EER / C.O.P (W/W)
Energy Class
Model of Indoor Unit
Fan Motor Speed (r/min) (H/M/L)
Output of Fan Motor (w)
Input of Heater (w)
Fan Motor Capacitor (uF)
Fan Motor RLA(A)
Fan Type-Piece
Diameter-Length (mm)
Evaporator
Indoor Pipe Diameter (mm)
unit
Row-Fin Gap(mm)
Coil length (l)×height (H)×coil
width (L)
Swing Motor Model
Output of Swing Motor (W)
Fuse (A)
Sound Pressure Level dB (A)
(H/M/L)
Sound Power Level dB (A)
(H/M/L)***
Dimension (W/H/D) ( mm)
Dimension of Package(W/H/D)(mm)
Net Weight /Gross Weight (kg)
GWC09MA-K1NNA*A
COOLING
220-240V~
50Hz
2500
925
1200
5.45
500
0.8
2.7
/
GWC09MA-K1NNA*A/I
1260/1050/920/730
10
--
1
--
Cross flow fan - 1
Φ85X 596
Aluminum fin-copper tube
Φ7
2.-1.5
581×264×25.4
MP24AA
1.5
PCB 3.15A Transformer 0.2A
37/30/26
--
790×265×170
870×248×355
9/12
GWH09MA-K1NNA*A
COOLING HEATING
220-240V~
50Hz
2500 2800
925 900
1200 1200
5.45 5.45
500
0.8
2.7
/
GWH09MA-K1NNA*A/I
1260/1050/920/73 1320/1200/1100/9
0 50
10
——
1
——
Cross flow fan – 1
Φ85X 596
Aluminum fin-copper tube
Φ7
2.-1.5
581×264×25.4
MP24AA
1.5
PCB 3.15A Transformer 0.2A
37/30/26 37/33/29
——
790×265×170
870×248×355
9/12
