Please read this owner's manual carefully before operating, and keep it for reference.
Split Air Conditioner
Wall Mounted Model
OWNER'S MANUAL
CHANGE & COSY
S RI
WWW.GREE.CA
St-Mathieu-de-Beloeil (Québec) Canada
1-866-680-GREE
© Copyright, Gree, 2012
00638_28/08/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHANGE & COSY Series and is the answer not in the manual?

Questions and answers

Related Manuals for Gree CHANGE & COSY Series

Summary of Contents for Gree CHANGE & COSY Series

  • Page 1 Please read this owner's manual carefully before operating, and keep it for reference. Split Air Conditioner Wall Mounted Model OWNER’S MANUAL CHANGE & COSY S RI WWW.GREE.CA St-Mathieu-de-Beloeil (Québec) Canada 1-866-680-GREE © Copyright, Gree, 2012 00638_28/08/12...

  • Page 2: Table Of Contents

    CONTENTS In accordance with the company’s policy of continual product improvement, this appliance’s aesthetic and dimensional characteristics, technical data and accessories may be changed without notice. GENERAL INFORMATION Notices before use Operation and maintenance Notices for use Parts How to use the wireless remote control 7-8-9-10-11 Emergency operation Maintenance...

  • Page 3: Notices Before Use

    Notices before use Please read the following carefully before operating When the voltage Disconnect the Never splice the is very high, the compo- power supply when power cord or use nents can easily be the air conditioner an extension cord. damaged.

  • Page 4: Notices For Use

    Notices for use Please read the following carefully before operating Do not cut or damage the When the unit is in use, use the remote power cords and control wires. control to adjust the vertical and lateral If they are damaged, have them air direction.
  • Page 5 Notices for use Operating principle and special functions for cooling Principle: The air conditioner absorbs heat in the room and sends it outside, so as the indoor ambient temperature decreases, the cooling capacity will increase or decrease based on the outdoor ambient temperature. Anti-freezing function If the unit is running in COOL mode and on a low temperature, frost will form on the heat exchanger.

  • Page 6: Parts

    Parts Indoor unit Air inlet Air outlet SET TEMP/ AMBIENT TEMP Wireless remote control Cool Heat Power Receive window ON/OFF Outdoor unit Air in (1) Remote control (2) Front panel (3) Filter (4) Guide louver Air out (5) Wall pipe (6) Bind tape (7) Drainage pipe Note:This is just the schematic plan, please refer to the actual product...

  • Page 7: How To Use The Wireless Remote Control

    How to use the wireless remote control Parts and Functions of the Wireless remote control Note: Be sure that there are no obstructions between the receiver and the remote control. Do not drop or throw the remote control. Do not allow the remote control to come into contact with liquids, direct sunlight or intense heat.
  • Page 8 How to use the wireless remote control Parts and functions of the wireless remote control This is a universal wireless remote control, and can be used for several units. The buttons on this control which are not available to this unit will not be described below. + button Press this button to increase the temperature setting.
  • Page 9 How to use the wireless remote control Parts and functions of the wireless remote control This is a universal wireless remote control, and can be used for several units. The buttons on this control which are not available to this unit will not be described below. TIMER ON button Timer On setting: The “ON”...
  • Page 10 How to use the wireless remote control User Guide- General use 1. After turned on, press the button, to run the unit. (Note: When it is powered on, the guide louver of main unit will close automatically.) 2. Press the button to select the desired running mode.

  • Page 11: Emergency Operation

    How to use the wireless remote control • About Lock Press the + and - buttons simultaneously to lock or unlock the keyboard. If the remote control is locked, the icon will be displayed. When any button is pressed, the icon will flash three times. When the keyboard is unlocked, the icon will disappear.

  • Page 12: Maintenance

    Maintenance CAUTION • Turn the power off and remove the power plug before cleaning the air conditioner. Failure to do so may cause electric shock. • Never put water directly into the indoor unit to clean it because this way cause an electric shock. •...

  • Page 13: Maintenance

    Maintenance Remove the air filter Open the surface panel at an angle, pull the air filter downward, and remove it. ( a) Clean the air filter ( b) To clean the dust on the filters, you can either use a vacuum cleaner, or wash them with warm water and a neutral deter- gent if very dirty (i.e.

  • Page 14: Troubleshooting

    Troubleshooting CAUTION Do not repair the air conditioner yourself. Incorrect repairs may cause electric shock or fire, so please contact an authorized service center for professional repair. You can save time and repair fees by going over the troubleshooting tips below. Problem Troubleshooting The unit does not immediately start the air condi-...
  • Page 15 Troubleshooting CAUTION Do not repair the air conditioner yourself. Incorrect repairs may cause electric shock or fire, so please contact an authorized service center for professional repair. You can save time and repair fees by going over the troubleshooting tips below. Problem Troubleshooting A creaking noise can be heard when the unit...
  • Page 16 Troubleshooting CAUTION Do not repair the air conditioner yourself. Incorrect repairs may cause electric shock or fire, so please contact an authorized service center for professional repair. You can save time and repair fees by going over the troubleshooting tips below. Problem Troubleshooting Indoor unit is not delivering air...

  • Page 17: Installation Service Notices For Installation

    Installation service - Notices for installation Important Notices 1. The unit must be installed by a qualified technician according to local regulations and the instructions in this manual. 2. If the air conditioner the instructions in plug, connect it directly to a fixed circuit, A breaker should be installed in the fixed circuit.

  • Page 18: Notices For Installation

    5. Children should be supervised to ensure that they do not play with the appliance. 6. Installation by anyone but a certified GREE technician will void warranty.

  • Page 19: Installation Dimension Diagram

    Installation dimension diagram Installation dimension diagram Space to the ceiling 15 cm (6") Space to the wall 15 cm (6") 15 cm (6") Space to the wall 165 cm (65") Air outlet Space to the floor The dimensions of the space necessary for correct installation of the appliance including the minimum permissible distances to adjacent structures Air inlet side...

  • Page 20: Installing The Indoor Unit

    Installing the indoor unit Install the Rear Panel 1. Always mount the rear panel horizontally. As the water drainage pipe is on the left, when adjusting the rear panel, this side should not be too high; the right side should be slightly higher. Wall Wall 2.

  • Page 21: Installing The Indoor Unit

    Installing the indoor unit NOTE: If the electrical wire is not long enough, please contact the authorized service centre to buy an exclusive electric wire of the correct length. The wire are not allowed • The electric wiring must be correctly connected. Incorrect connection may cause a malfunction.

  • Page 22: Install Outdoor Unit

    Install outdoor unit Electric wiring Handle 1. Disassemble the handle on the outdoor unit right side plate. N(1) blue brown yellow- black 2.Take off cord anchorage. Connect and fix power connect blue green yellow- brown cord (for cooling and heating unit,connect and fix power green connect cord and signal control wire)to terminal block.

  • Page 23: Testing And Post-Installation Verification

    Testing and post-installation verification Check After Installing Items to be checked Possible malfunction Is the unit firmly attached The unit may fall, shake or make noise. Has the refrigerant been tested for leakage It may cause insufficient cooling(heating). Is the heat insulation sufficient? It may cause condensation and dripping.

  • Page 24: Installing And Maintaining A Healthy Filter

    Installing and maintaining a healthy filter Installation Instructions 1. Pull the front panel from the two ends in the direction indicated by the arrows. Then pull the air filter downwards to remove it. (See Fig.a) 2. Mount the healthy filter onto the air filter,(as shown in Fig.b). If the air filter cannot be in- stalled, please mount the healthy filter on the front case.

  • Page 25: Warranty

    Note : The internal compressor is covered by a 5-YEAR limited warranty. During the warranty period, if this air conditioner fails under normal use, GREE will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the air conditioner is returned.
