Summary of Contents for Gree Cozy
- Page 1 Change for Life Split Air Conditioner Owner's Manual Residential Air Conditioners Thank you for choosing Residential Air Conditioners,please read this owner’s manual carefully before operation and retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS Operation and maintenance ............Notices for operation ■ ..............■ Notices for use .......... Names and functions of each part ■ ..........Operation of Remote Controller ■ ............Emergency operation ■ ............. Care and Cleaning ■ ..............■ Troubleshooting Installation service ............ -
Page 3: Notices For Operation
Notices for operation Please read the following carefully before operating Be sure to pull out ★ When the voltage ★ Never splice the is very high, the the power plug as power cord or use components would be easily the air conditioner not in use an extended cord. - Page 4 Notices for operation ★ To adjust the airflow direction ★ Please don't cut off or damage the power cords and control cords. appropriately. When operating the unit, to adjust the vertical and lateral air If they are damaged, please ask the qualified flow direction by use of remote controller.
-
Page 5: Notices For Use
Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function: If the unit is running in COOL mode and in low temperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 0... -
Page 6: Names And Functions Of Each Part
Names and functions of each part Indoor unit Air in ⑵ ⑴ ⑶ Air out ⑹ ⑷ ⑸ Power cable ⑴ H O U R ONOFF ON OF F ⑼ ⑵ Front panel MODE FAN SW I NG I FEE L SLEE P TE M P TI MER - ON... -
Page 7: Operation Of Remote Controller
Operation of Remote Controller ON/OFF Press it to start or stop operation. : Press it to decrease temperature setting. : Press it to increase temperature setting. MODE Press it to select operation mode (AUTO/COOL/DRY/FAN/HEAT). Press it to set fan speed. H O U R ONOFF SWING... - Page 8 Operation of Remote Controller 18 19 20 21 MODE icon: Up & down swing icon: is displayed when pressing If MODE button is pressed, current operation mode icon down button. up & down swing Press this button again to clear the (AUTO), ( COOL), display.
- Page 9 Operation of Remote Controller FAN SPEED display: HEALTH icon: Press FAN button to select the is displayed when pressing the desired fan speed setting(AUTO- HEALTH button. Press this button Low-Med-High). Your selection will again to clear the display. be displayed in the LCD windows, (Not available on all models) except the AUTO fan speed.
- Page 10 Operation of Remote Controller Remote Controller Description ON/OFF : Press this button to turn on the unit . Press this button again to turn off the unit. Press this button to decrease set temperature. Holding it down above 2 seconds rapidly decreases set temperature.
- Page 11 Operation of Remote Controller SLEEP: Press this button to go into the SLEEP operation mode. Press it again to cancel this function. This function is available in COOL, HEAT (Only for models with heating function) or DRY mode to maintain the most comfortable temperature for you. TEMP: Press this button, could select displaying the indoor setting temperature or indoor ambient temperature.
- Page 12 Operation of Remote Controller Combination of "+" and "-" buttons: About lock Press "+ " and "-" buttons simultaneously to lock or unlock the keypad. If the remote controller is locked, is displayed. In this case, pressing any button, blinks three times.
-
Page 13: Emergency Operation
Emergency Operation Emergency Operation When the wireless remote control is lost or damaged, please use the manual switch, at this time, it is running in Auto Run mode that will not change the temperature setting value and fan speed. The manual switch can be operated as follow: At operation: When the unit stopped running, ●... -
Page 14: Care And Cleaning
Care and Cleaning Caution Disconnect the power supply before cleaning and maintenance. ● Do not splash water on the units for cleaning, as electric shocks may occur. ● Wipe the units with a dry soft cloth, or a cloth slightly moistened with water or cleaner (not with ●... - Page 15 Care and Cleaning Check before Use ① Be sure that nothing obstructs the air outlet and inlet. ② Check if the batteries of remote controller are replaced. Check if the installation stand of the outdoor unit is damaged. ③ If damaged, consult the technicians. Maintenance after Use ①...
-
Page 16: Troubleshooting
Troubleshooting CAUTION The air conditioner is not expected to be serviced by users. Incorrect repair may cause electric shock or fire, so please contact an authorized service center for professional service. The following checks prior to contact may save your time and money. Phenomenon Troubleshooting The unit does not operate:... - Page 17 Troubleshooting Phenomenon Troubleshooting Is the power cut off? ● The unit can not be started up: Is the power plug loose? (If applicable ) ● Is the circuit protection device tripped off? ● Is voltage higher or lower? ● (Tested by professionals) Breaking off Is the TIMER correctly used? ●...
- Page 18 Troubleshooting Phenomenon Troubleshooting Indoor unit can not blow air: In HEAT mode, when the temperature of indoor ● heat exchanger is very low, air flow is stopped in order to prevent cold air. (Within 2minutes) In HEAT mode, when the outdoor temperature ●...
-
Page 19: Notices For Installation
Notices for Installation Caution The unit should be installed only by authorized service center according to local or government regulations and in compliance with this manual. Before installing, please contact with local authorized maintenance center. If the unit is not installed by the authorized service center, the malfunction may not be solved due to incovenient contact between the user and the service personnel. - Page 20 Notices for Installation Installation Site of Indoor Unit The air inlet and outlet should be away from the obstructions. Ensure the air can be blown through the whole room. Select a site where the condensate can be easily drained out, and where it is easily connected to outdoor unit.
- Page 21 Notices for Installation Earthing Requirements 1. Air conditioner is type I electric appliance. Please ensure that the unit is reliably earthed. 2. The yellow-green wire in air conditioner is the earthing wire which can not be used for other purposes. Improper earthing may cause electric shock. 3.
-
Page 22: Installation Drawing
Installation Drawing Installation Drawing Space to the ceiling Above 15cm Above 15cm Above Space to the wall Space to the wall Above Above Air outlet side Space to the floor Space to the obstruction Air inlet side 30cm Above Space to the wall 50cm Above Space to the wall Air outlet side... -
Page 23: Installation Of Indoor Unit
Installation of Indoor Unit Installation of Mounting Plate 1.Mounting plate should be installed horizontally. As the water tray's outlet for the indoor unit is two-way type, during installation, the indoor unit should slightly slant to water tray's outlet for smooth drainage of condensate. - Page 24 Installation of Indoor Unit Connecting Indoor and Outdoor Electric Wires 1. Open the front panel upwardly. 2. Screw off the fixing screw of cover plate and screw off cover plate. 3. Put the power connection cable through the back of indoor unit wire hole and take it out. 4.
- Page 25 Installation of Indoor Unit Installation of Indoor Unit External connection The piping can be output from right, right rear, left Gas side piping electric wire ● Liquid side piping or left rear. When routing the piping and wiring from the left Tailing 2 or right side of indoor unit, cut off the tailings Gas side piping...
-
Page 26: Installation Of Outdoor Unit
Installation of Outdoor Unit Electric Wiring 1. Remove handle of right side plate or front side plate of outdoor unit. 2. Take off wire clamp, connect and fix power connect cord to terminal of line bank. Wiring should fit that of indoor unit. 3. -
Page 27: Check After Installation And Operation Test
Check after Installation and Operation Test Check after Installation Items to be checked Possible malfunction Has the unit been fixed firmly? The unit may drop, shake or emit noise. It may cause insufficient cooling(heating) Have you done the refrigerant leakage test? It may cause condensation. -
Page 28: Installation And Maintenance Of Healthy Filter(Optional)
Installation and Maintenance of Healthy Filter(Optional) Installation of Healthy Filter Lift up the front panel from its two ends, as shown by the arrow direction, and (as shown in Fig.a) then remove the air filter. Fig. a Fig. b Attach the healthy filter onto the air filter, Air filter (as shown in Fig.b). -
Page 29: Configuration Of Connection Pipe And Additional Volume Of Refrigerant
Configuration of connection pipe and additional volume of refrigerant 1. Standard length of connection pipe 5m、7.5m、8m 2. Min length of connection pipe For the unit with standard connection pipe of 5m, there is no limitation for the min length of connection pipe. For the unit with standard connection pipe of 7.5m and 8m, the min length of connection pipe is 3m. - Page 30 Configuration of connection pipe and additional volume of refrigerant Sheet 2. Additional refrigerant charging amount for R22 R407C R410A and R134a Diameter of connection pipe mm Indoor unit throttle Outdoor unit throttle Liquid pipe Gas pipe Cooling only, Cooling only Cooling and cooling and heating (g / m)
- Page 32 GREE ELECTRIC A PPL IA NCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai, Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn www.gree.com 66129912628...
