Gree Cozy Series Service Manual page 73

No Description
1 Wall-Mounting Frame
2 Rear Case
3 Evaporator Assy
4 Evaporator Support
5 Cross Flow Fan
6 Bearing cushion rubber base
7 Ring of Bearing
8 Volute tongue
9 Left Axile Bush
10 Crank
11 Axile Bush
12 Swing Louver1
13 Swing Louver2
14 Front Case
15 Filter
16 Remote Control YB1FA
17 Decorate Piece
18 Double-side glue
19 Receiver Board D5183B
20 Front Panel
21 Screw Cover
22 Guide Louver
23 Wire Clamp
24 Rear Clamp
25 Motor MP24AA
26 Motor Clamp
27 Motor FN20J-PG
28 Electric Box Cover 1
29 Covering Plate2
30 Terminal Board
31 Electric Box
32 Main PCB
33 Jumping Connector
34 Transformer 41X26.5G
35 Power Cable
36 Connecting Cable
37 Signal Cable
The above data are subject to be changed without notice.
Part Code
GWC12MB-K1NNA4A/I
01252013
2220245401
0100255802
24212091
10352017
26152022
76512203
26112163
10512037
10582070
10542008
10512156
10512155
20012123
1112220401
305100412
2019223601
55112004
30565012
20012153
24252016
10512157
71010003
26112164
1521210801
26112161
150120874
20102848
20122075
42010266
20112064
30035565
4202300130
43110236
4002048712
400205401
/
GWH12MB-K1NNA4A/I
01252013
2220245401
0100255802
24212091
10352017
26152022
76512203
26112163
10512037
10582070
10542008
10512156
10512155
20012123
1112220401
305100412
2019223601
55112004
30565012
20012153
24252016
10512157
71010003
26112164
1521210801
26112161
150120874
20102848
20122075
42010262
20112064
30035566
4202300130
43110236
4002048712
400205401
40020536
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
