This user's guide provides an overview of the TRF2436 evaluation module (EVM) to
get you started using the TRF2436EVM right away. It also provides a general
description of the features and functions to be considered when using this module.
1
Introduction
2
TRF2436EVM Operational Procedure
3
Physical Description
1
Top Layer 1
2
Ground Plane Layer 2
3
Power Plane Layer 3
4
Bottom Layer 4
1
TRF2436EVM PARTS LIST
1
Introduction
1.1
Purpose
The TRF2436 EVM provides a platform for evaluating the TRF2436 high-power, dual-band RF front-end
under various signals, reference, and supply conditions. Use this document with the EVM schematic
diagram supplied. Using the TRF2436EVM, you can rapidly evaluate the TRF2436 with a minimum of
manual setup.
1.2
System Requirements
Use the following equipment when evaluating the TRF2436EVM:
+3.3-V power supply, 800 mA.
Signal generator: Agilent ESG Series (with baseband I/Q modulation option for modulated testing) or
equivalent.
Spectrum analyzer: Agilent PSA Series (with phase noise option) or equivalent.
Vector signal analyzer: Agilent 89600 Series for 802.16x modulated EVM testing or equivalent.
1.3
Power Requirements
The demonstration board requires only one supply for proper operation. Connect +3.3 V at P1 and the
return to P2. Always terminate active PA outputs before enabling the power supply.
Voltage Limits
Exceeding the maximum input voltages can damage EVM components. Undervoltage can cause improper
operation of some or all of the EVM components.
SLWU038 – August 2006
Submit Documentation Feedback
Contents
..........................................................................................
...........................................................
................................................................................
List of Figures
..........................................................................................
..............................................................................
...............................................................................
......................................................................................
List of Tables
.......................................................................
User's Guide
SLWU038 – August 2006
TRF2436EVM
1
2
3
4
4
5
5
6
TRF2436EVM
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments Chipset TRF2436EVM
Summary of Contents for Texas Instruments Chipset TRF2436EVM
- Page 1 This user’s guide provides an overview of the TRF2436 evaluation module (EVM) to get you started using the TRF2436EVM right away. It also provides a general description of the features and functions to be considered when using this module. Introduction TRF2436EVM Operational Procedure Physical Description Top Layer 1...
-
Page 2: Hardware Configuration
TRF2436EVM Operational Procedure Hardware Configuration The TRF2436EVM can be set up in a variety of configurations to accommodate a specific mode of operation. Before starting an evaluation, decide on the configuration and make the appropriate connections or changes. The demonstration board comes with the following factory-set configuration: Jumper J10 installed between 1-2 Jumper J11 installed between 2-3 Jumper J12 installed between 1-2... -
Page 3: Trf2436Evm
www.ti.com RX Operation 1. Set TR (J13) to logic 0. 2. Set PA_A SEL (J10) to logic 0. 3. Connect a differential LO source to the LOP/LON SMAs (or use an external balun). Set the LO to an appropriate frequency, with the power level between 0 to +4 dBm. Remember that for A-band operation, the LO input frequency is doubled inside the TRF2436;... -
Page 4: Top Layer
Physical Description PCB Layout The EVM is constructed on a 4-layer, 3.6-inch Turbo/HR material. Figure 1 TRF2436EVM 3.6-inch, 0.042-inch thick PCB using Polycad 370 through Figure 4 show the PCB layout for the EVM. Figure 1. Top Layer 1 Figure 2. Ground Plane Layer 2 www.ti.com SLWU038 –... -
Page 5: Figure 3. Power Plane Layer
www.ti.com Physical Description Figure 3. Power Plane Layer 3 Figure 4. Bottom Layer 4 SLWU038 – August 2006 TRF2436EVM Submit Documentation Feedback... -
Page 6: Slwu038 – August
Physical Description Part List Table 1 lists the parts used in constructing the EVM. C4 C6 C11 C15 C17 C24 C5 C9 C12–C14 C16 C19 C20 C22 C25 C26 C31 C7 C8 C18 C10 C23 C29 C21 C32 FL1 FL2 FL3 FL4 J1–J9 J10–J14... -
Page 7: Trf2436Evm
50 OHM LOP SMA LOP SMA 50 OHM LON SMA LON SMA ADT4-1T ADT4-1T 100 OHM IF_SMA 50 OHM 100 OHM IF SMA IF SMA .01uF .01uF MXB SMA MXB SMA TRACE GAP, NO PART TRACE GAP, NO PART TRACE GAP, NO PART TRACE GAP, NO PART Filter, 2400-2484 MHz Filter, 2400-2484 MHz... - Page 8 +3.3V_IN +3.3V_IN 3.3V_IN Filter Block, DC power Filter Block, DC power Murata BNX002-01 Murata BNX002-01 V+IF 120 ohm @100MHz 120 ohm @100MHz 100pF 100pF 1.2pF 1.2pF 5 MIL trace 120 ohm @100MHz 120 ohm @100MHz 33nH 33nH 5 MIL trace 33nH 33nH 1000pF...
- Page 9 PABCA .01uF .01uF ABSEL ABSEL ABSEL PABCB MMDT3906 MMDT3906 MMDT3904 MMDT3904 2K POT 2K POT RXDGC RXDGC RXDGC MMDT3906 MMDT3906 Title Title Title TRF2436 Evaluation Module TRF2436 Evaluation Module TRF2436 Evaluation Module Size Size Size Document Number Document Number Document Number Date: Date: Date:...
-
Page 10: Fcc Warning
EVALUATION BOARD/KIT IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the product(s) must have electronics training and observe good engineering practice standards. -
Page 11: Important Notice
TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated products in automotive applications, TI will not be responsible for any failure to meet such requirements. Following are URLs where you can obtain information on other Texas Instruments products and application solutions: Products Amplifiers amplifier.ti.com...
