SHOCK ABSORBER

ADJUSTING THE REBOUND
DAMPER
Turn screw A to adjust the hydraulic re-
bound damper.
For adjustment refer to the table on the side.
For standard setting, refer to page 11.
ADJUSTING THE HYDRAULIC
COMPRESSION DAMPER
Turn knob A to adjust the hydraulic com-
pression damper.
For adjustment refer to the table on the side.
For standard setting, refer to page 11.
M03_L0008
Increase
braking effect
A
M03_L0021
Increase
braking effect
43
3
A
Decrease
braking effect
Decrease
braking effect
