FLOW AND TEMPERATURE CHART

+30°C
+20°C
+10°C
-10°C
-20°C
-30°C
FIGURE 4.1
This chart shows the relationship between the flow rate and it's effect on the heating and
cooling of the air. The lower the flow rate, the more heating and cooling is achieved. The flow
rate must stay above 170 slpm at all times.
Heating
170 200
Cooling
Flow Rate slpm
+60°F
+40°F
+20°F
230
-20°F
-40°F
-60°F
17 17
