SETUP AND CARE

FIGURE 1.2
ATTACH THE BREATHING TUBE
Thread on the loose running nut of the
Breathing Tube on to the C40
Control Device (03-502). Screw the running
nut in a clockwise direction until tight.
FIGURE 1.4
ADJUST AIR PRESSURE
Adjust the air pressure at the point of
attachment according to the Breathing Air
Pressure Table in the head-top instruction
manual. Then connect the Breathing Air Line
to the flow control device.
03-502
Climate
™
FIGURE 1.3
CONNECT AIR SUPPLY HOSE
Connect a RPB Breathing Air Line insuring
®
the maximum sections and lengths are
within the specifications of the Breathing Air
Pressure Table in the head-top instruction
manual.
FIGURE 1.5
CHECK AIR PRESSURE
Re-check the air pressure at the point of
attachment and adjust it if necessary. Ensure
you are comfortable with the flow of air
inside the respirator.
