H3C LSQM1CGS2QSA0 User Manual

H3C LSQM1CGS2QSA0 interface card
user manual-6PW101
▌Introduction
Overview
The LSQM1CGS2QSA0 interface card provides two QSFP28 ports
and two QSFP+ ports.
Figure 1 Front panel
(1) QSFP+ port LED
(3) QSFP28 port
QSFP+ ports
You can install the following transceiver modules and cables in the
QSFP+ ports on the card:
•
QSFP+ transceiver modules in
•
QSFP+ cables in
•
QSFP+ to SFP+ cables in
Table 1
Table 3.
Table
1
(2) QSFP28 port LED
(4) QSFP+ port
and Table
4.
2.
