- Page 1 BTL 0 1 stage - Instruction for light oil burners model: BTL 4 1 stage BTL 6 1 stage BTL 10 1 stage Cod. 0006080836_200711...
- Page 3 ONE STAGE LIGHT OIL BURNERS GB - Before using the burner for the first time please carefully read the chapter “WARNINGS NOTES FOR THE USER : HOW TO USE THE BURNER SAFELY” in this instruction manual, which is an integral and essential part of the product. The works on the burner and on the esystem have to be carried out only by competent people.
-
Page 4: Warning Notes For The User How To Use The Burner Safely
• If there is any fault or if the equipment is not working properly, de-activate the equipment and do not attempt to repair it or tamper with it directly. In such case get in touch with only qualified technicians. Any product repairs must only be carried out by EOGB authorised assi- stance centres using only original spare parts. -
Page 5: Electrical Supply
ONE STAGE LIGHT OIL BURNERS WARNING NOTES FOR THE USER HOW TO USE THE BURNER SAFELY ELECTRICAL SUPPLY • The equipment is electrically safe only when it is correctly connected to an efficient ground connection carried out in accordance with current safety regulations. -
Page 6: Standard Accessories
ONE STAGE LIGHT OIL BURNERS MODEL BTL 0 BTL 4 BTL 6 BTL 10 2,70 5,10 min kg/h 1,80 2,20 Burner output 10,0 max kg/h 31,9 60,2 min kW 21,3 26,0 Thermic capacity 74,3 118,0 max kW 42,7 56,1 5,5 cst / 20° C Fuel max. - Page 7 ONE STAGE LIGHT OIL BURNERS BTL 0 245 122,5 122,5 218,5 BTL 4 245 122,5 122,5 218,5 BTL 6 245 122,5 122,5 218,5 BTL 10 245 122,5 122,5 218,5 Control box Ignition transformer 7 pole connector Air-damper adjusting screw Reference for disk head positioning...
-
Page 8: Hydraulic Connections
ONE STAGE LIGHT OIL BURNERS N° 0002900860 HYDRAULIC CONNECTIONS Rev. 27/07/99 The pipes that connect the tank tothe burner should be in perfect tight condition; we recommend the use of copper or steel pipes of an adeguate diameter.Fuel gate valves should be fitted at the end of the rigid pipelines.Fit the filter to the suction pipeline after the gate valve. -
Page 9: Installing On Boyler
ONE STAGE LIGHT OIL BURNERS N° 0002933210 DIAGRAM SHOWING HOW TO PLACE THE FLEXIBLE PIPES Rev. 22/09/00 The two flexibles hoses shall be positioned as show on the figure for ensuring correct closing of the cover, they can come out from the lower side or the left side of the burner. N°... -
Page 10: Appliance Specifications
ONE STAGE LIGHT OIL BURNERS APPLIANCE SPECIFICATIONS Extraneous light / advanced ignition During the pre-ventilation and/or pre-starting phase there shall be no flame signal. Should the signal be present, for example for advanced ignition due to bad tightness of the electrovalve, external lighting, short-circuit in the photo- resistance or in the connecting cable, a breakdown in the flame signal amplifier, and so on., when the pre-ventilation... -
Page 11: Ignition And Adjustment
BTL 0 - 4 BTL 6 - 10 N.B. Ignition can be improved under certain working conditions by slightly adjusting the position of the electrodes. -
Page 12: Recommended Nozzles
ONE STAGE LIGHT OIL BURNERS Adjustment data Model Nozzle Pump Burner type flow rate Air gate Disk position adjustment adjustment kg/h n° tacca n° tacca BTL 0 1.00 4,20 0,85 3,50 0,75 3,00 0,60 2,40 0,50 2,00 BTL 4 1,25 5,00 1,10... -
Page 13: Maintenance
ONE STAGE LIGHT OIL BURNERS N° 0002933250 MAINTENANCE Rev. 26/09/00 Most components can be inspected by removing the hood. To inspect the head you must disassemble the component-carrying plate which can be hung on hung on the burner body in two different positions to make work as practical as possible. The motor, transformer and solenoid valve are connected via a connector while the photo-resistor is push-locked into place. -
Page 14: Operating Anomaly
ONE STAGE LIGHT OIL BURNERS OPERATING ANOMALY TYPE OF IRREGULARITY PROBABLE CAUSE RIMEDY The controll-box stops with 1) Photoresistance is cut off or 1) Clean or replace it. flame (red light on) dirty with smoke. The failure is limited to the 2) Boiler fouled 2) Check all smoke circuits inside the boiler flame-controlling device. - Page 15 ONE STAGE LIGHT OIL BURNERS BT 8930/1 N°0002900910 SUNTEC AS 47C 1538 SUNTEC AE 47C 1387 Rev 21/04/94 Rev. 04/05/00 N° 0002900340 DELTA VM 1 LR 24 Rev 21/04/94 1 ELECTROVALVE (USUALLY CLOSED) 2 PRESSURE TEST POINT AND PURGE POINT (1/8”) 3 PRESSURE REGULATION SCREW 4 RETURN...
-
Page 16: Electric Connections
ONE STAGE LIGHT OIL BURNERS N° BT 2125/2 ELECTRIC CONNECTIONS Rev. 17/07/96 The electrical lines should be at an adeguate distance from hot parts.It is advisable to make all the connections with flexible elecric wire. Conductor’s minimun section 1,5 mm -BLOCK LAMP L1 - FASE/PHASE/PHASE PHASE/FASE... - Page 17 ONE STAGE LIGHT OIL BURNERS NOZZLE FLOW-RATE TABLE FOR LIGHT OIL Pump pressure Nozzle Nozzle Nozzle output flow-rate G.P.H. G.P.H. 0,40 1,27 1,36 1,44 1,52 1,59 1,67 1,73 1,80 1,86 1,92 1,98 2,04 2,10 2,15 2,20 0,40 0,50 1,59 1,70 1,80 1,90 1,99 2,08 2,17...
- Page 18 EOGB Energy Products Ltd 5 Howard Road, Eaton Socon, St. Neots, Cambs. PE19 8ET Telephone: 08703 899499 Facsimile: 01480 477022 Website: www.eogb.co.uk 197506...
