LP110/LP110-S
Trigger Monitor
Instructions for Use
ENGLISH
Manufactured by Huntleigh Healthcare Ltd for CANON Medical Systems.
Medical Devices Directive 93/42/EEC
as amended by 2007/47/EC
Manufactured in the UK by Huntleigh Healthcare Ltd. As part of the ongoing development
programme the company reserves the right to modify specifi cations and materials of the
Lifepulse range without notice.
Lifepulse and Huntleigh are registered trademarks of Huntleigh Technology Ltd. 2009.
© Huntleigh Healthcare Ltd. 2009
Advertisement
Table of Contents
Related Manuals for Huntleigh LP110-S
Summary of Contents for Huntleigh LP110-S
- Page 1 Medical Devices Directive 93/42/EEC as amended by 2007/47/EC Manufactured in the UK by Huntleigh Healthcare Ltd. As part of the ongoing development programme the company reserves the right to modify specifi cations and materials of the Lifepulse range without notice.
-
Page 2: Table Of Contents
Contents 1. Quality, Reliability & Safety ..........4 Cautions ....................4 2. Introduction ................ 7 Intended Use ..................7 Preliminary Checks................8 2.2.1 Installation ......................8 2.2.2 Line Power Operation..................... 8 2.2.3 Battery Operation and Low Battery Alarm (LP110 only) ......... 9 2.2.4 Fuses........................ - Page 3 5. Trouble Shooting ..............25 6. Maintenance ............... 26 Care of your Equipment ................ 26 Cleaning and Disinfecting ..............27 Further Maintenance ................27 7. Warranty & Service ............28...
-
Page 4: Quality, Reliability & Safety
Healthcare Ltd. CE MARKING This equipment carries a CE mark but this is only fully valid if it is used in conjunction with cables and accessories approved by Huntleigh Healthcare Ltd. Cautions The following are descriptions of general hazards and unsafe... - Page 5 Do not sterilise this product. Sterilisation environments can Possible cause severe damage. Equipment Do not autoclave or gas sterilise accessories unless Damage manufacturer instructions clearly approve it. The unit is equipped with a touchscreen designed to be operated by fi ngertouch. Do not use sharp instruments to operate.
- Page 6 This product contains sensitive electronics; strong radio frequency fi elds could interfere with the operation of the system. In the event where this occurs, we suggest that the source of interference is identifi ed and the equipment is used ‘out of range’. Do not use this equipment in the presence of fl...
-
Page 7: Introduction
The LP110-S series weighs 2.0Kg and is powered from an AC mains supply only. An optional mounting plate can be fi tted to the underside of the LP110/LP110-S to enable the monitor to be mounted on a wall bracket, stand or gantry. -
Page 8: Preliminary Checks
-10 and 50 °C, and relative humidity of 0-99% (non-condensing) 2.2.1 Installation LP110/LP110-S monitors are supplied with a plug-in mains lead, fi tted with a 3 pin mains plug. The cores use the European colour code : BROWN LIVE... -
Page 9: Battery Operation And Low Battery Alarm (Lp110 Only)
2.2.3 Battery Operation and Low Battery Alarm (LP110 only) The battery, when fully charged will provide approximately 6 hours continuous use. An on-screen battery indicator shows the state of charge at all times. Battery charging takes place whenever the monitor is connected to the mains. When the battery is discharging two fl... -
Page 10: Rear Panel Features
Rear Panel Features Mains Input Socket I/O Sockets (from the top) : • RS232,Trigger O/P, ECG O/P • External Monitor Socket • Equipotential Earth Connector Integral Battery Access Cover Serial Number Label Rating Label 2.4.1 External Pin Out Connections Note: External connections are to be made to IEC60601-1 compliant equipment only. -
Page 11: Patient Inputs
All patient inputs are fully isolated from electrical earth. ECG rate is achieved via conventional electrodes and a 3 way patient cable. The side panel of the LP110/LP110-S has the patient input connector (1). ECG Input The LP110/LP110-S is supplied with an integrated ECG Simulator (2,3,4). -
Page 12: Display
Display The display comprises a waveform for ECG, either single or dual trace. Max/Min Pulse Time & Date Counter * Battery Status 10:40 23/03/10 85 % Pacer Lead ID 25 mm/s Cascaded Waveform (Setup Option) Menu Touchscreen Freeze Size Lead Start/Stop/Clear Lock Waveform... -
Page 13: Specifi Cations
UL 60601-1 1st Edition, CAN/CSA C22.2 No. 601.1-M90 IEC 60601-2-27 2nd Edition 2005 excluding Section 8 ‘ACCURACY OF OPERATING DATA AND PROTECTION AGAINST HAZARDOUS OUTPUT’ LP110-S Only WITH RESPECT TO ELECTRIC SHOCK, FIRE AND MECHANICAL HAZARDS ONLY, IN ACCORDANCE WITH UL60601-1, CAN/CSA C22.2 No 601.1... -
Page 14: General
A fully discharged battery will take approximately 4 hours to recharge to 90% capacity. 240mm wide, 223mm high (including feet), 160mm deep (including Size equipotential earth connector) 2.7Kg (LP110) 2.0Kg (LP110-S) Weight ECG Monitoring Functions 15 – 260 BPM ±1% ±1 digit Heart Rate range I, II, or III Selectable leads 0.5, 1, 2 or 4. -
Page 15: Accessories
Accessories Item Part No. ECG Electrodes - box 300 ACC-OBS-027 3 Way IEC Patient Cable (complete with 900mm chest leads) ACC-VSM-213 Chest Leads - 600mm (IEC) ACC-VSM-214 Chest Leads - 900mm (IEC) ACC-VSM-215 3 Way Trunk ACC-VSM-216 Fixing Kit (a) ACC-VSM-152 Mobile cart with intergrated storage basket (b) ACC-VSM-153... -
Page 16: Equipment Markings
Trigger O/P, ECG O/P Monitor Battery This product may be disposed of only through a government approved collection scheme or treatment facility. Do not dispose of in the domestic refuse. If in doubt contact your local Huntleigh Healthcare Ltd representative. -
Page 17: Operation
Operation General 4.1.1 Switching On To switch the LP110/LP110-S ON, press the main ON / OFF button on the unit front panel. The amber Led will illuminate followed by a short tone. 4.1.2 Displays At switch ON, the LP110/LP110-S will carry out a system self test and display the following welcome screen: Version X.X... -
Page 18: Menu
The LP110/LP110-S is controlled from a series of touch sensitive programmable soft keys which are located along the bottom of the screen. Pressing these will enable the user to access a function or sub menu level. MENU START/STOP/CLEAR PAUSE SIZE LEAD 4.1.3... -
Page 19: Start / Stop / Clear Counter
(requires access code) Service Application Firmware version Battery voltage * Battery charge / discharge cycles * Max run time USB Upgrade Calibrate TS Filter ON ALD ON Reset to factory default settings (Y/N) Exit 4.1.4 Start / Stop / Clear Counter The start / stop / clear counter softkey is only available if the COUNTER setting is switched... -
Page 20: Pause
4.1.5 Pause Pressing the PAUSE soft key will freeze the waveform on the screen, other background applications will continue. Press the PAUSE soft key again to un-freeze the waveform 4.1.6 Size Pressing the SIZE soft key will enable the user to change the size of the waveform (½, 1, 2, 4) on the screen. -
Page 21: Patient Preparation
4.2.1 Patient Preparation Good quality electrodes and patient contact are essential for reliable measurements. Pre gelled electrodes, silver / silver chloride electrodes are recommended. Do not mix electrode types. Prepare the area where the electrode is to be placed, the skin should be abraded slightly with a gauze pad or alternatively, an electrode preparation solution may be used in place of abrasion. -
Page 22: Pausing The Ecg Waveform
4.2.4 PAUSING the ECG waveform Press the PAUSE soft key to freeze the ECG waveform on the screen. Press the PAUSE softkey to un-freeze the waveform. 4.2.5 Adjusting the ECG waveform amplitude Press the SIZE softkey once to increase the size of the waveform on the screen. -
Page 23: Synchronised Output
Synchronised Output The LP110/LP110-S provides a trigger pulse which is used to control other equipment. The synchronised output produces a trigger pulse which is synchronised with the peak of each ‘R’ wave. The synchronised output is provided via the 25 way ‘D’ type connector on the rear panel. -
Page 24: Ecg Simulator
ECG Simulator Note : The ECG simulator should only be used for testing purposes. When the simulator is switched ON, a ‘Simulator ON’ message is displayed on the screen. Connect the patient cable to the unit and the chest leads to the simulator terminals on the right side of the unit. -
Page 25: Trouble Shooting
Trouble Shooting This section gives some of the more common problems encountered during use together with their possible causes. If the operator cannot locate the problem after consulting the table in this section, the monitor should be switched off, disconnected from mains power source and a qualifi ed technician should be consulted. -
Page 26: Maintenance
Maintenance Care of your Equipment Although the LP110/LP110-S is robust and has been designed to withstand normal clinical use, the unit contains delicate components, such as the display and accessories, which should be handled and treated with care. It is recommended that the unit and accessories are inspected and tested on a regular basis. -
Page 27: Cleaning And Disinfecting
Butyl alcohol, Denatured ethanol, Freon™, Mild chlorine bleach solution, Isopropyl alcohol, Trichloroethane, Trichloroethylene, Acetone, Vesphene II, Enviroquat®, Staphene®, Misty®, Glutaraldehyde. Further Maintenance Huntleigh Healthcare Ltd recommends that preventative maintenance checks are carried out at least annually. Maintenance must only be carried out by suitably qualifi ed personnel... -
Page 28: Warranty & Service
A copy is available on request. These contain full details of warranty terms and do not limit the statutory rights of the consumer. Service Returns If for any reason the LP110/LP110-S has to be returned, please: • Clean the product following the instructions in this manual.
