- Page 1 SETUP INSTRUCTIONS 2014 690 Duke EU 690 Duke AU/GB 690 Duke US 690 Duke MY 690 Duke R EU 690 Duke R AU/GB 690 Duke R MY Art. no. 3213153en...
- Page 3 KTM accepts no liability for delivery options, deviations from illustrations and descriptions, as well as misprints and other errors.
-
Page 4: Means Of Representation
MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 SETUP Unpacking and setting up the vehicle – Remove the box and the plastic packaging. Info To avoid damaging the motorcycle while mounting the handlebar, leave the film on the fuel tank until all of the work on the motorcycle has been fin- ished.
- Page 6 Recharge the battery. ( p. 5) – Install the battery. ( p. 6) – Refuel. ( p. 7) – Print out the current PDI form found on KTM DEALER.NET and perform the delivery inspection. – Set kilometers or miles. ( p. 7)
-
Page 7: Recharging The Battery
– Do not discard batteries with the household waste. Dispose of faulty batteries in an environmentally compatible manner. Give the battery to your authorized KTM dealer or dispose of it at a collection point for used batteries. Warning Environmental hazard Hazardous substances cause environmental damage. - Page 8 WORK – Disconnect the negative cable of the battery to avoid damage to the motorcycle's electronics. Main work – Connect the battery charger to the battery. Switch on the battery charger. Battery charger (58429074000) You can also use the battery charger to test the rest potential and start potential of the battery, and to test the alternator.
-
Page 9: Setting The Clock
WORK Setting the clock Condition The motorcycle is stationary. – Switch on the ignition by turning the ignition key to the position – Press the MODE button repeatedly until the ODO mode is active. – Keep the MODE button and the SET button pressed simultaneously. The time display begins to flash. - Page 10 WORK – Switch off the engine. – Open the filler cap. ( p. 8) – Fill the fuel tank with fuel up to the lower edge of the filler neck. Total fuel tank 13.8 l Super unleaded (ROZ 95/RON 95/PON capacity, approx.
- Page 11 WORK – Remove the ignition key and close the cover.
-
Page 12: Technical Data - Tightening Torques For Chassis
TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS – Screw, combination instrument EJOT 1 Nm (0.7 lbf ft) – Screw, headlight EJOT 2 Nm (1.5 lbf ft) – Screw, headlight mask EJOT 1 Nm (0.7 lbf ft) Screw, side stand switch 2 Nm (1.5 lbf ft) Loctite ®... - Page 13 TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS Loctite ® 243™ Screw, footrest bracket, rear M8x45 Countersunk screw 25 Nm (18.4 lbf ft) – Screw, fork stub 15 Nm (11.1 lbf ft) Screw, front brake disc 30 Nm (22.1 lbf ft) Loctite ®...
- Page 14 SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
- Page 15 *3213153en* 3213153en 01/2014 KTM-Sportmotorcycle AG 5230 Mattighofen/Austria Photo: Mitterbauer/KTM http://www.ktm.com...
