6 0 0 C F M F L E X I B L E B L O W E R
A B O U T T H I S M A N U A L
Signal Words for Safety and Best Use
WARNING
This indicates that death or serious injuries may occur as
a result of non-observance of this warning.
CAUTION
This indicates that minor or moderate injuries may occur
as a result of non-observance of this warning.
NOTICE: This indicates that damage to the appliance or
property may occur as a result of non-compliance with
this advisory.
Note: This alerts you to important information and/or tips.
Pay special attention to the important safety instructions in the
"Safety" section.
I M P O R T A N T S A F E T Y I N S T R U C T I O N S
READ AND SAVE THESE INSTRUCTIONS
General notes
Note: Examine the appliance after unpacking it. In the event of
transport damage, do not plug it in.
Note: Do not remove any of the aluminum tape as it is needed
for sealing air leaks.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
Before servicing or cleaning unit, switch power off at service
panel and lock the service disconnecting means to prevent
power from being switched on accidentally
When the service disconnecting means cannot be locked,
securely fasten a prominent warning device, such as a tag,
to the service panel.
INSTALLATION INSTRUCTIONS
F O R U S E W I T H
T H E S E D O W N D R A F T
M O D E L S
CAUTION
To reduce the risk of fire and electric shock, install this blower only
with downdraft hood models shown below. Other downdraft hood
models cannot be substituted. (Downdraft hoods sold separately).
Models HDD80050UC / HDD86050UC
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable codes
and standards, including fire-rated construction.
Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of fuel
burning equipment to prevent back drafting. Follow the
heating equipment manufacturer's guideline and safety
standards such as those published by the National Fire
Protection Association (NFPA), and the American Society
for Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
Ducted fans must always be vented to the outdoors.
Model DHG602DUC
