13. Untie and discard the wire tie.
While a second person holds the Console (33)
near the Upright (5), connect the console wires
to the Wire Harness (60) and to the Pulse Wires
(34).
Insert the excess wire into the Console (33) or
into the Upright (5).
Tip: Avoid pinching the wires. Attach the
Console (33) to the Upright (5) with four M4 x
16mm Screws (93).
14. Attach the Front Upright Cover (25) by pressing
the tabs on the Front Upright Cover into the
Rear Upright Cover (24).
All manuals and user guides at all-guides.com
12
13
33
60
14
24
Avoid pinching
the wires
Console Wires
34
5
93
25
