USG Quick Start Guide
Console
RJ45 serial console port for CLI management. Use a RJ45-to-DB9 serial console cable to
connect the Console port to your computer. Then configure using the following settings:
Baud rate 115200
Data bits 8
Parity NONE
Stop bits 1
Flow control NONE
Reset
Resets to factory defaults. The UniFi Gateway should be powered on. Press and hold the Reset
button for about 10 seconds until the right LED on the WAN 2 / LAN 2 port starts flashing and
then becomes solidly lit. After a few seconds, the LED will turn off, and the UniFi Gateway will
automatically reboot.
WAN 1 Port
Supports 10/100/1000 Ethernet WAN connections. Default setting is DHCP client.
LAN 1 Port
Supports 10/100/1000 Ethernet LAN connections. Default setting is DHCP Server.
Server IP: 192.168.1.1/24
WAN 2 / LAN 2 Port
Supports 10/100/1000 Ethernet connections. Configure the port using the UniFi Gateway
configuration interface.
LEDs
