SpeakerCraft SC-BT-10 Manual

ALL-WEATHER LANDSCAPE BURIAL SUBWOOFERS

Burial Subwoofers: 10" & 12" (250mm & 300mm)
CONTENTS
10" Burial Subwoofer:
ƒ (1) Burial Subwoofer with Direct Burial Cable
Attached
ƒ (2) Silicone-Filled Wire Connectors
12" Burial Subwoofer Box 1 of 2:
ƒ Burial Subwoofer with Direct Burial Cable
Attached
ƒ (2) Silicone-Filled Wire Connectors
12" Burial Subwoofer Box 2 of 2:
ƒ (1) Burial Subwoofer Canopy Assembly
ƒ (1) Port Tube with Compression Clamps
REQUIRED TOOLS:
ƒ Wire Strippers
ƒ Digging Tools as needed for the
soil type
ƒ Measuring Tape
ƒ Slotted Screwdriver
ƒ Pea Gravel
(optional, recommended as a drainage base for
high clay content soils)
AMPLIFICATION GUIDELINES:
Crown CDi 2|600 Amplifier
These Subwoofers are 8Ω and are optimized for
use with the Crown CDi 2|600 amplifier which is
preprogrammed with customized DSP settings
for a variety of different speaker/ subwoofer
installations. Please refer to the addendum
included in the Crown CDi 2|600 for additional
instructions.
Other Amplifiers
These Subwoofers are 8Ω and are compatible
with low impedance amplifiers with low pass
filters. The minimum recommended power
per channel in low impedance mode is 100W/
Channel. A low pass filter that slightly overlaps
the high pass filter of the associated satellite
speakers is recommended for proper blending.
WARNING:
ƒ PLEASE READ AND FOLLOW ALL
INSTRUCTIONS BEFORE BEGINNING YOUR
INSTALLATION.
ƒ POTENTIAL HAZARDS SUCH AS ELECTRICAL,
GAS, BURIED CABLES, PLUMBING OR OTHER
OBSTACLES SHOULD BE VERIFIED AND
CHECKED BEFORE INSTALLING GROUND
STAKES AND/OR OTHER ACCESSORIES.
ƒ MANY LOCALITIES FORBID DIGGING
WITHOUT PRIOR AUTHORIZATION, SO
CONTACT LOCAL AUTHORITIES BEFORE
INSTALLATION.
SPEAKER CABLE
Burial–rated cable (not included) is strongly
recommended. It is also important to use the
proper speaker cable gauge depending on
the size of your area.
Cable Gauge
18 Gauge
16 Gauge
14 Gauge
12 Gauge
10 Gauge
INSTALLATION
CONSIDERATIONS
Before you start digging a trench:
ƒ Test EACH speaker prior to installation.
ƒ Verify that the proposed area is accessible
and not prone to flooding or standing water.
It is also important to ensure your speakers
cannot be easily damaged, kicked, or hit.
ƒ Take into consideration the overall
landscape/garden design and positioning in
relation to listening area.
1
Distance
Up to 100 ft (30m)
Up to 150 ft (45m)
Up to 200 ft (61m)
Up to 400 ft (122m)
Up to 650 ft (198m)
