CPX-Terminal
Brief description
CPX field bus
node
type CPX-FB6
– English
8101668
2018-11a
[8101670]

Advertisement

loading

Summary of Contents for Festo CPX-FB6

  • Page 1 CPX-Terminal Brief description CPX field bus node type CPX-FB6 – English 8101668 2018-11a [8101670]...
  • Page 2 Translation of the original instructions Documentation on the product For all available product documentation è www.festo.com/pk Copyright: Festo AG & Co. Ruiter Straße 82 73734 Esslingen Germany Internet: http://www.festo.com E-Mail: service_international@festo.com Reproduction, distribution or sale of this document or communication of its contents to others without express authorization is prohibited.
  • Page 3 User instructionsEnglish The field bus node CPX-FB6 for CPX terminals is intended exclusively for use as a slave on the Interbus. The maximum values specified in the section “Technical specifications” must be observed here. Detailed informa­ tion can be found in the manual for the field bus node P.BE-CPX-FB6-..
  • Page 4 (yellow) active) Transmit/Receive (yellow) In normal operating status all green LEDs light up; the yellow and red LEDs do not light up. Without a field bus connection the LEDs UL, RD, PS and PL light up. Festo CPX-FB6 2018-11a English...
  • Page 5: Installation Instructions

    Installation instructions 3.1 Fitting Field bus node CPX-FB6 is mounted in a manifold sub-base of the CPX terminal. Screws, tightening torque 0.9...1.1 Nm Field bus node CPX-FB6 Contact rails Manifold sub-base Dismantling Remove the screws and carefully lift up the field bus node.
  • Page 6 4.2 = OFF 4.1 = OFF Status bits 4.2 = ON 4.1 = ON I/O diagnostic interface 4.2 = OFF 4.1 = ON Reserved 4.2 = ON Only valid if switch 1.1 = OFF Factory setting Festo CPX-FB6 2018-11a English...
  • Page 7 The plug housing is connected to the FE of the CPX terminal by means of an R/C combination. The plug housing is connected to the FE of the CPX terminal. Sub-D plug and socket from Festo: Connection Plug/socket type...
  • Page 8 CPX-GE-EV-S Operating voltage for the Manifold sub-base without electronics and sensors supply type CPX-GE-EV Load voltage for digital Manifold sub-base with addi­ outputs tional supply type CPX-GE-EV-Z Functional earth (FE) (pin 1 not assigned) Festo CPX-FB6 2018-11a English...
  • Page 9 1. Operating volt­ 1. Not connected age supply for electronics and sensors (V EL/SEN 2. Load voltage for 2. Load voltage valves and out­ puts (V 3. 0 V 3. 0 V 4. Earth/ground 4. Earth/ground connection connection Festo CPX-FB6 2018-11a English...
  • Page 10 External fuses CPX-GE-EV-S The load voltage of the valves/ Connection of outputs can be switched off additional supply for separately electric outputs type CPX-GE-EV-Z Earth connection pin 4 is designed for 16 A Festo CPX-FB6 2018-11a English...
  • Page 11 Detailed instructions can be found in the manual for the field bus node P.BE-CPX-FB6-.. or in the manual for your handheld. Festo CPX-FB6 2018-11a English...
  • Page 12: Technical Specifications
