Configuring RTSP Stream URI

In the Compression and Image Rate page, you can also configure
the camera's real time streaming protocol (RTSP). The RTSP
Stream URI allows you to watch the camera's live video stream
from any application that supports viewing RTSP streams,
including many video players.
1. To set the protocol, select either Unicast or Multicast in
the RTSP Stream URI area then click Apply.
2. To watch the camera's live video stream from an external
video player, click Generate RTSP Stream URI.
a. Copy and paste the generated address in to your video
player. DO NOT open the live video stream yet.
b. Add your username and password to the beginning of
the address. Use this format:
http://<username>:<password>@<
>/
URI
For example:
defaultPrimary?streamType=u
c. Open the live video stream.

Motion Detection

On the Motion Detection page, you can define the green motion
detection areas in the camera's field of view. Motion detection is
ignored in areas not highlighted in green.
If motion is detected anywhere in the camera's field of view, the
motion indicator on the top right corner turns red. To help you
define motion sensitivity and threshold, motion is also highlighted
in red in the image panel.
10
rtsp://admin:admin@192.168.1.79/
generated RTSP Stream
