Annex

Technical data
Standard:
Frequency range:
Transmission performance: 10 mW on average
SMA socket:
Voice transmission:
Fax mode:
Modem mode:
Dialling mode:
Connectable telephones:
CLIP:
Operating temperature:
Relative humidity:
Permissible
storage temperature:
Display unit:
Dimensions:
Weight:
Mounting location:
Power supply:
Delivery package:
Product approval/CE mark
disty communications gmbh hereby declares that the distybox 300/5000
conforms to the fundamental requirements and other relevant regulations
stated in Directive 1999/5EU (Radio and Telecommunication Terminal
Equipment, R&TTE). Conformity is declared by the CE mark. The full de-
claration of conformity can be viewed on the following website: www.dis-
ty.de
Cleaning
Simply wipe the device with a slightly damp cloth or with an antistatic
cloth; do not use a dry cloth. Do not use cleaning or scouring agents.
DECT (Digital Enhanced Cordless
Telecommunications, GAP-compatible
1880 MHz to 1900 MHz
For connecting an external aerial via coaxial
cable (distybox 5000 only)
32 kbit/s ADPCM
Group 3, V.29, 9600 bit/s maximum
9600 bit/s maximum
DTMF (voice frequency signalling)
Up to three standard telephones can be
connected in parallel
Transmission via FSK1; protocol conforms to
ETSI standard
+10°C to +40°C
20% to 75%
-10°C to +60°C
LED
120 x 100 x 38 mm (W x H x D)
140 g
Wall mounting in interior rooms
10 V AC (0.12 A zero signal current, 0.4 A
maximum); alternatively, 12 V DC +/- 15%
= 10.2-13.8 V (0.12 A zero signal current,
0.4 A maximum)
230 V AC, 50 Hz power supply unit, optional
adapter
