1
1.1
Selecting a The distybox is designed for wall mounting in interior rooms.
suitable
location
NOTE Please note that the device must not be fitted in the immediate vicinity of
any other electronic devices such as hifi systems, office machines or micro-
wave ovens. This prevents any interference between the devices. In additi-
on, the device should not be installed near heat sources (e.g. radiators or in
direct sunlight).
To prevent noise interference when making calls, the connected terminal
should not be positioned closer than one metre away from the distybox.
Radio coverage
The distybox must be able to establish a radio link to the DECT base stati-
on. Before determining the final mounting position, you should therefore
check that your desired location is within the range of the DECT base sta-
tion.
Owing to the digital transmission in the frequency range used, there may
be radiowave "blind spots" even within the specified range, depending on
the nature of the building. This results in a loss of transmission quality.
However, just a small change in position will restore normal transmission
quality. As the distybox works as a cordless unit on your DECT base stati-
on, you can use your cordless handset to check whether or not the
mounting position is suitable.
Wall mounting Follow the steps given below to install the distybox
1. Drill two 6 mm diameter holes into the wall at a distance of 60 mm
2. Insert the rawl plug and turn the screws until they are approx. 5 mm
3. Connect the external aerial to the appro-
4. Connect your terminal to the distybox.
5. Connect the distybox to the power sup-
6. Fit the distybox in place.

Commissioning

Mounting

apart.
away from the wall.
priate socket (distybox 5000 only).
ply.
5
60 mm
