- Page 2 THIS MANUAL MUST REMAIN WITH THE PRODUCT OWNER FOR FUTURE REFERENCE. This manual covers the following BROILMASTER products: POWER BURNER / DOUBLE SIDE BURNER SINGLE SIDE BURNER MODELS BSABW16 BSABF12 BSAF12D F O R O U T D O O R U S E O N L Y IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH.
- Page 3 TABLE OF CONTENTS BROILMASTER BBQ Models......................2/4 Overall Dimensions .......................... 5 Combustible Enclosure........................6 Warning Before Use.........................7 Safety Information..........................8 NOTICE: Commonwealth Of Massachusetts / CA Prop 65..............9 Gas Accessory Conversion......................10 LP Gas Cylinder Safety Information....................11 Gas Requirements and Connections....................12-15 Power Burner Use..........................16 Gas Connections..........................17 Lighting Instructions..........................18 Equipment Location..........................19...
- Page 4 USING YOUR ACCESSORY This manual covers several accessory appliances and optional accessories for those appliances. ACCESSORIES COVERED IN THIS MANUAL SINGLE SIDE BURNER BSAF12D DOUBLE SIDE BURNER BSABF12 PR EM IU M GR ILL S POWER BURNER BSABW16 Page 4...
- Page 5 Overall Gas Appliance Dimensions PR EM IU M GR ILL S Page 5...
- Page 6 Built-In Sleeve Dimensions FOR COMBUSTIBLE INSTALLATIONS DOUBLE SIDE BURNER STEP 1: Place the Stainless Sleeve into the combustible construction STEP 2: Place equipment into sleeve and connect gas POWER BURNER STEP 1: Place the Stainless Sleeve into the combustible construction STEP 2: Place equipment into sleeve and connect gas PR EM IU M GR ILL S Page 6...
- Page 7 WARNING • Read this manual carefully and completely before using your grill, to reduce the risk of fire, burn hazard or other injury, and to ensure proper installation and servicing. • Never use rusted, dented or damaged propane cylinders. Never store additional or empty propane cylinders in the grill cabinet or in the vicinity of this or any other gas or electrical appliance.
- Page 8 Important Grilling Safety Information 1. ALWAYS ENSURE THAT SOMEONE IS 8. Never use charcoal in this gas Gas AT THE GAS APPLIANCE AT ALL Appliance. TIMES. 9. Be aware that cooking excessively fatty 2. Prior to using Gas Appliance ensure that meats and other such products will all tie down wires have been removed cause flare ups.
- Page 9 NOTICE: Commonwealth Of Massachusetts 1. Massachusetts requires all gas be installed using a plumber or gas fitter carrying the appropriate Massachusetts license. 2. All permanently-installed natural gas or propane installations require a “T” handle type manual gas valve be installed in the gas supply line to this appliance. 3.
- Page 10 Converting Your Gas Accessory Your BROILMASTER appliance comes equipped to be converted to the opposite gas. Each appliance comes "GAS SPECIFIC", natural gas and packed with an LP gas conversion kit. On the side of the GAS BBQ there will be a rating plate that specifies the "GAS TYPE"...
- Page 11 LP Gas Cylinder Safety LP gas accessory models are designed for your gas accessory is adjusted to have an use with a standard 20lb. Liquid Propane outlet pressure of 11" water column (W.C.) Gas (LP Gas) tank (sold separately. Never for connection to an LP gas tank.
- Page 12 Gas Requirements And Hook-up LP GAS MODEL ONLY - TYPE 1 CHECK ALL CONNECTIONS CONNECTION WITH REGULATOR FOR LP GAS LEAKS. AND HOSE TO YOUR LP GAS TANK. Never test for leaks with an open flame. Connect and tighten the swivel nut of the gas Prior to first use, at the beginning of each hose to the Gas Appliance manifold shown season, or every time your LP Gas tank is...
- Page 13 Gas Requirements And Hook-up (Cont'd.) CAUTION: DISCONNECTING A LIQUID When the appliance is not in use the gas must be turned off at the tank. Place PROPANE GAS (LPG) TANK FROM dust cap on cylinder valve outlet whenever YOUR Gas Appliance the cylinder is not in use.
- Page 14 Gas Requirements And Hook-up (Cont'd.) CONNECTING TO A PERMANENTLY Whether the Gas Appliance is built-in to a permanent structure, the use of a S/S PLUMBED GAS LINE Flex-Line is recommended from Gas Appliance to gas supply. Follow the diagrams below when connecting gas to your Gas Appliance Connect the Swivel nut of the flex-line or from a natural gas line or a permanently...
- Page 15 Gas Requirements And Hook-up (Cont'd.) GAS SAFETY INSTRUCTIONS CHECK ALL CONNECTIONS FOR GAS LEAKS Your gas Appliance is designed for use with natural gas (NG) or LP gas. The gas Never test for leaks with an open flame. pressure regulator supplied with this Prior to first use and at the beginning appliance must be installed and used on your of each season, you must check for gas...
- Page 16 USING THE BROILMASTER POWER BURNER The BROILMASTER Power Burner incorporates a cast Stainless, dual-ring, burner. Each ring can be independently operated for maximum heat control. Used together they can generate up to 60,000 BTU’s. The knob on the left controls the outer burner ring and the knob on the right controls the inner burner ring.
- Page 17 maxImum runs for all applIances on supply lIne WarnIng Run Length Max BTU for all COLD WEATHER WARNING: PROPANE 3/4” Pipe (in feet) Appliances on line Extremely cold temperatures may cause your burner to 360,000 light inside the burner instead of outside. Once lit, if you hear a ‘whooshing’...
- Page 18 LIGHTING INSTRUCTIONS FOR ALL GAS ACCESSORIES SIDE BURNER / DOUBLE SIDE BURNER • Press and 1/4 turn - Hold knob in and wait a few seconds • Once you hear "Gas" turn to the left and you will hear a "CLICK" sound and the burner should ignite •...
- Page 19 Location of your Gas Accessory The BROILMASTER Built in model is designed for easy installation into a non-combustible masonry enclosure. The BBQ must be surrounded by non-combustible material like Brick or Hardibacker but should never be installed into a wood island without a non-combustible enclosure (accessory) surrounding the Gas gas appliance Accessory.
- Page 20 Vent Registers LP Gas REQUIRED WHEN AN LP GAS TANK IS USED 10 Square Inch Minimum Each Register. 2 Per Side. 1 High And 1 Low 2 1/4" Minimum Ground To Vent Bottom INSULATED SLEEVE INSTALLATION INSTRUCTIONS IMPORTANT: Before you build the frame, you must take into consideration the total weight of the sleeve, Gas Appliance and any finishing materials.
- Page 21 WARNING Spiders and small insects can spin webs and nest in the grill burner ventures which can lead to a gas flow obstruction resulting in a fire in and around the burner tubes. This type of "FLASHBACK FIRE" can cause serious Gas Appliance damage and create an unsafe operating condition for the user.
- Page 22 Cleaning The Gas Appliance Proper care and maintenance will keep your Gas Appliance in top operating condition and prolong its life. Follow these cleaning procedures on a timely basis and your Gas Appliance will stay clean and operate with minimum effort. CAUTION: Be sure your Gas Appliance is OFF and cool before cleaning.
- Page 23 Cleaning The Gas Appliance (Cont'd.) TO HELP MAINTAIN THE FINISH OF STAINLESS STEEL FOLLOW THESE CLEANING EXTERIOR STAINLESS CLEANING PROCEDURES FOR THE STEEL SURFACES: BEST RESULTS: Routine care and maintenance is required 1. After every use (after your Gas to preserve the appearance and corrosion Appliance has cooled down), wipe resistance of stainless steel.
- Page 24 BROILMASTER Limited Warranty WARRANTY TERMS FOR EMPIRE COMFORT SYSTEMS INC. BROILMASTER Stainless Steel Gas Grills Models: BSG262N, BSG343N, BSG424N Empire Comfort Systems Inc. warranties this BROILMASTER stainless steel gas accessory to be free from defects at the time of purchase and for the periods specified below. The grill must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner's manual.
-
Page 25: Master Parts Distributor List
MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www. empirecomfort.com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit. To Order Parts After the Warranty Period, please contact your dealer or one of the Master Parts Distributors listed below. - Page 26 Contacting Your BROILMASTER Dealer Before calling your BROILMASTER Dealer, please make sure you have the following information: • Model number • Date of purchase • Proof of purchase by the original owner • Serial number The serial number can be located on the rating plate which is located on the left side of the Gas Appliance or on the pull-out drip tray lighting instructions and also on the underside of the drip tray.
- Page 27 SIDE BURNER EXpLODED pARTS VIEW PR EM IU M GR ILL S Page 27...
- Page 28 DOUBLE SIDE BURNER EXPLODED PARTS VIEW PR EM IU M GR ILL S Page 28...
- Page 29 POWER BURNER EXPLODED PARTS LIST PR EM IU M GR ILL S Page 29...
- Page 30 PR EM IU M GR ILL S BROILMASTER A Division of Empire Comfort Systems, Inc. 918 Freeburg Ave. Belleville, Illinois 62220 Visit our web site at www.broilmaster.com If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer.
