AUD2MP1
USER MANUAL
VOLUME1
Manufactured by R.V.R ELETTRONICA S.p.A. Italy

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUD2MP1 and is the answer not in the manual?

Questions and answers

Related Manuals for R.V.R. Electronica AUD2MP1

Summary of Contents for R.V.R. Electronica AUD2MP1

  • Page 1 AUD2MP1 USER MANUAL VOLUME1 Manufactured by R.V.R ELETTRONICA S.p.A. Italy...
  • Page 2 J. H. Berti 10/02/2015 Hardware update J. H. Berti 10/07/2015 Hardware update J. H. Berti AUD2MP1 - User Manual Version 1.2 © Copyright 2014-2015 R.V.R. Elettronica SpA Via del Fonditore 2/2c - 40138 - Bologna (Italia) Telephone: +39 051 6010506 Fax:...
  • Page 3 AUD2MP1 ELETTRONICA ECLARATION OF ONFORMITY We, the undersigned, Manufacturer’s Name: R.V.R. Elettronica SpA Manufacturer’s Address: Via del Fonditore 2/2c Zona Ind. Roveri 40138 Bologna Italy Certify and declare under our sole responsibility that the product: Product Description: Digital/SCA/RDS/MPX/Analog Stero& Mono 2-Way...

  • Page 4: Technical Description

    AUD2MP1 ELETTRONICA Technical Description AUD2MP1 Parameters Conditions U.M. Value Notes GENERALS Phisical Dimensions 436 x 41 x 239 W x H x D W x H x D Overall Dimensions 483 x 44 x 252,6 complete with 19” panel Weight complete with 19”...

  • Page 5: Table Of Contents

    AUD2MP1 ELETTRONICA Table of Contents Preliminary Instructions Warranty First Aid Treatment of electrical shocks Treatment of electrical Burns General Description Unpacking Features Rear Panel Description Connectors Pinouts Quick guide for installation and use Preparation Working Principles User Manual Rev. 1.2 - 10/07/15...
  • Page 6 AUD2MP1 ELETTRONICA This page was intentionally left blank User Manual Rev. 1.2 - 10/07/15...

  • Page 7: Preliminary Instructions

    AUD2MP1 ELETTRONICA IMPORTANT The symbol of lightning inside a triangle placed on the product, evidences the operations for which is necessary gave it full attention to avoid risk of electric shocks. The symbol of exclamation mark inside a triangle placed on the product, informs the user about the presence of instructions inside the manual that accompanies the equipment, im- portant for the efficacy and the maintenance (repairs).

  • Page 8: First Aid

    AUD2MP1 ELETTRONICA • Do not stop chest compressions while giving Units returned without a return authorisation may artificial breathing. be rejected and sent back to the sender. • Call for medical help as soon as possible. Be sure to include a detailed report mentioning all problems you have found and copy of your original 3.1.2...

  • Page 9: General Description

    4. General Description The AUD2MP1 is a passive 2-way audio distributor, Digital/MPX+RDS+SCA1+SCA2/ Analog stereo or mono, working in a wide range of levels. The AUD2MP1 is designed to being contained into a 19” rack box of 1HE. 4.1 Unpacking The package contains:  1 AUD2MP1...

  • Page 10: Rear Panel Description

    OUT R2 OUT1 OUT2 OUT1 OUT2 Figure 4.1 - AUD2MP1/V4 configuration L&R, MONO, MPX , AES/EBU, SCA1, SCA2, RDS [1] AES-EBU IN XLR female connector, balanced AES/EBU digital audio input. [2] AES-EBU OUT 1 XLR male connector, balanced AES/EBU digital audio output 1.

  • Page 11: Connectors Pinouts

    AUD2MP1/V1 and AUD2MP1/V2). [8] SCA1 OUT 1 BNC female connector, unbalanced SCA1 analog output 1 (not available on AUD2MP1/V1 and AUD2MP1/V2). [9] SCA1 OUT 2 BNC female connector, unbalanced SCA1 analog output 2 (not available on AUD2MP1/V1 and AUD2MP1/V2).

  • Page 12: Quick Guide For Installation And Use

    AUD2MP1 ELETTRONICA 5. Quick guide for installation and use This section provides a step-by-step description of equipment installation and configuration procedure. Follow these procedures closely upon first power-on and each time any change is made to general configuration, such as when a new transmission station is added or the equipment is replaced.

  • Page 13: Working Principles

    AUD2MP1 ELETTRONICA 6. Working Principles A schematic view of the modules and connections making up the AUD2MP1 is shown in following figures. L&R 1 L&R 1 XLR F XLR F L&R L&R XLR M XLR M ÷ L&R 2 L&R 2...
  • Page 14 AES/EBU AES/EBU XLR M XLR M AES/EBU 2 AES/EBU 2 XLR F XLR F Figure 6.3 - - AUD2MP1/V3 configuration L&R, MONO, MPX , AES/EBU, SCA1, RDS L&R 1 L&R 1 XLR F XLR F L&R L&R XLR M XLR M ÷...
  • Page 15 ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
  • Page 16 ISO 9001:2000 certified since 2000 R.V.R Elettronica S.p.A. Via del Fonditore, 2 / 2c Zona Industriale Roveri · 40138 Bologna · Italy Phone: +39 051 6010506 · Fax: +39 051 6011104 e-mail: info@rvr.it ·web: http://www.rvr.it The RVR Logo, and others referenced RVR products and services are trademarks of RVR Elettronica S.p.A. in Italy, other countries or both. RVR ® 1998 all rights reserved. All other trademarks, trade names or logos used are property of their respective owners.
