- Page 1 TX500 User Manual Manufactured by Italy...
- Page 2 File name: capitoli_en.p65 Version: Date: 02/12/2002 Revision History Version Date Reason Editor 02/12/2002 New version D. Canazza TX500 - User Manual Versione 1.0 © Copyright 2002 R.V.R. Elettronica SpA Via del Fonditore 2/2c - 40138 - Bologna (Italia) Telefono: +39 051 6010506 Fax: +39 051 6011104 Email:...
- Page 3 Notification of intended purpose and limitations of product use This product is a FM transmitter intended for FM audio broadcasting. It utilises operating frequencies not harmonised in the intended countries of use. The user must obtain a license before using the product in intended country of use.
- Page 4 This page intentionally left blank...
- Page 5 This manual describes the TX500SS, a radio transmitter for frequency modulation audio broadcasting. The TX500SS is a modular device, built up of components assembled in a 19” rack, complete with electrical and RF wiring. This manual shall be read together with the manuals of the different components, that are attached herewith.
- Page 6 TX500 2.2 TX500SSRD/RDS This version is the most complete version of the TX500SS. With respect to the “essential” components, it features: Double exciters (2 PTX30LCD/s); • • Double RDS encoders (2 TRDS4001); Automatic change-over unit (SCM1+1 LCD); • Telemetry unit (TLC300).
- Page 7 TX500 2.3 TX500SSRD This version of the transmitter gives to the customer the benefit of redundant exciters and remote control. It is composed of: Double exciters (2 PTX30LCD/s); • • Automatic change-over (SCM1+1 LCD); Telemetry unit (TLC300); • Amplifier (PJ500M LCD). •...
- Page 8 TX500 2.4 TX500SSD/RDS This version of the transmitter gives redundant exciters and RDS coders. It consists of: Double exciters (2 PTX30LCD/s); • Double RDS encoders (2 TRDS4001); • Automatic change-over (SCM1+1 LCD); • Amplifier (PJ500M LCD). • 4 / 8 Rev.
- Page 9 TX500 2.5 TX500SSD This version is composed of: Double exciters (2 PTX30LCD/s); • Automatic change-over (SCM1+1 LCD); • • Amplifier (PJ500M LCD). User Manual Rev. 1.0 - 02/12/02 5 / 8...
- Page 10 TX500 2.6 TX500SSR/RDS This version of the transmitter is tele-controllable and includes the RDS coder. It is composed of: Exciter (PTX30LCD/s); • RDS encoder (TRDS4001); • Telemetry unit (TLC300); • Amplifier (PJ500M LCD). • 6 / 8 Rev. 1.0 - 02/12/02 User Manual...
- Page 11 TX500 2.7 TX500SSR This is the simplest telemetrized version of the TX500SS. This version is composed of: Exciter (PTX30LCD/s); • Telemetry unit (TLC300); • Amplifier (PJ500M LCD). • User Manual Rev. 1.0 - 02/12/02 7 / 8...
- Page 12 TX500 2.8 TX500SS/V2 This version is composed of: Exciter (PTX30LCD/s); • Amplifier (PJ500M LCD). • 8 / 8 Rev. 1.0 - 02/12/02 User Manual...
