Introduction
The contact contains a transmitter and a magnet, which can be
mounted on a door, window, or any object that can be opened
or closed. When the transmitter and magnet are separated, the
contact will send a signal to the control panel and the control panel
will trigger an alarm. The tamper switch ensures that sabotage
attempting to disassemble the contact will trigger an alarm.
Overview
LED
Indicator
Transmitter
Front side
Tamper Switch
Magnet
Back side
LED Indication
Flash once:
Intruder is detected.
Flash once per 3 seconds after triggered:
the battery as soon as possible.
PCB Layout
Tamper Switch
Note:
When tamper switch is pressed, system will alarm immediately.
EN
Low battery. Replace
CR2032 Lithium Cell
Battery
