Installation and Service Manual
Under-The Counter 6 Stage
Reverse Osmosis System
With Ultraviolet Sterilization
System Flow Rate
12 Gallons Per Day
24 Gallons Per Day
36 Gallons Per Day
*A voltage code is added to the end of the model number. Example: AAA-126UVU
Industry Leader in RO Expertise and Membrane Applications Since 1983™
2325 Cousteau Ct., Vista, CA 92081, USA • www.appliedmembranes.com
Model Number
AAA-126UV*
AAA-246UV*
AAA-366UV*
System Flow Rate
50 Gallons Per Day
75 Gallons Per Day
100 Gallons Per Day
Model Number
AAA-506UV*
AAA-756UV*
AAA-1006UV*
AAA6-MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Applied Membranes AAA-126UV Series
Summary of Contents for Applied Membranes AAA-126UV Series
- Page 1 Installation and Service Manual Under-The Counter 6 Stage Reverse Osmosis System With Ultraviolet Sterilization System Flow Rate Model Number System Flow Rate Model Number 12 Gallons Per Day AAA-126UV* 50 Gallons Per Day AAA-506UV* 24 Gallons Per Day AAA-246UV* 75 Gallons Per Day AAA-756UV* 36 Gallons Per Day AAA-366UV*...
-
Page 2: Conditions For Operation
Introduction Please read this entire service guide prior to beginning installation. The Applied Membranes reverse osmosis drinking water system has been designed for quick and simple installation and maintenance. By carefully reading this instruction manual and following the operational guidelines you will ensure a successful installation and reliable operation. Routine maintenance is essential to the longevity and performance of the system. - Page 3 Product Water – Final From the ultraviolet system outlet to the faucet. Yellow Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 3...
-
Page 4: Preparing For Installation
(additional tubing will be needed). The system will produce a faster flow at the faucet with the shortest tubing run from tank to faucet. Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Page 4 Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. -
Page 5: System Mounting
With the collet held in this position the tube can be removed. The fitting can then be re-used. Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 5... - Page 6 Installation and Service Manual – Under-the-Counter 6 Stage Reverse Osmosis System with UV Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Page 6 Copyright © 2008 Applied Membranes, Inc. All Rights Reserved.
-
Page 7: Starting Your Installation
Wrap the threads on the ball valve with Teflon tape, approximately 3 wraps. Screw the ball valve into the slip joint adapter. Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 7... -
Page 8: Drain Saddle Installation
Variable speed drill w/ ⅛” and ¼" drill bits o Phillips Screwdriver Drain Saddle Assembly Black Tubing Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Page 8 Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. - Page 9 NOTE: Some states require the use of an air gap faucet. Check your local plumbing code to assure compliance. Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 9...
- Page 10 Tank Valve in OPEN Position Tank Valve in CLOSED Position Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Page 10 Copyright © 2008 Applied Membranes, Inc. All Rights Reserved.
-
Page 11: Faucet Installation
“Relton” type device. Follow the directions that accompany the tool carefully. Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 11... -
Page 12: Additional Point Of Use Connection (Optional)
Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Page 12 Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. -
Page 13: Turning The System On For The First Time
This is normal and safe to drink. The air bubbles will disappear within a few days of regular use. Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 13... -
Page 14: System Maintenance
Follow the normal Start-up Procedures. (Drain the first tank of water after changing the filters before drinking.) Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Page 14 Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. - Page 15 (Figure 1). Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 15...
- Page 16 The post filter should be changed after sanitizing the system. Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Page 16 Copyright © 2008 Applied Membranes, Inc. All Rights Reserved.
-
Page 17: Replacement Parts
Replacement Ballast (power Replacement Quartz Sleeve supply) for UV for UV Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 17... - Page 18 For Membrane Housing H-J2025PW H-B2044W (Membrane Housing) Membrane Filter Bracket Housing Clip Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Page 18 Copyright © 2008 Applied Membranes, Inc. All Rights Reserved.
-
Page 19: Troubleshooting Chart
Water should lose the milky look within a few days of normal usage. Systems and Components Membranes, Filters, Chemicals 2325 Cousteau Ct., Vista, CA 92081 USA • www.appliedmembranes.com • E-mail: sales@appliedmembranes.com Copyright © 2008 Applied Membranes, Inc. All Rights Reserved. Page 19... -
Page 20: Product Warranty
Product Warranty SELLER hereby warrants to CUSTOMER that the goods herein described will be free from any liens or encumbrances, that good title to said goods will be conveyed to CUSTOMER by sale of same. SELLER warrants materials of its own manufacture against defects in material and workmanship under normal conditions of usage and service as specified in this manual for one year from whichever of the following events occur first: ...
