DECK MECHANISM DISASSEMBLY
GEAR UP/DOWN
FRAME UP/DOWN
3. Frame Assembly Up/Down(Fig. 4-3)
1) Release Screw(S5).
3-1. PCB Assembly Junction
1)Unconnect the 5 Connectors(C5), (C6).
2)Release 2 Screws(S6).
3-2. Base Assembly Sled Damper
Note
• Put the Base Assembly Main on original position(Top side)
All manuals and user guides at all-guides.com
GEAR MIDDLE
GEAR ASSEMBLY RACK
RUBBER DAMPER
(S8)
(S7)
PICK UP
ASSEMBLY
GENERAL
(C7)
GAER ASSEMBLY RACK
GEAR MIDDLE
GEAR ASSEMBLY FEED
(A)
(B)
PCB ASSEMBLY JUNCTION
Fig. 4-3
(L3)
GEAR ASSEMBLY FEED
(S7)
RUBBER REAR
RUBBER REAR
(S7)
BASE PU(OUTSERT)
(S7)
RUBBER DAMPER
PICK UP ASSEMBLY GENERAL
MOTOR ASSEMBLY SPINDLE
(S5)
FRAME UP/DOWN
PCB ASSEMBLY JUNCTION
(S6)
(S6)
(C6)
BASE MAIN
1) Release 4 Screws(S7).
2) Disconnect the Connector(C7).
3-2-1. Gear Assembly Feed
1) Look the Locking Tab(L3) in direction of arrow.
3-2-2. Gear Assembly Middle
3-2-3. Gear Assembly Rack
1) Release the Screw(S8).
3-3. Rubber Damper
3-4. Frame Up/Down
2-4
(C5)
