REMARK
This service manual corresponds to service modification code number "MZ01" and later. When exchanging MAIN
PCB on the product of the service modification code "MZ00", it is necessary to also exchange the following parts on
the I/O PCB simultaneously.
(The service modification code is mentioned in the number label on the rear panel. Ex.MZ01xxxxxxxxxx)
Two kinds of MPEG ICs (IC501) exist in this model. Since the conventional IC (Pantera-2) became a production stop,
this was generated. Since power supply voltage is changed, new IC (Pantera-2 Plus) has change in a power supply
part. In the case of repair, please fix after checking the version of IC.

1. TECHNICAL SPECIFICATIONS

DVD VIDEO PLAYER
Power supply
Power consumtion
Mass
External dimensions
Signal system
Laser
Frequency range (audio)
Signal-to-noise ratio (audio)
Audio dynamic range (audio)
Harmonic distortion (audio)
Wow and flutter
Operations
OUTPUTS
Video outputs
S-video outputs
Component video output
Audio output (Optical)
(Coaxial)
Audio output (analog audio)
*Designs and specifications are subject to change without notice.
All manuals and user guides at all-guides.com
Service modification code
MZ00
Location <Pantera-2>
D116 1N17
D117 1N17
C127 2200uF/6.3V
AC120 V, 60 Hz
16 W
5.7 kg (12.6 lbs)
440 x 118 x 423 (W x H x D)
NTSC
(DVD) Semiconductor laser, wavelength 650 nm
(CD) 780 nm
DVD : fs = 96 kHz 4 Hz - 44 kHz
fs = 48 kHz 4 Hz - 22 kHz
CD: 4 Hz - 20 kHz
More than 105dB (EIAJ)
More than 100dB (EIAJ)
0.003%
Below measurable level (less than +0.001%(W.PEAK)) (EIAJ)
Temperature : 5˚C(41˚F) to 35˚C(95˚F),
Operation status : Horizontal
1.0V(p-p), 75Ω, negative sync., RCA jack x 1
(Y)1.0V(p-p), 75Ω, negative sync., Mini DIN 4-pin x 1
(C)0.286V(p-p), 75Ω
(Y)1.0V(p-p), 75Ω ,negative sync., RCA jack x 1
(Cb)/(Cr) 0.7V(p-p), 75Ω
Optical Connector x 1
0.5V(p-p), 75Ω, RCA jack x 1
2.0Vrms (1kHz, 0dB), 330Ω Ω , RCA jack (L, R) x 2
MZ01
<Pantera-2 Plus>
Tin Wire
Tin Wire
220uF/6.3V
