Summary of Contents for Lang GCCO-C
- Page 1 Installation Operation Maintenance Model: GCCO-C Lang Manufacturing Company 10 Sunnen Drive St. Louis, MO 63143 Part Number 60800-13 Rev. C Phone: 314-687-6315 Fax: 314-781-2714 September 1, 2011...
- Page 2 Installation, startup and adjustments of this appliance should be accomplished by personnel qualified to install gas equipment. Retain this manual for future reference. Lang Manufacturing Company 10 Sunnen Drive St. Louis, MO 63143 Part Number 60800-13 Rev. C...
-
Page 3: Table Of Contents
MOTOR REMOVAL ........................9 SAFETY THERMOSTAT REMOVAL ..................9 PARTS ..............................11 CONTROL PANEL LAYOUT....................11 PARTS LIST ..........................12 WIRING DIAGRAM ........................13 WARRANTY .............................14 Lang Manufacturing Company 10 Sunnen Drive St. Louis, MO 63143 Part Number 60800-13 Rev. C Phone: 314-678-6315 Fax: 314-781-2714 September 1, 2011... -
Page 4: Installation
Do not etc.) on the right side. return damaged merchandise Lang Manufacturing Company. File your claim Keep the appliance area free and clear of with the carrier. combustible material and do not obstruct the flow of combustion or ventilation air. -
Page 5: Stacking The Ovens
1/2 PSGI (3.45 AS WITH ANY GAS APPLIANCE INSTALLED ON CASTERS, kPA) and the appliance must be isolated from ANY LANG GAS GRIDDLE, GAS CLAMSHELL®, OR GAS CONVECTION OVEN ON CASTERS MUST BE INSTALLED the gas supply piping system by closing its... -
Page 6: Initial Start Up
THIS APPLIANCE IS EQUIPPED WITH A 3- INITIAL START UP PRONG (GROUNDING) PLUG FOR YOUR PROTECTION AGAINST SHOCK HAZARD WARNING AND MUST BE PLUGGED DIRECTLY PRIOR TO STARTING THIS APPLIANCE, INTO PROPERLY GROUNDED THE MAIN GAS VALVE MUST BE OFF PRONG RECEPTACLE. -
Page 7: Operation
OPERATION GENERAL Convection ovens constantly circulate air over looking through the oven door windows. Do not and around the product. This strips away the open the oven doors during the bake as this will thin layer of moisture and cool air from the change the baking characteristics of the oven and product allowing heat energy to penetrate more make it difficult to determine a final program. -
Page 8: Status Screen
MANUAL BACK UP This a toggle switch located below the control panel, behind the louvered access door. In the event of a computer failure, this switch takes control of the oven away from the computer and directs the temperature control to a mechanical thermostat located next to the switch. -
Page 9: Manual Back-Up
To cook, place the product into the oven cavity MANUAL BACK-UP and shut the oven doors. Press the Product The button labeled MAN PROG is the Manual Button which is labeled for that product. Programming button. The Status Screen will then display "SHELF". The MAN PROG button allows the operator to Press the Shelf Button(s) that match the shelf create a simple program for one time products. -
Page 10: Temperature Recall Button
Screen will display "EntEr" and the control is time any products. ready to accept a new operator command. If service is required on the Lang computer, refer The READ/CLEAR Button can also be used to to the Lang Authorized Service Agency "read"... -
Page 11: Maintenance
MAINTENANCE CLEANING DOOR CHAIN ADJUSTMENT Always start with a cold oven. WARNING DISCONNECT THE OVEN FROM POWER The porcelain or stainless interiors can easily be cleaned using most domestic or commercial oven The door chain assembly is located directly cleaners. beneath the oven doors, inside the lower trim piece. -
Page 12: Service
SERVICE WARNING SERVICE ON THIS, OR ANY OTHER LANG APPLIANCE, MUST BE PERFORMED BY QUALIFIED PERSONNEL ONLY. CONSULT YOUR AUTHORIZED SERVICE STATION DIRECTORY OR CALL THE FACTORY AT 206-881-7569 FOR THE SERVICE STATION NEAREST YOU. CALIBRATION The Lang Computerized Control is electronically Remove the eight 1/4 - 20 bolts from the motor calibrated. - Page 13 Remove the four thumb screws located at the The safety thermostat is bolted to the back side corners of the fan baffle. Remove the fan baffle of the motor plate next to the blower motor. from the oven. Remove the screws holding the safety thermostat Remove the eight 1/4 - 20 bolts from the motor bracket to the motor plate.
-
Page 14: Parts
PARTS CONTROL PANEL LAYOUT ITEM DESCRIPTION ITEM DESCRIPTION Touch Control Panel Manual Back-up Switch G - Temperature Sensor Motor Contactor Connection H - Output to Contactors Manual Back-up Relay Microprocessor Terminal Block A - 12 Volt Supply 24 Volt Transformer B - Ribbon Connections 12 Volt Transformer Beeper Board... -
Page 15: Parts List
PARTS LIST JANUARY 19, 2013 GCCO-C Bulb Socket, Oven Light 31602-04 Bulb, Oven Lamp 31603-09 Burner, Main Flame GCCO-257-W1 Burner, Pilot Flame 80201-14 Circuit Board Assembly, Buzzer 40102-10 Circuit Board Assembly (Replaces 40102-08, 40102-20, 40102-11, & 40102-44) 40102-59 Contactor, 2 Pole... -
Page 16: Wiring Diagram
GCCO-C WIRING DIAGRAM... -
Page 17: Warranty
(12) twelve consecutive months, with the following conditions and subject to the following limitations. Purchasers* I. This parts and labor warranty is limited to Lang Equipment sold to the (Domestic U.S., Hawaii, & original commercial purchaser/users (but not original equipment Canadian Sales only.)
