Sindoh A1 Series
User Manual
This user manual contains the product warranty inside.
●
Please read this user manual before using this product
●
and keep the manual nearby.
3dprinter.sindoh.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sindoh A1 Series

Summary of Contents for Sindoh A1 Series

  • Page 1 Sindoh A1 Series User Manual This user manual contains the product warranty inside. ● Please read this user manual before using this product ● and keep the manual nearby. 3dprinter.sindoh.com...
  • Page 2 Safety Instructions Please make sure to follow the instructions below when using the machine. Warning: Failure to observe the instructions may lead to death or serious injury. Do not plug the power cord into extensions. Plug the cord directly into the wall socket. If the power cable or plug is worn or damaged, pull out the power plug.
  • Page 3 Before using the machine Thank you for purchasing our product. This user manual contains detailed information about correct use of machine and easy maintenance to maintain the optimal state, and to contribute to the rationalization of office work of your company Please carefully read the user manual before using the machine and keep close at hand.

  • Page 4: Table Of Contents

    Contents Before using the machine Preface ------------------------------------------------------------------------------------------------------------------ 1 Conventions ---------------------------------------------------------------------------------------------------------- 2 Symblos ----------------------------------------------------------------------------------------------------------------- 2 Safety Information -------------------------------------------------------------------------------------------------- 3 Precautions ----------------------------------------------------------------------------------------------------------- 7 Installation -------------------------------------------------------------------------------------------------------------- 7 Leveling Machine ----------------------------------------------------------------------------------------------------- 8 Moving the Machine ------------------------------------------------------------------------------------------------- 9 Handling Consumables ------------------------------------------------------------------------------------------- 10 SLA Resin (Photo Curable Resin) --------------------------------------------------------------------------------11 Isopropyl Alcohol, IPA ------------------------------------------------------------------------------------------------12 Instructions for Use ------------------------------------------------------------------------------------------ 13 Ventilation -------------------------------------------------------------------------------------------------------------15...
  • Page 5 Chapter 2. UI Menu Function UI Menu Function Descriptions ------------------------------------------------------------------------------ 2-2 Home ------------------------------------------------------------------------------------------------------------------- 2-3 Cartridge --------------------------------------------------------------------------------------------------------------- 2-4 Change ----------------------------------------------------------------------------------------------------------------- 2-4 Setting ---------------------------------------------------------------------------------------------------------------- 2-10 XY Scale ------------------------------------------------------------------------------------------------------------- 2-11 Z Offset -------------------------------------------------------------------------------------------------------------- 2-14 Chamber Heating ------------------------------------------------------------------------------------------------- 2-16 Resin Auto Supply ------------------------------------------------------------------------------------------------- 2-18 Platform Leveling -------------------------------------------------------------------------------------------------- 2-20 Auto Platform Leveling ------------------------------------------------------------------------------------------- 2-25 Cloud Monitoring -------------------------------------------------------------------------------------------------- 2-27...
  • Page 6 Detaching Printed Output ----------------------------------------------------------------------------------------- 4-2 Finishing the Printed Output -------------------------------------------------------------------------------------- 4-5 Preparing the Next Print ------------------------------------------------------------------------------------------- 4-7 Enhancing Print Quality -------------------------------------------------------------------------------------------- 4-8 When Printer Can’t be Turned ON ---------------------------------------------------------------------------- 4-9 If problems Persist ---------------------------------------------------------------------------------------------- 4-10 Chapter 5. Maintenance Machine Cleaning -------------------------------------------------------------------------------------------------- 5-2 Printer Interior Cleaning ------------------------------------------------------------------------------------------- 5-2 Periodical Inspection ----------------------------------------------------------------------------------------------- 5-2 Oil/Grease Inspection ---------------------------------------------------------------------------------------------- 5-2...
  • Page 7 Actions in Case of a Printing Failure ------------------------------------------------------------------------- 5-19 Removing Failed Print ------------------------------------------------------------------------------------------- 5-19 Cleaning the Resin Tank and Platform ----------------------------------------------------------------------- 5-19 If Noise is Generated from the Lead Screw of Platform ------------------------------------------------- 5-20 Replacing consumables and important components ----------------------------------------------- 5-21 Replacing the Resin Cartridge --------------------------------------------------------------------------------- 5-21 Replacing the Platform ------------------------------------------------------------------------------------------- 5-25 Replacing the Resin Tank --------------------------------------------------------------------------------------- 5-27...

  • Page 9: Before Using The Machine

    - The content of the user manual is subject to be changed without any prior notifications. - Sindoh shall not be liable for consequential, special, indirect damages or losses caused by the handling or operating of the machine or by the user’s negligence.

  • Page 10: Conventions

    Before Using the Machine Conventions Symbols The following symbols are used in this manual and their definitions are as follow. Warning - Indicates important safety notes. Ignoring these notes could result in serious injury or death. Be sure to read these notes carefully for your safe operations of the machine. Caution - Indicates important safety notes.

  • Page 11: Safety Information

    Before Using the Machine Safety Information Please plug the power cord into a properly grounded outlet with is near and quickly accessible from the machine. Do not use or place the machine in wet or humid environment. This machine is very sophisticated 3D printing machine, so please keep in mind the following safety information for safe use.
  • Page 12 Before Using the Machine Bodily Injury and Pain Hazard Caution - Dropping the platform and resin tank may cause body pain. - To avoid personal pain or damages to the device, you need to follow the instructions below. Be careful not to drop the platform and resin tank when attaching / detaching from the machine. Because it is made of heavy metal, dropping it may cause the machine damage or bodily injury.
  • Page 13 Before Using the Machine Finishing Tools Caution - Some of finishing tools being used to handle printed outputs such as scrappers, knives, tweezers, nippers, etc) have sharp edges. Handle them with caution because it may cause injury or hazardous situations in sudden. Internal Laser Radiation Caution - Typical Wavelength : 405 nm...
  • Page 14 Before Using the Machine Warning Laser Exposure - This mark is only about Laser Scanning Unit (LSU) placed inside of the product. When orange cover opened and interlocks defeated, it may cause exposure to Class 3B laser during the operation. To avoid exposure to Class 3B laser, close the cover or turn off the power.

  • Page 15: Precautions

    Before Using the Machine Precautions Installation Injury Hazard Caution - Install the machine in a well ventilated area. - You can smell odor during the operation. It should not be harmful, but if the area of the place where the machine is located is not well ventilated, make sure to ventilate the area appropriately periodically.

  • Page 16: Leveling Machine

    Before Using the Machine Leveling Machine Install the printer on a flat surface. If the printer is not leveled, irregular noise and vibration may occur, resulting in splash resin or printing failure. This product has four screws for the purpose of leveling. The printer can be leveled by turning them according to the indication of the built-in level.

  • Page 17: Moving The Machine

    Before Using the Machine Moving the Machine Turn off the power by pressing power button. Unplug the power cord and all cables connected to the machine. Make sure if resin tank is removed. Otherwise, resin in the resin tank may overflow. Lift the machine using handles located in the left/right side of the machine.

  • Page 18: Handling Consumables

    Before Using the Machine Handling Consumables Warning - Isopropyl alcohol can be flammable, even explosive.. Any containers holding isopropyl alcohol should be kept closed or covered when not in use because it is highly volatile. it should be kept away from heat, fire or sparks. Caution - Keep consumables out of reach of children, pet, etc.

  • Page 19: Sla Resin (Photo Curable Resin)

    Before Using the Machine SLA Resin (Photo Curable Resin) Please be cautious of the followings when handling Resin. - Wear nitril gloves all the time while handling the resin. - Resins being used for this machine should not be used for the food, drink and medical purposes. - Do not eat or inhale resin in any forms.

  • Page 20: Isopropyl Alcohol, Ipa

    Before Using the Machine Isopropyl Alcohol, IPA Please be cautious on the followings when handling the IPA. - Please make sure to wear nitril gloves all the time while using the IPA - Carefully follow the safety instructions provided with the isopropyl alcohol you purchase. You should consult the chemical manufacturer or supplier for more in depth safety information.

  • Page 21: Instructions For Use

    Before Using the Machine Instructions for Use Caution - The following items are for user-handling components made of metal, so they are very heavy. Resin tank Platform - If any of them falls while installing/removing or moving it, the machine may be damaged, or if it falls on a person, it may cause an injury.
  • Page 22 Before Using the Machine Important - If any of the following optical components positioned in the path of a laser beam reaching the resin is damaged or dirty, it may cause reduced quality or failed printing, so make sure to clean it while preparing the next one after completing the previous printing.

  • Page 23: Ventilation

    Before Using the Machine Ventilation Caution - Use the machine in a place with good ventilation. Do not block vents. Inappropriate cooling may lead to high temperatures inside the machine. - In general, a new machine may produce small amount of gaseous components, so ensure good ventilation when the machine is used for the first time.

  • Page 24: Notices

    Before Using the Machine Notices Noise Emission Level ❖ The following noise level is measured in accordance of ISO 7779 and reported to meet ISO 9296. Some modes may not be available in products you purchased. Average Sound Pressure at 1 Meter Away (dBA) Printing 45dBA Standby...
  • Page 25 Before Using the Machine This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one m ore of the following measures :...
  • Page 26 Before Using the Machine Deactivated Mode ❖ The machine consumes power even in the deactivated mode. Unplug the power cord to completely stop the power consumption. Total Energy Usage ❖ It would be useful to calculate the Total energy usage of the machine. Since the electricity bill is charged in Watt unit, you have to multiply time spent in each mode by power consumption in order to calculate the energy use.

  • Page 27: Disposal Of Used Battery

    Before Using the Machine Disposal of Used Battery Control board uses a Lithium battery. Please discard used batteries following the environmentally friendly procedure stated on the manufacturer guidelines. To replace batteries, please contact a qualified service engineer.

  • Page 28: 10. Wifi Module Disclaimer

    - Do not expose this product to water, humidity or liquid. - Do not expose this product to direct light, hot temperature or fire. Caution - If the machine has been modified by unauthorized personnel, Sindoh is not liable for the machine trouble or failure. Caution - To prevent RF signals that exceed FCC RF exposure limits from being exposed to human, this module has been mounted in a place that minimizes human access.
  • Page 29 Before Using the Machine Important IEEE 802.11b : 2412MHz ~ 2462MHz IEEE 802.11g : 2412MHz ~ 2462MHz Frequency IEEE 802.11n(20MHz) : 2412MHz ~ 2462MHz IEEE 802.11n(40MHz) : 2412MHz ~ 2452MHz IEEE 802.11b : 10mW(10dbm)/MHz IEEE 802.11g : 10mW(10dbm)/MHz Antenna Power Density IEEE 802.11n(20MHz) : 10mW(10dbm)/MHz IEEE 802.11n(40MHz) : 10mW(10dbm)/MHz IEEE 802.11b : 11...

  • Page 30: 11. Usb Flash Drive Disclaimer

    - Please use the enclosed USB flash drive. - The enclosed USB flash drive is in FAT32 format. The A1 Series 3D printer does not support USB flash drives in NTFS format. - The warranty will not be valid if a 3rd party USB drive is used.
  • Page 31 : (1) this device may not cause interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RESPONSIBLE PARTY Name : Sindoh America, Ltd. Address : 6047 Tyvola Glen Circle, Suite #115, Charlotte, NC 28217 Phone No. : 1-704-414-6690...

  • Page 33: Chapter 1. Preparation For Machine Operation

    Sindoh A1 Series USER MANUAL Preparation for Machine Operation...

  • Page 34: Specifications

    *.stl, *.ply, *.obj Operating System Windows 10(64bit) or Above Memory (Recommended) Sindoh A Desktop Slicer – At least 8GB (16GB is recommended) Exocad, NetFabb – At least 16GB (64GB is recommended) Note - Graphic card must support OpenGL 4.0 or higher.

  • Page 35: Components

    Preparation for Machine Operation Components Basic Components Please check all basic components in the packaging box. Caution - Please keep the box and packaging material; they are needed for product exchange or repair service. 3D Printer Power Cord USB Cable T-Handle Hexagon USB Memory Quick Installation Guide...
  • Page 36 Preparation for Machine Operation Finisher Kit (Optional) Nipper Sprayer Nitril Gloves (2pairs) Washing Tub Cleaning Tray Filters (3pcs) Metal Scrapper Rubber Scrapper Platform Cleaning Brush Funnel Hammer Empty Bottle Kit List Warning - The blade side of metal scraper is very sharp. Please do not use it for other than removing the sculpture. In particular, do not touch or contact the blade side.

  • Page 37: Resin Cartridge (Optional)

    Preparation for Machine Operation Resin Cartridge Resin Cartridge Resin Supply Cap Nozzle Tube Replacing Guide...

  • Page 38: Understanding The Parts

    Preparation for Machine Operation Understanding the parts [ Front ] [ Rear ] Part Name Description Press this button shortly to turn on printer. Power Button Press and hold for more than 2 seconds to turn off the printer. Power Button Lamp ON Power is ON Indicator...
  • Page 39 Preparation for Machine Operation [ Interior ] Part Name Description Resin Tank Working space where resin is filled and printing is processed. Resin Tank Locking Levers Levers that lock and unlock the resin tank. Camera Let users monitor how the printing is going on. ※...
  • Page 40 Preparation for Machine Operation [ Resin Cartridge ] Part Name Description Resin Cartridge Bottle being filled with resin. Resin Cartridge Handle Let users hold the cartridge in case of handling it. Nozzle Discharges resin through it from the cartridge. Nozzle Tube Makes resin flow directly into resin tank preventing splashing Seals cartridge Air Pump Tube...

  • Page 41: Installation (Incl. Connection, Cartridge Setup And S/W Installation)

    Preparation for Machine Operation Installation (Incl. Connection, Cartridge Setup and S/W Installation) Caution - Please remove all packaging materials from inside and outside of the device. Furthermore, open the orange cover and remove all protective materials and accessories from interior. Device Connection Connect the power cable to the power socket on the rear side of the device, and connect the power cable to the power outlet.
  • Page 42 Preparation for Machine Operation Please set the time zone of the machine according to instructions shown on UI. Set time and date of the machine according to instructions shown on UI. After booting up is completed, check if home screen is displayed on UI. Open orange cover and install resin tank and platform.
  • Page 43 Preparation for Machine Operation Release two platform locking knobs from machine, attach the platform as shown below, tighten the locking knobs firmly, and attach the platform cover to the platform. Connection to PC ① Direct Connection : Connects one end of the enclosed USB cable to the back of the device and the other end to the PC.

  • Page 44: S/W Installation

    Preparation for Machine Operation S/W Installation Start the S/W installation by clicking on “3DWOX Desktop.exe” file in the enclosed USB flash drive. Install the additional files required by the software list. When installation of the additional files is done, a pop-up window shows up as the picture below. Press [Next] button to start the installation of A Desktop Program.
  • Page 45 Preparation for Machine Operation Choose the destination location of the files and press [Next] to proceed. All configurations get saved and the installation starts. After all installation is complete, you can see that “A Desktop” icon created on the desktop of your computer.

  • Page 46: Resin Cartridge Installation

    Preparation for Machine Operation Resin Cartridge Installation Remove the sealing cap and sealing paper of the resin cartridge, replace with resin supply cap, and nozzle tube. Assemble air pump tube after installing the resin cartridge into the machine. Press [Cartridge] to check if information of the resin cartridge is correct.
  • Page 47 Sindoh A1 Series USER MANUAL UI Menu Function...

  • Page 48: Ui Menu Function Descriptions

    UI Menu Function UI Menu Function Descriptions ※ Please refer to ‘Chapter 3. Printing’ for Print menu. Cartridge Change Cartridge Setting XY Scale Z Offset Chamber Heating Auto Resin Supply Platform Leveling Auto Platform Leveling Cloud Monitoring Level Printer Laser Power of 1st Layer Network Test Print S/W Update...

  • Page 49: Home

    UI Menu Function Home The first screen that user can see when turning ON the machine. Part Name Description Home Button Go to Home screen. ※ When it’s not Home screen, it changes to the Back( ) button. Slide Menu Bar Open up Slide Menu.

  • Page 50: Cartridge

    UI Menu Function Cartridge Change This function is used to replace the resin cartridge in case that the current resin cartridge is empty or user wants to switch to the different type of resin. Press [Cartridge] from the Home screen. It displays the screen indicating the status of the Resin Cartridge currently loaded.
  • Page 51 UI Menu Function To install a new cartridge, remove the used cartridge first. Open the orange cover, and then remove the resin cartridge. Nozzle Tube Remove the air pump tube from the resin cartridge and fix it to the saddle for a moment. Air Pump Tube Saddle...
  • Page 52 UI Menu Function Lift up the resin cartridge with its handle, and then take it out. Caution - If any resin remains in the removed cartridge, replace the sealing cap to prevent leakage and curing, and then store it. If the cap is not replaced, the resin may leak through the opening on top of the cap or be cured.
  • Page 53 UI Menu Function Photocurable resin consists of different chemicals. Make sure to shake it enough before replacing it with a new one so that the resin is well mixed inside the cartridge. Caution - Make sure to close the sealing cap to prevent leakage before shaking it. Sealing cap Remove the sealing cap and sealing bracket, and then replace it with the enclosed resin supply cap.
  • Page 54 UI Menu Function Insert a nozzle tube into the nozzle of the new resin cartridge. Nozzle Tube Insert a new resin cartridge into the housing of the machine. Insert the tube connected to the air pump from the top of the top projection of the cap. Air Pump Tube...
  • Page 55 UI Menu Function Important - If the air pump tube is not properly connected with the resin supply cap, the resin may not be properly supplied. Make sure that the tube is fully inserted into the resin supply cap. Tube Press [OK] when the installation of the new cartridge is complete.

  • Page 56: Setting

    UI Menu Function Setting Setting XY Scale Z Offset Chamber Heating Auto Resin Supply Platform Leveling Auto Platform Leveling Cloud Monitoring Level Printer Laser Power of 1st Layer Network Test Print S/W Update General Setting Language Power Saving Beep Unit Voice Guide Time Setting Time Zone...

  • Page 57: Xy Scale

    UI Menu Function XY Scale If the actual printing size differs from the designed model size, this function allows users to adjust the thickness error range and the horizontal(X)/ vertical(Y) scale of the print output. If you are not familiar with the machine, you can use the semi-auto calibration (adjustment) function, which suggests corrected (corrected / adjusted) values after measuring the print output size.
  • Page 58 UI Menu Function XY scale and XY thickness error range reconfiguring screen appears. Adjust each value with the slide bar or by pressing [+] or [-] . XY scale can be adjusted by 0.01% from 95.0% to 105.0%. XY thickness error can be adjusted by 0.01mm from -0.5 mm to +0.5 mm. Then, press [Save] to save the setting values.
  • Page 59 With the print output attached to the platform, measure X1, X2, Y1, and Y2 as shown in the picture. Reference - [Print] button only works with a Sindoh proprietary resin. Adjust each measured value with the slide bar on the screen or by pressing [+] or [-].

  • Page 60: Z Offset

    UI Menu Function Z Offset This function allows users to adjust the distance between platform and resin tank to change the thickness of the first layer of raft. Change Z Offset value to [-] direction in case of printing failure caused by a drop of raft. On the other hand, change Z offset value to [+] value to increase raft thickness in case that raft is thicker than specified.
  • Page 61 UI Menu Function Z Offset screen shows up. Change a value by pressing [+] or [-] until it reaches the target number. Adjustable range is -0.05mm~+0.5mm in 0.05mm unit. Press [Save] when finished.

  • Page 62: Chamber Heating

    A Desktop’s user manual. Important - In the case of using Sindoh proprietary resin, you should keep the chamber temperature at the right level using the heater for the best printing quality. We recommend to set ON in this case.
  • Page 63 UI Menu Function Press [Chamber Heating] . It is a notice message notifying that the machine doesn’t guarantee the printing quality in Open Mode. If you agree on the message of pop-up window, press [Done] to continue. Select [On] or [Off] , and press [Save] to finish.

  • Page 64: Resin Auto Supply

    UI Menu Function Resin Auto Supply This function allows user to enable or disable resin auto supply features. Press [Slide Menu Bar] from the Home screen. Press [Setting] from the Menu screen. Press [Auto Resin Supply]...
  • Page 65 UI Menu Function If you agree on the message of pop-up window, press [OK] to continue. Select [On] or [Off] on ‘Enable Auto Resin Supply’ and press [Save] . If select [Off], Resin should be supplied manually. And then, Select [On] or [Off] on ‘Auto-stop every 100㎖ Printing’...

  • Page 66: Platform Leveling

    UI Menu Function If select [Off] or [On] for 'Auto-stop every 100㎖ Printing', a pop-up guide for the function will appear accordingly. Caution - If [Off] of ‘Enable Auto Resin Supply’ and [Off] of ‘Auto-stop every 100㎖ Printing’ are selected, there can be not enough resin for the printing.
  • Page 67 UI Menu Function Press [Setting] from the Menu screen. Press [Platform Leveling] . Remove all resin remaining in resin tank. Refer to “Resin tank of 5.Maintenance” for details of how to remove resin from the resin tank. Please note that leveling wil fail or won’t work precisely if resin still remaining in the resin tank.
  • Page 68 UI Menu Function Platform rises. Click [Next] when the Platform lifting completion message shows up.
  • Page 69 UI Menu Function Loosen six platform locking screws with a T-handle hexagon wrench, and press [Next] . Caution - Do not completely remove the screws from the platform and just loosen them up. If you try to remove the screws, they may drop onto the resin tank, and damage the release film and transparent window.
  • Page 70 UI Menu Function When the platform lowering is complete, fasten back the six platform locking screws using a T-handle hexagon wrench, and press [Next] Lock the platform locking screws in the following order: ① front side → ② left side → ③ right side. ②...
  • Page 71 UI Menu Function Check the gap of the platform and the resin tank using enclosed gap gauge. The gap of all 4 corners as shown in instruction of UI needs to be checked. If gap gauge is inserted into any corners, it would mean platform is not leveled well.

  • Page 72: Auto Platform Leveling

    UI Menu Function Auto Platform Leveling Platform leveling is automatically performed. The auto platform leveling is only applicable to the Z axis, so fine tuning is not available. If the problem persists even after the auto platform leveling is carried out, perform the platform leveling. Press the [Slide Menu Bar] button from the home screen.
  • Page 73 UI Menu Function Remove all resin remaining in the resin tank. Refer to “Resin tank of 5. Maintenance” for details on how to remove resin from the resin tank. If resin is not completely removed from the resin tank, leveling may be done incompletely.

  • Page 74: Cloud Monitoring

    UI Menu Function Cloud Monitoring This function lets users check the state of the machine remotely and send management data through email. Press the [Slide Menu Bar] button from the home screen. Press [Setting] . Swipe up the screen, and then select [Cloud Monitoring] .

  • Page 75: Level Printer

    UI Menu Function Select [Off] or [On] , and then press [Save] to save the settings. Level Printer This function lets users level the printer. Important - Sensor which is used to display the level or the printer should be used within the proper tempearature(20~30 ℃) in order to prevent malfunction.
  • Page 76 UI Menu Function Swipe up the screen, and then select [Level Printer] . The screen shows the leveling state of the printer. The leveling state screen shows the level of the machine with a circular level, which is commonly found in a washing machine. The circular level shows the level state with a bubble. Level the printer so that the orange circle of level is centered.
  • Page 77 UI Menu Function With the enclosed spinner, properly turn the leveling screws located at the bottom of the printer to level the machine. Turn the leveling screws counterclockwise to lower the printer. Turn the leveling screws clockwise to raise the printer.
  • Page 78 UI Menu Function Level it so that the bubble is centered in the level and turns green. Once the bubble turns green, the [Done] button will be activated so that the leveling procedure can be completed. Caution - If the leveling screws are turned clockwise too much, they may be removed from the printer. To prevent this, turn them counterclockwise to lower any higher corner.

  • Page 79: First Raft Laser Power

    UI Menu Function First Raft Laser Power This function is used to change the strength at which the Raft is attached to the platform. The bond strength can be changed by adjusting the laser power of the first raft. Adjusting the laser power in the [+] direction increases the bond strength, and adjusting in the [-] direction decreases the bond strength.
  • Page 80 UI Menu Function Swipe up the screen and select [Laser Power of First Raft] . The screen changing the laser power according to the type of resin will appear. First, select the type of resin to change the laser power. Then, press the [+] or [-] button to set the laser power for the selected resin type. The adjustment can be incremented or decremented by 1 by pressing the active [+] or [-] button.

  • Page 81: Network

    UI Menu Function Network This function let users to set up network configurations of the device. Both wired and wireless LAN can be configured in details. Important - Using both wired and wireless network simultaneously is not recommended for electric devices which can be connected to network.
  • Page 82 UI Menu Function Swipe the screen upward, and press [Network] . Network setup screen shows up. Enable to choose wireless or wired connection according to your network connection provider. Wireless (Wifi) Setting Part Name Description ON/OFF Turn ON or OFF Wifi. Network Name (SSID) Select SSID or enter the name manually if can’t find the one you’re looking for.
  • Page 83 UI Menu Function As pressing [Network] button, list of SSIDs is displayed. Select a SSID you want to connect, and press [Save] to store the setting. If selected SSID requires password, enter it. Select DHCP if the SSID gets IP automatically assigned from the network provider. As press [Connect], it will connect to the internet with the SSID.
  • Page 84 UI Menu Function Press [Static] in the network setting screen if a fixed IP address is required. Press the pen icon [ on the right to enter the IP address manually. Then, press [Connect] to connect to an SSID. Wired LAN Setting For wired LAN, DHCP and fixed IP settings can be selected to connect to the network in the same procedure as the Wi-Fi.

  • Page 85: Test Print

    UI Menu Function Test Print This function allows users to print a sample model already saved in the internal memory of printer. Press [Slide Menu Bar] from the Home screen. Press [Setting] from the Menu screen. Swipe up the screen, and then select [Test Print] .
  • Page 86 UI Menu Function The example files of the machine are listed. Select a file to print. Press the [ ] button to preview the information of the file to print. The information of the selected file is displayed. Press the [ ] button of the file to print to start printing.

  • Page 87: S/W Update

    UI Menu Function S/W Update This function keeps S/W of the machine up to date. It checks the latest firmware through the network connection. Therefore, it won’t be working if the network is not connected. Press [Slide Menu Bar] from the Home screen. Press [Setting] from the Menu screen.
  • Page 88 UI Menu Function Confirm to proceed with the software update. Press [Start Update] . If there is a firmware update, the software update will start. After the update is complete, press the [Done] button to reboot the machine.

  • Page 89: General Setting

    UI Menu Function General Setting This function allows users to change general settings. Press [Slide Menu Bar] from the Home screen. Press [Setting] from the Menu screen. Swipe the screen upward, and press [General Setting] .
  • Page 90 UI Menu Function List of [General Setting] items appears. Select an item to change. Language ❖ The system language of the machine can be chosen. Select a language using [<] and [>]. Power Saving ❖ The time delay before entering the power saving mode can be set. The adjustable range is in the unit of 5 min.
  • Page 91 UI Menu Function Voice Guide ❖ The voice guide and related functions can be changed. On/Off : Turn ON or OFF the voice guide. Volume : Very Low, Low, Medium, High, or Very High can be selected. Speed : Very Slow, Slow, Medium, Fast, or Very Fast can be selected. Reference - Some models do not support the voice guide function.
  • Page 92 UI Menu Function Reference - Some models are not equipped with Camera. The camera frame rate setting function is disabled so that it cannot be selected for those models without Camera. SSD Format ❖ The SSD can be formatted and initialized. Reference - Some models are not equipped with SSDs.

  • Page 93: Saved Files

    UI Menu Function Saved Files Press [Slide Menu Bar] from the Home screen. Press [Saved Files] from the Menu screen.
  • Page 94 UI Menu Function List of files existing in printer’s internal memory is shown. Part Name Description Info Display detailed information of file. Print Start printing a selected file. Edit Manage files such as file deleting/editing, in the internal storage memory of printer. Info ❖...
  • Page 95 UI Menu Function Print ❖ Check if there are remaining printed output on the platform. If there is no problem, press [Next]. Make sure that the resin tank and platform are firmly fixed, and then press [Next]. In manual resin supply mode, check if enough resin is filled in the resin tank using marks.
  • Page 96 UI Menu Function After all the procedures are completed, press [Done] to start printing. Printing gets started.

  • Page 97: Info

    UI Menu Function Info This allows users to check detailed information about the machine, and to set the name of the machine and administrator password. Press [Slide Menu Bar] from the Home screen. Press [Info] from the Menu screen. In Info screen, it is possible to set the name of the device and administrator password, and to see the other detailed information about the device.
  • Page 98 UI Menu Function Statistical information regarding machine usage is shown. For details, press [>] . Total Print Time ❖ Total running time of the device by now is displayed. Number of Printed Model ❖ Total number of print jobs and number of print jobs which are successfully finished are displayed.
  • Page 99 UI Menu Function Cumulative Usage - Resin ❖ Display total cumulative amount of resin and usage volume per each resin type. Most Recent Print File List ❖ Display the list of most recently print files.

  • Page 100: Quick Guide

    UI Menu Function Quick Guide It shows a brief description for each feature. Press [Slide Menu Bar] from the Home screen. Press [Quick Guide] from the Menu screen. Select a function that needs to be explained. If there are several pages, press the [Previous] or [Next] button to move to the previous or next page.

  • Page 101: Programs

    UI Menu Function Programs Press [Slide Menu Bar] from the Home screen. Press [Programs] from the Menu screen. It displays the related sub menu.
  • Page 102 UI Menu Function FAQs ❖ You can access FAQs page of Sindoh homepage using build-in web browser. Application Manager ❖ You can install or uninstall add-In S/W.. To install a new S/W, press [ ] icon, or press [ ] icon to uninstall.

  • Page 103: Cloud

    UI Menu Function Cloud Press [Slide Menu Bar] from the Home screen. Press [Cloud] from the Menu screen.
  • Page 104 UI Menu Function It displays the list of apps available via cloud service. Reference - The list of apps is subject to change without notice. Alexa ❖ You can get a registration code to register Alexa, Google’s AI service. Name of printer can be entered if you press [Alexa]. You can get a registration code if you press [Generate Code] to register an app supporting Alexa service.
  • Page 105 UI Menu Function Reference - Please visit Sindoh’s homepage in order to get detailed information regarding register and activate Sindoh printer to Alexa service. Cloud Monitoring ❖ You can register printers to Cloud Monitoring service being provided by Sindoh, and manage them.

  • Page 107: Printing

    Sindoh A1 Series USER MANUAL Printing...

  • Page 108: Printing From Usb Flash Drive

    Printing Printing User can start printing via USB flash drive, USB cable, or over the network. The following Home screen on the device means it is ready to start print. Printing from USB Flash Drive Connecting USB flash drive into the device In order to print using USB flash drive, insert the flash drive into USB port.
  • Page 109 Printing When the USB flash drive is connected while in the home screen, a list of files in the USB appears. Part Name Description File Name A list of files existing in the USB flash drive. Download Downloading a file to the internal memory of the printer. Preview Preview image of print appears.
  • Page 110 Printing Check if there is remaining printed output on the platform. If there is no problem, press [Next]. Make sure that the resin tank and platform are firmly fixed, and then press [Next]. In manual resin supply mode, check if enough resin is filled in the resin tank using marks.
  • Page 111 Printing After all the procedures are completed, press [Done] to start printing. You can find a pop-up message saying USB should not be removed during file transfer. If USB memory is removed before the pop-up message disappears, printing will be canceled automatically. Icon ( ), which means that USB memory can be removed, will show up, and printing starts.
  • Page 112 Printing Resin filling will start if enough resin is not filled in the resin tank. Air pump supplies resin into the resin tank. When resin reaches the target level, pump stops and printing starts. If chamber temperature is lower than the target, heater will heat up the inside of the chamber. When chamber temperature reaches the target, printing starts.
  • Page 113 Printing Printing Check Printing status can be checked. Press [Printing Check] to move the platform upward so that user can check printing status. Printing resumes after certain amount of time. Change Cartridge This function allows users to replace resin cartridge with new one if needed. Resume It returns to the printing screen and continues to print.

  • Page 114: Printing Via Pc

    Printing Printing Completion If printing is complete, the platform moves up to return to the original position. When the moving of the platform is finished, remove the platform from the machine, and then print. Reference - For removing a print from the platform and preparing for the next printing, refer to “4. Checking Printed Output”...
  • Page 115 Printing Check the printing status through the camera of the printer. Additional features can be used by pressing buttons if necessary. Name Descriptions Lamp Lamp can be turned ON or OFF. Camera Setting Camera frame rate and lamp off time can be set. Remaining Time Remaining print time is shown.

  • Page 116: Cloud Monitoring

    Reference - Cloud monitoring may not be supported depending on models. Sign Up / Login Connect to Cloud Monitoring service(https://cloud3d.sindoh.com) and login. If you don’t have an account, click [Sign Up] to create. Initial Screen If you login Cloud Monitoring service very first time, the initial screen as follows is shown.
  • Page 117 Printing Generation Code Go to [Cloud Monitoring] of UI menu, and press [Generate Code] to get a registration code. Generated code should be used in 600 seconds, otherwise it will be void. New registration code will be generated if you press [Generate Code] again. Reference - For details of entering Cloud Monitoring of UI menu, refer to “Cloud of Chapter.2 UI Menu Function”...
  • Page 118 Printing Adding New Printer In the initial screen, press [Add New Printer] and enter the registration code generated in Cloud Monitoring of UI. If registration code is correctly entered, printer registration will be finished.
  • Page 119 Printing Starting Screen Starting screen of Cloud Monitoring consists of as follows. Name Description Menu Select additional features provided in Cloud Monitoring Printer Delete Button Delete registered printer. Printer Status Names and types are shown. Add New Printer Add new printer Additional Features Press Printer Status and then information of printer detail is shown.
  • Page 120 Name of model file, printer, resin type and usage and print time can be checked. Setting ❖ Email address to which printer’s status is sent can be set, and change email notification setting. If you need to use several email addresses, use semi-colon. (i.e cloudmonitoring1@sindoh.com ; cloudmonitoring2@sindoh.com)

  • Page 121: Changing Resin

    Printing Changing Resin When a resin different from the current one needs to be used, clean up the resin tank and platform to ensure the best print quality and to prevent mixing. Cleaning the platform Clean the platform using a cleaning brush, isopropyl alcohol (IPA), and a paper towel. Remove existing resin as much as possible.

  • Page 123: Checking Printed Output

    Sindoh A1 Series USER MANUAL Checking Printed Output...

  • Page 124: Detaching Printed Output

    Checking Printed Output Checking Printed Output Caution - Wear nitril gloves before getting started. Detaching Printed Output Standby Until Platform Returns To Ready Position After printing is finished, wait until platform completely returns to ready position. Do not open the orange cover before platform stops moving. Platform Platform Locking Knobs Removal When platform stops moving, open the orange cover and remove two platform locking knobs...
  • Page 125 Checking Printed Output Platform Locking Screws Removal If not removing the resin remnant sufficiently, the table, work area or machine exterior may become contaminated by the overflowing resin from the platform when carrying the platform. Hold the platform firmly by using either one of handles, and scrape down remaining resin on platform toward resin tank with the other hand.
  • Page 126 Checking Printed Output Important - As moving the platform away from the machine, be careful not to let the resin splash or spill onto any part of the resin tank. Insert blade of metal scrapper between printed output and platform and detach it by pushing scrapper slowly and carefully.

  • Page 127: Finishing The Printed Output

    Checking Printed Output Finishing the Printed Output Removing supports Remove supports using the nipper enclosed in the finishing kit. Nipper Caution - Use the nipper with care because the blade is sharp. - Be careful not to cut the printed output by mistake. Cleaning the printed output with isopropyl alcohol (IPA) Pour isopropyl alcohol (IPA) in the washing tub enclosed in the finishing kit, and put the printed output in IPA to remove remaining resin.
  • Page 128 Checking Printed Output Remove remaining resin using a brush or toothbrush. Use a sprayer to wipe out the fine gaps or holes in the output with IPA. Drying and post-curing Important - The curing time may vary depending on the printed output’s size and shape. - For quick curing, fill a transparent container with water, and put the printed output in it.

  • Page 129: Preparing The Next Print

    Checking Printed Output Preparing the Next Print Cleaning Platform Remove debris of print and contaminants remaining on the platform using an enclosed metal scraper. Clean each holes and slits of the platform using a platform cleaning brush. Clean remaining resin on the top and bottom of the platform using a paper towel and IPA. Finally, clean all remaining IPA using a dry paper towel.

  • Page 130: Enhancing Print Quality

    Checking Printed Output Enhancing Print Quality Following the guideline for resin use - The print quality is seriously influenced by the condition of resin. Take note of the expiration date as well as the storage and working temperatures marked on the resin cartridge. - Resin in the resin tank needs to be filtered regularly using mesh filter.

  • Page 131: When Printer Can't Be Turned On

    Checking Printed Output When Printer Can’t be Turned ON When the power is ON again, platform moves upward to initial position. As described in “1. Checking Printed Output”, remove aborted print output from the platform, and clean the plat form and resin tank for the next job.

  • Page 132: If Problems Persist

    Checking Printed Output If problems Persist Please refer to “Error Messages and Solutions and Problems and Troubleshooting” from Chapter 5. Maintenance”. Please visit https://3dprinter.sindoh.com or contact your seller for further assistance and help.

  • Page 133: Chapter 5. Maintenance

    Sindoh A1 Series USER MANUAL Maintenance...

  • Page 134: Machine Cleaning

    Maintenance Machine Cleaning Caution - Turn off the power for the machine cleaning. If resin or cleaning tools go into the machine while the power is on, it may cause a machine malfunction. Printer Interior Cleaning During machine use, the resin may fall inside the machine. If the resin goes into sensitive parts such as a conveyor belt or any optical parts, it may cause a malfunction or printing failure.

  • Page 135: Platform

    Maintenance Platform If debris of print or contaminants exists on the surface of the platform or in its holes, platform leveling may not be performed perfectly. They may cause a degradation in the print quality or print failure. For the best printing performance, clean the platform regularly and after each printing job. Caution - Wear nitrile gloves before cleaning.
  • Page 136 Maintenance Clean remaining resin using a paper towel and IPA. Finally, clean all residual IPA using a dry paper towel. Caution - Do not place the IPA close to fire because it is flammable. If contaminants exist on a part where the platform is installed, platform leveling may fail, resulting in failed printing.

  • Page 137: Resin Tank

    Maintenance Resin Tank The resin tank consists of aluminum die-casted walls, a transparent window, a release film, and silicon rubber gaskets. For the best print quality, it is very important to keep optical parts, such as the transparent window and the release film, clean and undamaged. If the window and film are scratched, damaged, or contaminated, the laser beam will be scattered, reflected, or blocked.

  • Page 138: Cleaning The Resin Tank

    Maintenance Check for any of the following, and remove the contaminants. If serious damages, like holes, scratches, and so on, are found in the release film and transparent window, repair or replace the resin tank. Residues of prints sticking to the release film Floating contaminants or cured resin debris in resin Pigmentation of the release film Damages, like holes, scratches, and so on, in the release film...
  • Page 139 Maintenance Repeat this procedure. Rubber Scraper Cleaning Filter+Funnel Bottle After pouring the resin into the bottle, remove the residues of resin, debris, and other contaminants using IPA and a paper towel. Caution - Use a safe bottle made of stainless steel or transparent PE/PP plastic. If not, resin can be pigmented, or the bottle can melt down and mix with resin.
  • Page 140 Maintenance Reference - Grab the surrounding edges or handles of the resin tank to prevent contamination or damage of the transparent window. Cleaning the Transparent Window The transparent window needs to be cleaned only with IPA or a dedicated cleaner for glass and microfiber cloth. Non-microfiber cloth or paper towel can scratch the transparent window.

  • Page 141: Protective Glass

    Maintenance Protective Glass The protective glass is made of transparent glass to pass through a laser beam with maximum efficiency. In addition, it prevents external dust or resin from penetrating inside the machine. For the best printing performance, it is very important that the protective glass, through which the laser beam passes, is not scratched or contaminated.
  • Page 142 Maintenance Cleaning the protective glass The protective glass needs to be cleaned only with IPA or a dedicated cleaner for glass and a clean microfiber cloth. Non-microfiber cloth or paper towel can scratch the protective glass. ① Dampen the microfiber cloth with IPA, and wipe it from top to bottom without stopping. ②...

  • Page 143: Resin Cartridge

    Maintenance Resin Cartridge Managing the Resin Cartridge Photocurable resin consists of different chemicals. For the best print quality, shake unused resin cartridge at least once a week so that the ingredients are well mixed. Caution - Ensure that the sealing cap is firmly closed before shaking. Sealing Cap Storing the Resin Cartridge Store resin cartridges in a dark and well-ventilated place.
  • Page 144 Maintenance Caution - Be careful not to put IPA on the resin tank or other parts of the cartridge by mistake. Ensure that IPA is completely drawn and removed before restarting to use. - Ensure that the cartridge is not upset to prevent leakage of resin while cleaning. It is recommended to install the sealing cap first.

  • Page 145: Orange Cover

    Maintenance Orange Cover The orange cover is made of translucent orange acryl material to allow users to check the situation inside the device. Orange acryl is a specially selected material to safely shield the laser beam. To prevent users from accidentally using the machine with the cover open, double safety systems are installed. It is designed to stop temporarily for the safety of a user because if the cover is opened during printing, it may cause reduced quality or failed printing.

  • Page 146: Cleaning The Orange Cover

    Maintenance Reference - Pull the center part of the cover to easily close it. If you pull the left or right part, force is dispersed, which needs more force than the center. Cleaning the Orange Cover The orange cover needs to be cleaned only with a clean microfiber cloth and a dedicated cleaner for acryl material, for example, NOVUS No.

  • Page 147: Error Messages And Solutions

    Maintenance Error Messages and Solutions Message Description What To Do Booting On the first boot, the user must Once the boot-up process is finished and the Please wait until wait until the booting process is machine is ready, this message disappears booting is complete.

  • Page 148: Problems And Solutions

    Maintenance Problems and Solutions If the Resin Is Not Properly Supplied Checking the Auto Resin Supply Function If the [Auto Resin Supply] function is set to [OFF] , resin will not be supplied automatically. Check if “Auto Resin Supply of 2. UI Menu Function” is set to [ON]. Checking the Smart IC Chip and Terminals of the Resin Cartridge If the smart IC chip or terminals are contaminated with resin and so on, the resin cartridge may not be detected even if it is properly installed.

  • Page 149: Checking The Transparent Windows For Level-Detect Sensors

    Maintenance Checking the Transparent Windows for Level-Detect Sensors There are two small transparent windows for level-detect sensors. They are located on the back side of left and right. If those windows are contaminated, resin may not be supplied automatically because the SW considers that the resin tank is already filled with sufficient resin.

  • Page 150: Checking The Tube Connection

    Tube Third-Party Resin If a third-party resin is used instead of the one supplied by Sindoh, the resin may not be properly supplied or it is supplied until the resin tank overflows. With a third-party resin, set [Auto Resin Supply] of [Setting] to [Off] to supply it manually.

  • Page 151: Actions In Case Of A Printing Failure

    Maintenance Actions in Case of a Printing Failure Inevitably, printing can fail. In the event of a printing failure, a small piece of missing or incompletely cured resin will float in the resin tank or remain attached to the release film. These contaminants are generated more in case of a printing failure rather than successful printing.

  • Page 152: If Noise Is Generated From The Lead Screw Of Platform

    Maintenance If Noise is Generated from the Lead Screw of Platform Noise can be generated from the lead screw of platform if foreign matters such as resin, etc is located to the lead screw. To remove the noise, gently wipe the noise generating area of the lead screw using clean microfiber cloth in order to get rid of foreign matters.

  • Page 153: Replacing Consumables And Important Components

    Maintenance Replacing consumables and important components Replacing the Resin Cartridge Preparation for replacement Photocurable resin consists of different chemicals. Make sure to shake it enough before replacing it with a new one so that the resin is well mixed inside the cartridge. Caution - Make sure to close the sealing cap to prevent leakage before shaking it.
  • Page 154 Maintenance Important - If the cap is not fully closed, the resin may not be supplied. Turn the cap to close it until the projections of the cartridge and the cap contact each other. Insert the nozzle tube. Nozzle Tube Removing a used resin cartridge Open the orange cover, and remove the nozzle tube from the resin cartridge.
  • Page 155 Maintenance Pull out the tube from the resin cartridge. Tube Lift the resin cartridge using the handle, and take the cartridge out of the machine. Caution - If any resin remains in the removed cartridge, replace the sealing cap to prevent leakage and curing, and then store it.
  • Page 156 Maintenance Connecting tube Insert the tube connected to the air pump from the top of the projection of the cap. Tube Important - If the air pump tube is not properly connected to the resin supply cap, the resin may not be properly supplied.

  • Page 157: Replacing The Platform

    Maintenance Replacing the Platform Caution - Wear clean nitrile gloves before cleaning. Removing the current platform Open the orange cover, and remove the two platform locking knobs by turning in counterclockwise direction. Hold the platform with both hands grasping the handles, and remove it from the machine. Caution - Be careful not to drop the platform during installation or removal.
  • Page 158 Maintenance Installing a new platform Place the new platform on the machine in the exact reverse order of removing the platform, and secure it with two locking knobs. Important - When placing a platform on the mount, align the two protrusions of the fixed part. If they are not aligned, the platform will not be installed properly.

  • Page 159: Replacing The Resin Tank

    Maintenance Replacing the Resin Tank Replacing the Resin Tank Removing the current resin tank Open the orange cover, and then remove the resin tank in the following order: ① Turn the locking levers that hold both sides of the resin tank outward to unlock them. ②...
  • Page 160 Maintenance Removing remaining resin If resin remains in the resin tank, pour all remaining resin through the filter and store them in a bottle. If resin does not flow down from the resin tank, lean the resin tank onto several layers of waste paper or paper towel, and use a rubber scraper to scrape down resin.
  • Page 161 Maintenance Reference - Place the resin tank where its front parts and cover are aligned so that the resin tank can be easily pushed in. ② Turn the locking levers inward to secure the resin tank. Turn them until they are locked. Leveling the platform Once the new resin tank is installed, proceed with the platform leveling process again to adjust the alignment between the platform and resin tank.

  • Page 162: Replacing The Release Film

    Maintenance Replacing the Release Film Caution - Wear clean nitrile gloves before cleaning. If the release film is severely damaged, replace it according to the following procedure. Contact your local dealer regarding ordering a film replacement kit. Cleaning the resin tank If the release film is replaced without cleaning the resin tank, resin may enter the gaps of the tank, where it is difficult to remove the resin during disassembly.
  • Page 163 Maintenance Caution - To prevent adherence of the release film and transparent window, release agent is applied to the surface where the release film touches the transparent window touch. Do not clean the transparent window surface, which touches the release film, with IPA. Removing the sealing bracket Remove the sealing bracket by turning 36 sealing bracket fixing screws counterclockwise with the cross head screwdriver.
  • Page 164 Maintenance Assembling a new release film Prepare the new release film. The protection sheets are attached to both sides of the film. Remove them gently. Place the new release film between the rubber gaskets, and align them with the grooves of the resin tank for proper positioning.
  • Page 165 Maintenance Important - Fasten 4 screws in every corner of the sealing bracket first, and do the same for the other 32 screws. Cleaning the release film and transparent window If any contaminants exist between the release film and the window, it would be difficult to remove them. Therefore, it is necessary to clean up the release film and window before putting back the tray.
  • Page 166 Maintenance Important - Pay attention to the orientation when assembling the tray. Make sure that the protruded parts on the left and right sides of the tray are to be positioned opposite the outlet of the resin tank. If the assembly direction is wrong, the resin tank will not be installed.
  • Page 167 Notice to Users Type Notice This equipment is a Class A EMC Class A equipment (electromagnetic compatible) (commercial telecast equipment, and should not be used in hou- equipment) sehold locations This Product is a Class A equipment.
