- Page 1 DP200/DP102 DP201/DP202 2X / 2X DP303 1X / 1X DP302 3DWOX 1 3DWOX Desktop Manual Read the User Manual before operating the product, and keep the manual at a convenient place near the product. 3dprinter.sindoh.com...
-
Page 2: Table Of Contents
Contents Basic UI Elements -------------------------------------------------------------------------------------------------------------- Functions and Information -------------------------------------------------------------------------------------------------- Loading ----------------------------------------------------------------------------------------------------------------------------- Detail description ----------------------------------------------------------------------------------------------------------------- Profile Value Setting ------------------------------------------------------------------------------------------------------------- Detail description ----------------------------------------------------------------------------------------------------------------- Custom Profile ------------------------------------------------------------------------------------------------------------------ Filament Information Indicator ---------------------------------------------------------------------------------------------- Detail description --------------------------------------------------------------------------------------------------------------- View Mode Selection Button ------------------------------------------------------------------------------------------------- Detail description --------------------------------------------------------------------------------------------------------------- Moving a model ---------------------------------------------------------------------------------------------------------------- Adjusting Model Size ---------------------------------------------------------------------------------------------------------- Model Rotation ----------------------------------------------------------------------------------------------------------------- Print -------------------------------------------------------------------------------------------------------------------------------... - Page 3 Function to Calculate Optimal Printing Direction ---------------------------------------------------------------------- Estimated Printing Error Surface ------------------------------------------------------------------------------------------- Overhang Surface ------------------------------------------------------------------------------------------------------------- Amount of Support -------------------------------------------------------------------------------------------------------------...
-
Page 4: Basic Ui Elements
Basic UI Elements Reference - Font used in the printer GUI and the user manual is the “NANUM” font provided by NAVER. After installation is complete, double click on the icon created on your desktop, a screen similar to the following appears. - Page 5 Name Explanation 3D model 3D model data displayed on the screen. Import button (LOAD) Loads printable 3D data into program. Settings button Settings for values necessary for slicing. Filament information Shows information on filaments inside the printer. Easily informs user of indicator filament material, color and remaining quantity.
-
Page 6: Functions And Information
Functions and Information Loading Loads a printable 3D model and displays it on the screen. Currently supported file formats are ply, obj, stl (binary, ascii, amf) Detail description Click on the Import button located left of screen. After selecting file, 3D model file is displayed as if it’s on the printer bed. 2.2 Profile Value Setting Slicing and printing require variety of parameter values. - Page 7 Easy Mode - Easy mode can be set for printing speed-quality, material, support pattern, and inside filling. - For the 2X and 2X DP303, Cartridge No. is enabled. Advanced Mode - This enables the user to change profiles to modify output values as he/she desires. - Custom profiles (= user-defined profiles) can also be edited in the advanced mode.
- Page 8 - For the 2X or 2X DP303, two cartridges will be on the list, and each cartridge can be set individually. sign marked values are synchronized for two cartridges. Individual values cannot be set independently. - Support type can be selected or disabled. - Profile selection bar: The user may choose either a default profile or a custom profile.
- Page 9 Speed - It controls the printing and travel speeds. - If you print large object with a high “Fill Density”, please reduce the “Travel Speed”. Retraction / Cooling - Sets control values for the retraction of filament and nozzle cooling fan. Multi Nozzle - It is enabled only for the 2X or 2X DP303.
- Page 10 - The Wipe Tower is divided into an Inner tower and an Outer tower, and one cartridge can be used in the tower of each part. For example, if you set the outer cartridges to (1) as shown, the inner tower will automatically be set to cartridge (2).
-
Page 11: Custom Profile
2.3 Custom Profile Clicking [Profile] - [Custom Profile] will open the [Custom Profile List] window. Only custom profiles that are exclusive of the slicer program’s default profiles will be listed. If the user has not created a custom profile, the list will be empty. * Name: This is the profile name input by the user for profile creation. - Page 12 - The user may copy not only a default profile but also a previous custom profile that he/she has created. - The list of default profiles varies depending on the model. e.g., In the case of the DP200, when no custom profile is defined, only the “Sindoh PLA” and the “Sindoh ABS” will be listed.
-
Page 13: Filament Information Indicator
“Material” fields of the [Default Setting] will show the “ETC” profile. The user should select the “ETC” material if he/she uses a material that is different from those provided by Sindoh. * [OK] button: This will save all the setting values and close the dialog box. -
Page 14: Detail Description
Detail description 3D Model Viewer This mode renders the 3D model loaded and displays it on the screen. In this mode user is able to change position, angle and size of the 3D model and print it out. Support Edit Viewer When the model contains a slant surface, s support is needed at the bottom of the model to ensure good printing output. -
Page 15: Adjusting Model Size
Adjusting Model Size Scale and length of selected model on screen can be adjusted. Size of scale can be controlled in direction of three axes. Size of length can be controlled in direction of three axes. Expansion and contraction on the x,y,z directions at the same ratio. Adjust model to maximum printable size. -
Page 16: Select A Cartridge
If the Layer Color is activated, a 3D model cannot be right-clicked. (To delete or move object.) For DP200/DP102, DP201/DP202, 3DWOX 1 and 1X/1X DP302 - Pause the printing on the desired layer. Unload the cartridge, replace it, and continue printing. - Page 17 For 2X and 2X DP303 The Layer Color is a function to specify different cartridges for different layers. Move the left-side slider to show slider positioned layer and the layer number. Position the slider at cartridge change desired layer and press the [Add] button in the bottom. Then, another tab is created to replace cartridges by layer.
-
Page 18: Equal Distribution
0th to 69th layers are printed by cartridge 1 and 69th to 230th layers are printed by cartridge 2. If the boundary cross-sectional area of the layer color is small, increase the infill density of the internal filament for ensuring durability. 2.12 Equal Distribution Enter desired number of layers, and press the [Equal Distribution] button to divide all layers evenly. -
Page 19: Merge & Split
2.13 Merge & Split It is not applicable if the [Layer Color] is enabled. Merge Merge is a function to align the axis with respect to the origin. Ctrl + Select (left-click) two or more objects. Then, right-click and click merge object to merge the selected objects. - Page 20 Profile There are many profile-related functions. For custom profiles, see “2.3 Custom Profile.” Setting This enables the designation of various setting values needed for slicing. Printer Setting (DP200/DP102, 3DWOX 1) - Printer Model: A connected default printer appears on the screen. - Number of Nozzles: The number of nozzles of the device is displayed - Bed Heating Function: Only select when bed heating function is available.
- Page 21 - Printer Settings screen and features are same as DP200 and 3DWOX 1. When the printer in use is DP201/DP202 - For DP201, the printer setting screen has been changed as below. - Bed Heating Function: This function is deactivated for DP201/DP202.
- Page 22 When the printer in use is 2X/2X DP303 - For 2X, the printer setting screen has been changed as below. - 2X/2X DP303 has two nozzles. Beside the change above, other setting screens are same as DP200/DP102. Caution - E-mail feature must be selected from the UI menu before being used. For further details, please refer to “UI Menu Feature Description.”...
- Page 23 Reset Profile Resets all profile parameter values to default value. View Able to choose viewing mode that is equivalent to features of View Mode Selection button. For more details, please refer to “2.4 View Mode Selection button” on page.11. Printer Finds and adds printers on the network.
- Page 24 - Compatible browser versions are Internet Explorer 11 or FireFox 40.0 or Chrome 47.0 or higher. Some features may not function properly if the browser version is lower than the above. < DP200/DP102, 3DWOX 1and < DP201/DP202 > < 2X/2X DP303 > 1X/1X DP302 >...
- Page 25 Analysis This function analyzes the 3D model and notifies user of any problems that might arise. (refer to Advanced Functions) Help User can gain access to information on Language, Keyboard Shortcuts, Online FAQ and Program Updates.
-
Page 26: Printing (Basic Functions)
Printing (basic functions) Explanation of the steps to printing 3D model using base functions. Loading 3D Model Files Click on the [LOAD] button located on the left hand side of the screen and select the 3D model file user wants to import. -
Page 27: Print
Total layer number Slider to move to the desired layer Current layer on screen Print There are three ways to print the sliced model. USB Thumbdrive Slice the model and press [Save G-code] on the File menu. Save the G-code file in the USB Thumbdrive. Connect to the USB port on the front side of the printer and load the G-code file to directly print the model. -
Page 28: Local Network Usage
If the monitor shows no problems as shown below, press [Print] to begin printing. G-code is sent through the Network and the printer begins printing. Local Network Usage In order to use this function, the printer must be connected through the USB cable. More details can be found in the <My Printers>... - Page 29 G-code is sent through the USB Cable and the printer begins printing.
-
Page 30: Advanced Features
Advanced Features Support Edit Function 3DWOX offers users to not only use the setting values automatically calculated by the program but can be changed manually. Thus, you can add or delete additional supports in addition to the established supports. These types of editing tools can be executed in Support Editing View Mode. Support Editing View Mode 3D Model First load 3d model into program. - Page 31 Creating and Removing Support Support Creation To create a support, click on the inactive area (blue) in the edit region. Now, the region will turn red and creation of perpendicular supports can be seen . Removing Support To remove support, press and hold Ctrl key and click on the active area of the edit cross section. The area that has been selected will turn black (inactive), Supports that have been created will be removed.
- Page 32 Because of the shape in the middle, Support area has been divided. Support Edit Maneuvering Slider Current Support editing size Minimum size of editing Maximum size of editing To edit the support inside, the model user has to move the edit cross section. Use the support edit slider to maneuver around.
-
Page 33: Model Analysis Function
Creating Final Support After finishing the touches to the support, change to Layer Viewer mode. The model will go through the slicing process again. Now the user can interact with the finished slice with edited supports. 3D Model Analysis Function 3DWOX has the function where printing the program analyses the shape of the 3D model and informs user of any problems that might occur before printing. -
Page 34: Under Analysis Menu, Select Thickness / Overhang
Under Analysis menu, select Thickness / Overhang. At the top of the screen, under the Analysis menu select Thickness / Overhang. The analysing process is displayed and calculated results and analysis control window appears. Analysis Control Window Controls the thickness. Display Overhang function on/off. -
Page 35: Overhang Analysis Function
Overhang Analysis Function In 3D printing, it’s very favorable if object is perpendicular to bed surface, more horizontal the shape is, the more disadvantageous it is. When the angle in horizontal direction is small, supports are needed. The Overhang analysis function calculates the geometry’s inverse draft and notifies the user of possible problems that might occur during an actual printing. - Page 36 Select 3D model With the 3D model loaded, click on the model to select. In Analysis menu, select “Optimal Printing Direction” and a window similar to the following appears. Calculate Graph for each evaluation criteria Calculation for each 6 different direction would be initiated once the user clicks on the Caculate button.
- Page 37 Results of 6 different directions of the model will be displayed, and each direction will be ranked on the evaluation results. Following the results of the evaluation, the most optimal direction will be graded accordingly,and a graph of each evaluation analysis can be examined. The taller the graph, the higher the scores are achieved for the corresponding evaluation criteria.
