USER MANUAL
Read the User Manual before operating the
product, and keep the manual at a convenient
place near the product.
MIMAKI ENGINEERING CO., LTD.
https://3dprinter.sindoh.com/
D203516-10
https://mimaki.com/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mimaki 3DWOX 1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sindoh Mimaki 3DWOX 1

Summary of Contents for Sindoh Mimaki 3DWOX 1

  • Page 1 USER MANUAL Read the User Manual before operating the product, and keep the manual at a convenient place near the product. MIMAKI ENGINEERING CO., LTD. https://3dprinter.sindoh.com/ D203516-10 https://mimaki.com/...
  • Page 2 Safety Instructions Be sure to observe the followIng instructions when using the device. Warning: Failure to observe the instructions may lead to death or serious injury. Plug the power cord directly into the wall socket. Do not use extension cord. If the power cable or plug is worn or damaged, pull out the power plug.
  • Page 3 Before use Thank you for purchasing our product. This user manual contains detailed information about correct use of device and easy maintenance to maintain the optimal state, and to contribute to the rationalization of office work of your company. Carefully read the user manual before using the device and keep close at hand. In order to use device correctly and safely, please carefully note the precautions before use.

  • Page 4: Table Of Contents

    Contents Before using the Machine Preface -------------------------------------------------------------------------------------------------------------------------- 1 Conventions ------------------------------------------------------------------------------------------------------------------ 2 2.1 Symbols ------------------------------------------------------------------------------------------------------------------------ 2 Safety Information ---------------------------------------------------------------------------------------------------------- 3 Precautions ------------------------------------------------------------------------------------------------------------------- 5 4.1 Installation ---------------------------------------------------------------------------------------------------------------------- 5 4.2 Moving the Machine ---------------------------------------------------------------------------------------------------------- 6 4.3 About the Caution Label ---------------------------------------------------------------------------------------------------- 7 Consumables Handling --------------------------------------------------------------------------------------------------- 8 Instructions for Use -------------------------------------------------------------------------------------------------------- 9 Ventilation ------------------------------------------------------------------------------------------------------------------- 10 Notices ----------------------------------------------------------------------------------------------------------------------- 11...
  • Page 5 LOAD ------------------------------------------------------------------------------------------------------------------------- 2-4 UNLOAD -------------------------------------------------------------------------------------------------------------------- 2-5 UNLOCK -------------------------------------------------------------------------------------------------------------------- 2-7 1.2 Settings -------------------------------------------------------------------------------------------------------------------2-10 X, Y, Z -----------------------------------------------------------------------------------------------------------------------2-11 EXTRUDER ---------------------------------------------------------------------------------------------------------------2-13 BED LEVELING ----------------------------------------------------------------------------------------------------------2-15 Z OFFSET -----------------------------------------------------------------------------------------------------------------2-17 NOZZLE CLEANING ----------------------------------------------------------------------------------------------------2-19 CLEANING CASE --------------------------------------------------------------------------------------------------------2-21 NETWORK ----------------------------------------------------------------------------------------------------------------2-22 LAMP ------------------------------------------------------------------------------------------------------------------------2-26 BED LOWERING ---------------------------------------------------------------------------------------------------------2-28 TEST PRINT ---------------------------------------------------------------------------------------------------------------2-29 POWER SAVING MODE -----------------------------------------------------------------------------------------------2-31 BEEP SOUND ------------------------------------------------------------------------------------------------------------2-32 NOZZLE SETTING ------------------------------------------------------------------------------------------------------2-34...
  • Page 6 Chapter 4 Printed Output Check Printed Output Check --------------------------------------------------------------------------------------------------- 4-2 1.1 Detaching Printable ------------------------------------------------------------------------------------------------------- 4-2 1.2 Improving Printing Quality ---------------------------------------------------------------------------------------------- 4-4 When Printer Cannot be Turned On ------------------------------------------------------------------------------- 4-5 If problems persist ------------------------------------------------------------------------------------------------------ 4-6 Chapter 5 Maintenance Machine Cleaning ------------------------------------------------------------------------------------------------------- 5-2 1.1 Cleaning Case Maintenance ------------------------------------------------------------------------------------------- 5-2 1.2 Printer Interior Cleaning ------------------------------------------------------------------------------------------------- 5-2 1.3 Periodical Inspection ----------------------------------------------------------------------------------------------------- 5-2...

  • Page 7: Before Using The Machine

    - The content of the User Manual is subject to change without any prior notification. Sindoh shall not be liable for consequential, special, indirect damages or losses caused by the handling or operating of the machine or by the user’s negligence.

  • Page 8: Conventions

    Before using the Machine Conventions Symbols This manual uses the following symbols and meanings. Warning - Indicates safety notes of high importance. Ignoring these notes could result in serious injury or death. Be sure to read these notes carefully for your safe operations of the machine. Caution - Indicates important safety notes.

  • Page 9: Safety Information

    Before using the Machine Safety Information Plug the power cord into a properly grounded outlet which is easily accessible. Do not use or place the machine in wet or humid environment. Caution Hot Surface - The inside of the machine may be hot. To reduce the risk of injury from a hot component, allow some time to cool down.
  • Page 10 - Sindoh is not liable for problems caused by using an unauthorized spare parts or consumables. - Disconnect the power cord and all the cables connected to the machine to prevent from any electrical shock when cleaning the outside or inside of the machine.

  • Page 11: Precautions

    Before using the Machine Precautions Installation Warning - Install the machine in a well ventilated area. There may be some odor during operation. It should not be harmful; however, if the area of where the machine is located is not ventilated, make sure to ventilate the area appropriately time to time. Important - Install the machine with its vents spaced at least 10 cm away from walls and other equipments.

  • Page 12: Moving The Machine

    Before using the Machine Moving the Machine Please turn off the machine. Please unplug the power cord and remove all the cables connected to the machine. After ensuring the bed and cartridge are inserted into the machine, close the front and top door. Lift the machine carefully using the handles on both sides of the machine and slowly carry it with the machine bottom facing the floor.

  • Page 13: About The Caution Label

    Before using the Machine About the Caution Label This machine has the caution label attched on it. Please read the caution label carefully. If the caution label becomes soiled or too worn to read, please get a new one from your seller or our sales office in your region.

  • Page 14: Consumables Handling

    Before using the Machine Consumables Handling Warning - Do not burn the Cartridge unit or filament. It may be a cause of big fire or burn by ignition. Caution - Keep them out of the reach of children. - If skin irritation occurs after touching the filament, please see a doctor. Important - Do not keep the cartridge unit in the following places.

  • Page 15: Instructions For Use

    Before using the Machine Instructions for Use Caution - The nozzle and the bed that are inside the machine are very hot during machine operation. Please be cautious not to touch the nozzle or the bed during removal of the printed objected or during inspection of the machine inside.

  • Page 16: Ventilation

    Before using the Machine Ventilation Caution - Use the machine in a place with good ventilation. If the machine is used in a place without good ventilation, this may be harmful for your health. Ventilate it on a regular basis. - Do not block vents.

  • Page 17: Notices

    Before using the Machine Notices Noise Emission Level The following are measured in accordance of ISO 7779 and reported to meet ISO 9296. Some modes may not be available in your purchased products. Average Sound Pressure at 1 Meter Away Printing 45 dB(A)(Normal Print Condition - Printing speed 40 mm/s, Movement speed 100 mm/s) Standby...
  • Page 18 Before using the Machine Total Energy Usage It would be useful to calculate the Total energy usage of the machine. Since the electricity bill is charged in Watt unit, you have to multiply time spent in each mode by power consumption in order to calculate the energy use.

  • Page 19: Disposal Of Used Battery

    Before using the Machine Disposal of Used Battery Control board uses a Lithium battery. Please discard used batteries following the environmentally friendly procedure stated on the manufacturer guidelines. To replace batteries, please contact a qualified service engineer.

  • Page 20: 10. Wifi Module Disclaimer

    Do not expose this product to water, humidity or liquid. Do not expose this product to direct light, hot temperature or fire. Warning - If the machine has been modified by an unauthorized personnel, Sindoh is not liable for the machine trouble or failure. Caution - To prevent RF signals that exceed FCC RF exposure limits, please install this machine in an area where human contact can be minimized.
  • Page 21 Before using the Machine Precautions IEEE 802.11b : 2400MHz ~ 2484MHz IEEE 802.11g : 2400MHz ~ 2484MHz Frequency IEEE 802.11n(20MHz) : 2400MHz ~ 2483MHz IEEE 802.11n(40MHz) : 2400MHz ~ 2483MHz Antenna Power Density IEEE 802.11b : 10mW(10dbm)/MHz IEEE 802.11g : 10mW(10dbm)/MHz IEEE 802.11n(20MHz) : 10mW(10dbm)/MHz IEEE 802.11n(40MHz) : 10mW(10dbm)/MHz No.

  • Page 22: 11. Usb Memory Disclaimer

    Before using the Machine 11. USB Memory Disclaimer FCC COMPLIANCE STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 23: Chapter 1 Preparations For Machine Operation

    3DWOX 1 USER MANUAL Preparations for Machine Operation...

  • Page 24: Machine Specifications

    USB Device, USB Host, Wifi, Ethernet Cartridge Auto Load / Unload Software/Support Supported Software Sindoh Exclusive Slicer Supported File Format *.stl, *.ply, *.obj, *.amf, *.gcode Supported Operating System Windows 7 or above, Mac OS X 10.10 or above Recommended Memory Requirements...

  • Page 25: Basic Components

    Preparations for Machine Operation Basic Components Please check all basic components are in the box. Caution - Please keep the box and packaging material; they are needed for product exchange or repair service. Power Cable 3D Printer Cartridge USB Cable Reference Guide Ferrite Core Scrapper...

  • Page 26: Understanding The Device Parts

    Preparations for Machine Operation Understanding the Device Parts <Front> <Rear> Part Name Description Front door handle A handle to open the front door. USB port Connect USB flash drive containing printing information and print directly from USB flash drive. LCD Control panel Screen used to control printer.
  • Page 27 Preparations for Machine Operation <Interior> Part Name Description Bed height adjustment Knob Used to level the Flexible bed. Removable bed handle Used to assemble and dismantle Flexible bed Bed heater Heats the printables' bottom surface to stabilize it on the bed. Flexible bed (bed sheet) Seating space for Printable <Nozzle>...

  • Page 28: Installation (Product Connection, Cartridge Setup And Includes Software Installation)

    Preparations for Machine Operation Installation(Product connection, Cartridge Setup and Software installation) Device Connection On the rear side of the machine, connect the power cable to the power socket. Next, connect the power cable to the power outlet. Press the power button, located on top of the machine. After main menu is displayed on the LCD screen, install the cartridge (Refer to UI manual “LOAD”).
  • Page 29 Preparations for Machine Operation When installation of the file is complete, a pop-up window shows up as picture below. Press [Next] button to initiate the installation of 3DWOX Desktop program. Choose the destination location of the file and press [Next] to proceed. The file gets saved and the installation starts.
  • Page 30 Preparations for Machine Operation After all installation is complete, you can see that the “3DWOX Desktop” created on the desktop of your computer.
  • Page 31 3DWOX 1 USER MANUAL UI Menu Function...

  • Page 32: Ui Menu Function Description

    UI Menu Function UI Menu Function description CARTRIDGE LOAD UNLOAD UNLOCK SETTING X,Y,Z ALL, X, Y, Z X, Y, Z EXTRUDER BED LEVELING Z OFFSET Move Save NOZZLE CLEANING CLEANING CASE NETWORK Wifi (Options) Wifi SELECT NETWORK LIST DHCP Static Clear SSID Wired (Options)

  • Page 33: Cartridge

    UI Menu Function E-MAIL E-mail Address E-mail Server Info Address Port SECURITY UNIT *Celsius(˚C) Fahrenheit(˚F) *meter(m) feet(ft) TIME SETTING YYYY, MM, DD, HR, MIN TIME ZONE SECURITY S/W UPDATE CLOUD INFORMATION Name Change Name & PW Name Reconfirm PW Cancel Model Name Serial No.

  • Page 34: Load

    UI Menu Function LOAD This function automatically loads filament to the Nozzle. From the HOME screen press [CARTRIDGE]. Press [LOAD] to activate Cartridge load.

  • Page 35: Unload

    UI Menu Function When [OK] is pressed at the cartridge load confirming message, cartridge load will automatically proceed. The filament reaches to the nozzle and it is heated up to the specified temperature. Then the filament is inserted into the heated nozzle. After the process has finished, screen will automatically return to the [HOME] screen.
  • Page 36 UI Menu Function Press [UNLOAD] to activate Cartridge unloading. When [OK] is pressed at the cartridge unload confirming message, cartridge unloading will automatically proceed. To remove filament, the nozzle is heated up to the specified temperature and the filament unload starts. After the filament has been removed, the screen will automatically turn to the [UNLOCK] screen to let the user remove the cartridge.

  • Page 37: Unlock

    UI Menu Function UNLOCK This Function is to remove the cartridge out of the printer. Cartridge unlock automatically initiates when filament unload is finished. Cartridge unlock can also be manually done by the user. When unlock screen automatically appears after cartridge unload. For 10 seconds [LOCK] state is deactivated and the user can detach cartridge from printer.
  • Page 38 UI Menu Function To manually unlock later. From home screen press [CARTRIDGE]. Press [UNLOCK] to activate UNLOCK function.
  • Page 39 UI Menu Function For 10 seconds [LOCK] state is deactivated and the user can detach cartridge from printer. If the cartridge can’t be pulled out even after “unlock”, gently push it forward and then try to pull out again. After 10 seconds printer will automatically change to [LOCK] state and [UNLOCK] appears.

  • Page 40: Settings

    UI Menu Function Settings SETTING X,Y,Z ALL, X, Y, Z X, Y, Z EXTRUDER BED LEVELING Z OFFSET Move Save NOZZLE CLEANING CLEANING CASE NETWORK Wifi (Options) Wifi SELECT NETWORK LIST DHCP Static Clear SSID Wired (Options) DHCP Static LAMP (Options) Always On Always Off...

  • Page 41: X, Y

    UI Menu Function E-MAIL E-mail Address E-mail Server Info Address Port SECURITY UNIT *Celsius(˚C) Fahrenheit(˚F) *meter(m) feet(ft) TIME SETTING YYYY, MM, DD, HR, MIN TIME ZONE SECURITY S/W UPDATE CLOUD X, Y, Z Use to change the position on the X, Y, and Z axes of the Nozzle. From home screen press [SETTING].
  • Page 42 UI Menu Function Press the [X,Y,Z] button to enter X, Y, Z. Press either [0.1], [1], [10], or [100] to select the movement distance, and press the arrows to move the Bed and the Nozzle in the respective position. To move to each axis' home location, press [All], [X], [Y] or [Z].

  • Page 43: Extruder

    UI Menu Function EXTRUDER This function is used to fine control the filament to its position. From home screen press [SETTING]. Press [EXTRUDER] to enter EXTRUDER settings.
  • Page 44 UI Menu Function To Control [EXTRUDER], Nozzle temperature needs to be raised. Press [1], [10], [50], or [100] to select an amount. In the image shown below, press the direction to move the filament.

  • Page 45: Bed Leveling

    UI Menu Function BED LEVELING This function is used to perform the leveling of the bed. From home screen press [SETTING]. Press the [BED LEVELING] button to enter BED LEVELING settings. If the current Nozzle temperature is too high, process for cooling down the Nozzle temperature is added.
  • Page 46 UI Menu Function On the SETTING page, user is able to perform bed leveling. The bed leveling process consists of 3 steps. From the center, the top side is measured first, and then both sides of the bottom level are measured. If the height of the bed is perfect then levelling process will be finished but if the height of the bed and nozzle does not match, screws will appear informing user the direction and the number of screw rotation.

  • Page 47: Z Offset

    UI Menu Function When all settings are done the program returns to the previous screen. Z OFFSET ※ After bed leveling, it is highly recommended to check the z-offset. This Menu allows user to control the GAP in between Nozzle and BED. Standard is 0.25mm and can be manually overwritten.
  • Page 48 UI Menu Function Press the [Z OFFSET] button to access Z Offset screen. Default value is 0.25mm, Use [+], [-] buttons to move in 0.05 mm unit.

  • Page 49: Nozzle Cleaning

    UI Menu Function Use the [MOVE] and [SAVE] buttons to adjust the gap and to save the setting. The saved value is applied when next time the print starts. These values will be reset if bed leveling is initiated. NOZZLE CLEANING Function used when nozzle needs cleaning of left over filament residue.
  • Page 50 UI Menu Function Press the [NOZZLE CLEANING] button to access nozzle cleaning settings. In order to get rid of filament residue, the nozzle needs to be heated. When the specified temperature is reached, it moves on to the next step to remove filament residue. Once finished message will appear press [OK], printer will return to the settings screen.

  • Page 51: Cleaning Case

    UI Menu Function CLEANING CASE Function used to clean out the case for the collected filament residue. From home screen press [SETTING]. Press the [CLEANING CASE] button to enter CLEANING CASE settings.

  • Page 52: Network

    UI Menu Function Entering Cleaning Case, the nozzle will automatically position itself to the left side to be visible and accessible. Like shown in the image, empty the CASE, press [OK] when done and user will be returned to the settings screen. NETWORK This is a menu to configure users network setting.
  • Page 53 UI Menu Function Press the [NETWORK] button to access network configuration screen. The default network setting is Wired (connection using LAN line). Press [DHCP] for automatic IP address setup. To manually input a fixed IP address press [Static] and enter an IP address.
  • Page 54 UI Menu Function In any case to use Wifi press the [Wifi] tab. Wifi setting can be turned ON or OFF. To select a Wifi network, click [Choose a network…] and the printer shows all available Wifi connections.
  • Page 55 UI Menu Function Select a wireless network from the list to connect to the network. For a password-protected network, a dialog pops up and asks for the password. You can refresh the network list by clicking [Search]. After successful connection printer may ask for [DHCP], [Static] similar to the WIRED setting. When all settings are finalized press [Connect] to save settings.

  • Page 56: Lamp

    UI Menu Function LAMP Menu to configure settings for machine lamp. From home screen press [SETTING]. Press [Next] to enter [LAMP] setting screen.
  • Page 57 UI Menu Function Settings available for [LAMP] are [Always On], [Always Off], and [On only in printing]. Use arrow buttons to select an option and press [OK].

  • Page 58: Bed Lowering

    UI Menu Function BED LOWERING Use this function, in times of moving printer to a different location. Bed will be lowered to the bottom and will be locked into position. Press [SETTING] from the home screen. Press [Next] to move to next page, where the [BED LOWERING] button is located.

  • Page 59: Test Print

    UI Menu Function Upon selection, the bed will automatically be lowered. TEST PRINT This function allows the user to test print a sample model already saved in the printer. From home screen press [SETTING].
  • Page 60 UI Menu Function Press [Next] button to move to the next page and press [TEST PRINT]. Select the test file to print.

  • Page 61: Power Saving Mode

    UI Menu Function POWER SAVING MODE Function to set timer for printer energy saver mode. From home screen press [SETTING]. Press [Next] button to move to the next page and press [POWER SAVING MODE].

  • Page 62: Beep Sound

    UI Menu Function The adjustable values of energy savor mode are [0 ~ 100 min]. The time can be adjusted in 5 min unit, select the desired time using the [ +, - ] then press [OK] button to save changes. 0 Min : Do not use Energy Saving Mode 5~100Min : Energy Saving Mode in 5 ~ 100 Min.
  • Page 63 UI Menu Function Tap on the [Next] button to move to next page, and press [BEEP SOUND]. Currently available sound settings are Low, Middle, High and Off. Select the desired setting and press the [OK] button to save settings.

  • Page 64: Nozzle Setting

    UI Menu Function NOZZLE SETTING Use this menu only when the nozzle has been replaced.(Refer to P.5-10 4.4 Exchanging Nozzle ) Press [SETTING] button from the home screen. Tap on the [Next] button to move to next page, and press [NOZZLE SETTING].
  • Page 65 UI Menu Function “NOZZLE SETTING” menu is a function that should be used after replacement to a new nozzle. Entering the menu, a notification message will pop up. Press the [OK] button to move to the next screen. Click inside the input field to insert the values for the new nozzle. Each nozzle has own value and it influences the GAP between nozzle and bed after bed leveling.

  • Page 66: Language

    UI Menu Function LANGUAGE Menu to set language for machine. From home screen press [SETTING]. Press [Next] 2 times to go to the screen where the [LANGUAGE] menu is.
  • Page 67 UI Menu Function Using the arrows select a language and press [OK].

  • Page 68: E-Mail

    UI Menu Function E-MAIL The printer takes an image of the current printing status and sends the information to the email address specified. Printer will send information of completion (%) based on the PC program standard settings. Maximum of 10 emails can be sent.
  • Page 69 UI Menu Function Configure the setting for email notification to be sent out from the device. Only the information that is required for sending the email is set up from the printer and the recipient information has to be configured in the Slicer program. Catergory Description E-mail Address...
  • Page 70 UI Menu Function To check the detailed setting values, please refer to the setup information from your email service provider. For the set up to use the outgoing email service, please find information by internet search or your email service provider’s instructions. A certain amount of interval time may be required after setting up the SMTP service before using.
  • Page 71 UI Menu Function Under "Sign-In&Secruity" click "Device activity & notifications" Scroll down and there is a "Allow less scure apps" criteria. Set it to "On" to enable the option. Printer Setting Set "smtp.google.com" for the settings of the email address. For Google, 25 and 587 ports are compatible.

  • Page 72: Unit

    UI Menu Function UNIT Settings for the units of measurments displayed on the printer. From the home screen, press [SETTING]. Press [Next] 2 times and select [UNIT].

  • Page 73: Time Setting

    UI Menu Function The units for temperature and length can be changed. TIME SETTING You can view or change the time setting. From the home screen, press [SETTING].
  • Page 74 UI Menu Function Press [Next] 2 times and select [TIME SETTING]. The time setting can be changed in this screen.

  • Page 75: Time Zone

    UI Menu Function TIME ZONE You can view or change the time zone setting. From the home screen, press [SETTING]. Press [Next] 2 times and select [TIME ZONE].

  • Page 76: Security

    UI Menu Function A preferred time zone can be selected from the time zone list. Once Time Zone has been set, the printer will restart to apply the new settings. SECURITY This menu allows you to enable the Security setting on your printer. From home screen press [SETTING].
  • Page 77 UI Menu Function Press the [Next] button to access the [SECURITY] Screen. After setting [On/Off] of the Security, and then press the [OK] button.

  • Page 78: S/W Update

    UI Menu Function S/W UPDATE With the printer connected to the internet user is able to download the latest software. From the home screen, press [SETTING]. Press [Next] 2 times and select [S/W UPDATE].

  • Page 79: Cloud

    UI Menu Function Press the [Start Update] button, and printer will start updating. After it has finished, restart the printer and updates will be applied. CLOUD This menu enables you to set up the Cloud menu whether to use the 3D printer or not. The machine will automatically reboot once the Cloud function setting is changed.
  • Page 80 UI Menu Function Press [Next] 3 times and select [CLOUD]. Select whether to add or remove the function by using the arrow key and then press [OK] to save.

  • Page 81: Information

    UI Menu Function Information INFORMATION Name Change Name & PW Name Reconfirm PW Cancel Model Name Serial No. Version Wired IP Wireless IP Wireless MAC Guide HISTORY In this menu user is able to view the detail information of the printer, and set device name & password. In [HISTORY] screen, user is able to view all the records of past works.
  • Page 82 UI Menu Function To set password and name for printer, select [Change Name & PW]. By entering the password, you can edit name and set a new password. Pressing [OK] saves the changes. Reference - *Initial password is ‘0000’.
  • Page 83 UI Menu Function In [INFO] screen, press [Guide] to access to the "Quick Guide" for the printer. Other useful information is also available in [INFO] screen.

  • Page 85: Printing

    3DWOX 1 USER MANUAL Printing...

  • Page 86: Printing From Usb Flash Drive

    Printing Printing User can print printables via USB flash drive, USB cable, or over the network. The following screen means you are ready to print. Printing from USB Flash Drive Connecting USB flash drive to the printer. In order to print using an USB flash drive, insert the flash drive into the USB port. When the USB flash drive is connected while in the home screen, a list of files in the USB appears.
  • Page 87 Printing Printing Files Select a file to print in the USB list. Print Preview Once selected, a preview of the model appears on the screen.
  • Page 88 Printing Printing Once [ ] is pressed the nozzle starts to be heated. When the specified temperature is reached, the printing starts. Pausing Print Pressing [ ] during a print will pause the progress. Press [ ] again and nozzle is heated again, and the printer will continue printing. Exchanging Cartridge during print Press [Change] to switch out the cartridge.
  • Page 89 Printing Print Cancelation During print pressing [ ] button a message pops up and asks for confirmation on the print canceling. When confirmed, the printing job is canceled. Another message requesting the removal of the remaining print will popup press [OK] and screen will return to home screen.

  • Page 90: Printing Via Pc

    Printing Printing Via PC Prepare PC connected to the same network where the printer is connected to. Run 3DWOX Slicer program. Press the “Print” button. Following Steps (Same as steps 3~7 of printing via USB) Note - Pause, print cancelation, please refer to "USB printing" section. CLOUD Printing To begin using the Cloud Print function, users must register the printer to the server.
  • Page 91 When using [CLOUD] for the first time, users must register their printer. * Alexa and Sindoh Cloud Slicer app share Printer registration information. [Generate Code] allows you to connect the device with the account of the user registered in the App.
  • Page 92 Printing When the print job is sent to the printer registered in the app, a menu called [Print Queue] appears, and the names of the sender and the transmitted print job are displayed in the list when the menu is entered. The transferred print job can be deleted with the [ - ] button.
  • Page 93 Printing [Printer Detail] menu lets users check the printer information. [Edit Printer] menu lets users change the [Display name].

  • Page 94: Print Job Management

    Printing [Deregister Printer] menu lets users delete the registered printer in the server. * If users delete the printer information, the [Print queue] list and the registered user list will be reset. * If users want to use the [CLOUD] function again after deletion, printer must be re-registered in the server. Print Job Management You can manage print jobs in queue.
  • Page 95 Printing The print jobs in queue are listed. You may click the list to look at the information of the print job and delete it if necessary.

  • Page 97: Printed Output Check

    3DWOX 1 USER MANUAL Printed Output Check...
  • Page 98 Printable Verification Printed Output Check Detaching Printed Output To safely detach the printed model, first let the bed cool down. Bed top plates must be detached as well. Caution Hot Surface - Without sufficient cooling the bed can be very hot. Please be cautious coming into contact . It may cause burns.
  • Page 99 Printable Verification Detach the object from the Flexible Bed. The object can be easily detached by bending the Flexible Bed up and down. Using the scrapper provided with the printer will be useful. Be careful not to apply too much pressure while using the scrapper could damage the bed sheet and the bed.

  • Page 100: Improving Printing Quality

    Printable Verification Improving Printing Quality Nozzle, Bed temperature Depending on the material (PLA), optimum temperature for the nozzle and bed can be different. Environmental factors (temperature, humidity) can affect the quality of the printed product. There is no absolute value for optimum temperature. Testing various temperatures and finding the optimum temperature are needed.

  • Page 101: When Printer Cannot Be Turned On

    Printable Verification When Printer Cannot be Turned On Open the Front door shown below and turn the belt counter-clockwis. After the bed is lowered, remove printed output and turn the power on.

  • Page 102: If Problems Persist

    Printable Verification If problems persist Please visit http://3dprinter.sindoh.com.

  • Page 103: Chapter 5 Maintenance

    3DWOX 1 USER MANUAL Maintenance...

  • Page 104: Machine Cleaning

    Maintenance Machine Cleaning Cleaning Case Maintenance On the LCD, if a message requesting for the cleaning of the cleaning case pops up, detach the cleaning case and clean all the filament residue inside the case. - If in need for further cleaning, on the menu, under settings, select cleaning case. The cleaning case can be detached.

  • Page 105: Cleaning The Inside Of The Nozzle

    Maintenance Cleaning the inside of the Nozzle Leftover residue in the nozzle interferes with filaments transfer. This interference can cause problems with printing and filament loading. The leftover residue makes the printing filament uneven or clogs the nozzle. Once melted, the filament can have different properties from the original. If the leftover residue in the nozzle is repeatedly heated / cooled, the properties will be changed.
  • Page 106 Maintenance Press [Setting] - [Extruder] to enter Extruder mode. After positioning the nozzle in the center, insert the enclosed Tube for Cleaning into the nozzle. Tube for Cleaning...
  • Page 107 Maintenance After reaching the target temperature of the extruder mode and the UI screen appears as below, insert the PLA filament into the tube and let it out through the nozzle. Note - White PLA filament is recommended for nozzle cleaning. It is easy to see that contaminant come out from the nozzle.
  • Page 108 Maintenance Insert the Tube for Cleaning into the nozzle again. Tube for Cleaning After reaching the target temperature of the extruder mode, insert the nozzle cleaner into the nozzle tube and let the contaminants out through the nozzle.
  • Page 109 Maintenance After Removing the nozzle cleaner, insert the PLA filament into the tube and let it out through the nozzle. Press the home button in the UI to lower the temperature of the nozzle. Slowly push the PLA filament until the nozzle temperature is 180 °C. If the nozzle temperature is between 80 ~ 90 °...
  • Page 110 Maintenance Repeat from step until the filaments are free of contaminants as shown below. If cleaned filament comes out with no contaminants as shown in the figure on the left below, the nozzle cleaning is complete. Cleaned Filament Contaminated Filament USING NOZZLE CLEAN TOOL If the filament does not come out of the nozzle well in step 5, proceed as follows.
  • Page 111 Maintenance Slowly turn left and right while pushing the nozzle cleaner inside the nozzle so that the filament inside of the nozzle can come out. Caution - When you pull out the filament, if you can not pull it out well, please heat the nozzle after removing it. B.
  • Page 112 Maintenance When the temperature of the nozzle is raised and the UI as shown below is displayed, insert the nozzle spring pin at the nozzle inlet side and turn it to the left and right to drill it. Caution - Be careful. It may cause burns. - The tip of the nozzle may be hot.

  • Page 113: Error Message And Solutions

    Maintenance Error Message and Solutions Message Description What To Do Booting Message means on the first boot Once the boot up process is over and Please wait until booting is user must wait until the booting is machine is ready, this message complete.
  • Page 114 Maintenance Message Description What To Do Notification 431 Occurs when printer is unable to Automatically UNLOCK screen will be Cartridge cannot be detected. detect cartridge. displayed. Reinstall cartridge. Re-insert cartridge after cartridge removal. Notification 432 Occurs when printer is able UNLOAD screen.
  • Page 115 Maintenance Message Description What To Do Notification 422 Occurs when filament does not Follow the on-screen instructions and Remove cartridge. Is there come out during UNLOAD. remove cartridge, and any filament any remaining filaments in residue. the tube or on the entrance of filament insertion (front of printer)?

  • Page 116: Problems And Solutions

    Maintenance Problems and Solutions 3.1 If filament does not come out of the nozzle (Fix for EC 401) Follow the on-screen instructions and start the auto recovery process. After the recovery process if problem persists follow the below steps. Initiate cartridge unlock. Remove the cartridge from the printer. Use the extruder jog mode to remove the filament.

  • Page 117: In Cases Where Filament Is Cut Between The Extruder And Nozzle

    Maintenance In Cases where Filament is Cut Between the Extruder and Nozzle Remove the Snap-Ring on the fitting in the nozzle and pull out the tube. Use Extruder mode and move the filament towards the nozzle to push out the cut filament. After removing all cut pieces of filament, insert the tube into the nozzle and attach the snap ring.

  • Page 118: Replenishing Consumables

    Maintenance Replenishing Consumables Bed Replacement Removing Flexible Bed Reference - Please refer to P. 4-2 “1.1 Detaching Printed Output”. Installing Flexible Bed Reference - Please refer to P. 4-2 “1.1 Detaching Printed Output”. Note - Small Scratches on the bed made during normal usage will not affect the print quality but if the bed sheet is ripped off or contaminated, the printed output may not adhere on the bed properly and should consider exchanging the bed to a new one.
  • Page 119 Maintenance Pull the upper fitting of the filter, and it will detach from the printer. Gently pull the filter to separate from printer. As shown below, slightly hang the lower half of the filter and gently push the top side to click it in. Fasten the screw using a Phillips screwdriver.

  • Page 120: Cartridge Replacement

    Maintenance Cartridge Replacement Replace cartridge when a cartridge is used up or a different color/material is needed. Initiate Cartridge Unload. Reference - For details on cartridge unload, please refer to P. 2-5 “UNLOAD” Please switch the cartridge first and then load. Reference - For details on cartridge load, please refer to P.
  • Page 121 Maintenance Press the tube holder and pull the tube to remove. TUBE TUBE HOLDER Push the hook on the top, and lift open the cover. HOOK COVER Push the 2 hooks on the harness connector to disengage the connector. To remove the left hand side connector, press on the hook until you hear a click sound. Then you can safely disconnect.

  • Page 122: Assembling The Nozzle

    Maintenance Pull the nozzle component to detach. NOZZLE Assembling the Nozzle Initiate process ONLY after power of machine is turned OFF, and after all power cables are disconnected. With the cover lifted up attach the nozzle. The Nozzle attaches magnetically, but please make sure that the component is firmly attached. NOZZLE Insert the 2 connectors and make sure to hear the clicking sound.
  • Page 123 Maintenance Push the cover down and make sure to hear the clicking sound. COVER Caution - Please be careful not to position the harness near the left, right and center section of the cover. The harness can get caught in between covers when closing. Caution Harness Insert Tube.
  • Page 124 Maintenance Slightly lifting the tube and insert the Snap-Ring. Insert the Snap-Ring in between the Fitting and Holder. SNAP-RING SNAP-RING INSERTION POINT Finally, push tube in all the way through. - Approximately 1.5mm can be additionally inserted. TUBE Use the “CARTRIDGE-LOAD” command to finish the cartridge loading process.

  • Page 125: Chapter 6 Appendix

    3DWOX 1 USER MANUAL Appendix...

  • Page 126: Type Of Consumables (Material, Color)

    Appendix Type of Consumables (Material, Color) Material: PLA are compatible PLA : White, Black, Gray, Red, Yellow, Greem, Blue, Pink, Purple...
  • Page 127 Notice to Users Type Notice This equipment is a Class A EMC Class A equipment (electromagnetic compatible) (commercial telecast equipment, and should not be used in hou- equipment) sehold locations This equipment is a Class B EMC (electro- Class B equipment magnetic compatible) (domestic telecast equipment, for household purposes, availa-...
  • Page 128 SindOh www.sindoh.com mimaki.com D203516-10-15062020 ©2019 MIMAKI ENGINEERING CO., LTD.

This manual is also suitable for:

3dff-222

Table of Contents
