- Page 1 WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. PC 550 2Z 2 I n s t a l l a t i o n M a n u a l...
-
Page 2: Power Failure
WARNING Please Read Carefully N o te to I n st a lle r s detectors, such as when the fire is in a chimney, walls or roofs, or on the other side This warning contains vital information. As the only individual in contact with sys- of closed doors. -
Page 3: Table Of Contents
4.5 Programming Quick Arm and Quick Exit Options ....9 4.6 Programming Function Keys ..........10 4.7 Programming the Master Code .........11 4.8 Setting Up the PC5502Z2 to Sound Alarms Locally ...12 4.9 Setting Up Door Chime Options ........12 4.10Programming Keypad Blanking Options ......13 4.11Resetting the PC5502Z2 to Factory Default Programming .13... -
Page 4: Limited Warranty
I ns ta l l e r ’s L o c ko u t • damage incurred in shipping or handling; Any products returned to DSC which have the Installer’s Lockout option enabled and exhibit no other problems will be subject to a •... -
Page 5: Section 1: Introduction
Sec ti on 1: I ntro duc t i on The PC5502Z2 is a 2-zone keypad that allows you to install up to seven 2-zone partitions on one control panel. The PC5502Z2 is compatible with the following control panels: • PC580/585 v2.3 and higher •... -
Page 6: Section 2: Installing The Pc5502Z2
S ecti o n 2: I ns t a l l i ng t he P C 5 5 0 2Z 2 This section describes how to mount, wire, and apply power to the PC5502Z2 keypad. 2.1 Unpacking The PC5502Z2 package includes the following parts: •... -
Page 7: Wiring
You cannot perform a system test from the PC5502Z2 keypad. To conduct a system test at the system keypad, please refer to your system’s Installation Manual and Instruction Manual. Now that you have connected the PC5502Z2, you will need to enroll it with the control panel. Please see section 3 for instructions. -
Page 8: Section 3: Enrolling The Pc5502Z2
[902] in the main panel Installer’s programming. The panel will now supervise all assigned keypads and enrolled modules on the sys- tem. Now that you have enrolled the PC5502Z2 on the system, you will need to program it. Please see section 4 for instructions. -
Page 9: Section 4: Programming
PC5502Z2 keypads. 4.1 How to Program the PC5502Z2 This section describes how to program a PC5502Z2. It is a good idea to fill out the Pro- gramming Worksheets section before you program the PC5502Z2. For instructions on programming the main control panel from a system keypad, please refer to your system’s... -
Page 10: Setting Up Pc5502Z2 Zones And Zone Options
4.2 Setting up PC5502Z2 Zones and Zone Options Each PC5502Z2 keypad can supervise two zones. By default, zone 1 is programmed as (01) Delay 1, and zone 2 is programmed as (02) Instant. If you need to change how the zones operate, you can select from these zone definitions: (00) Null Zone: The zone is vacant. - Page 11 (05) 24 Hour Burglary: If this zone is violated when the system is either armed or dis- armed, the PC5502Z2 will immediately sound an alarm. If the Local Alarm Timer is pro- grammed, the PC5502Z2 will wait the programmed amount of time, and then pass the alarm on to the main panel.
-
Page 12: Programming Zone Bypass Options
4.3 Programming Zone Bypass Options You can program the PC5502Z2 so that users will be able to bypass zones 1 and 2. Users can use the zone bypassing function when access is needed to part of the protected area while the system is armed, or if zones are temporarily out of service. -
Page 13: Programming Entry And Exit Times
P r o g r a m m i n g E n t r y a n d E x i t T i m e s Zone bypassing requires code You can also program the PC5502Z2 so that a user will need to enter an access code in order to bypass zones. This option is off by default. To turn this option on: 1. -
Page 14: Programming Function Keys
(see below). You can change the function of each function key on every keypad. To change the function keys, enter the following at the PC5502Z2 keypad: 1. Enter Installer’s Programming by pressing [*][8][Installer’s Code] 2. Enter [01] to [05] to change the programming for function keys 1 to 5 (i.e. enter [01] to change function key 1, [02] to change function key 2). -
Page 15: Programming The Master Code
Quick Arming option), users will always have to enter their code when using a function key. If you turn on both the main panel and PC5502Z2 Function Key Requires Code options, users will have to enter their code twice when using a function key. -
Page 16: Setting Up The Pc5502Z2 To Sound Alarms Locally
4.8 Setting Up the PC5502Z2 to Sound Alarms Locally You can set up the PC5502Z2 so that if an alarm occurs, the keypad will sound the alarm locally for a programmed amount of time before passing the alarm condition on to the main panel. -
Page 17: Programming Keypad Blanking Options
The lights will also come on if a key is pressed. [33] Keypad Blanking Requires Code for Removal This option is set to off by default. If this option is on, the PC5502Z2 will not turn the keypad lights back on until a valid access code is entered. -
Page 18: Section 5: Setting Up Panel Keypad Zones
Section 5: Setting Up Panel K e y p ad Z o n e s Now that you have programmed the PC5502Z2, you will also need to program the panel to monitor the PC5502Z2 keypad zones. NOTE: PC5502Z2 keypads will be “busy” (the System light will turn on) whenever someone enters a [*][1-8] function on the system keypad. -
Page 19: Programming Zone Definitions In The Panel
To exit, press [#]. NOTE: If you program 24-hour Supervisory Buzzer zones, then when the supervisory buzzer sounds users will not be able to arm the PC5502Z2 until a valid access code is entered on the system keypad. 4. When you are finished programming system zone definitions, press [#] to exit. -
Page 20: Section 6: Programming Worksheets
Secti on 6: P ro g r am mi ng Wo rks he et s Record all PC5502Z2 programming information on these worksheets. Record all main control panel programming information in the Programming Worksheets that came with your system. For the Record... - Page 21 [10] Zone Definitions (4.2 “Setting up PC5502Z2 Zones and Zone Options” on page 6) Valid entries: 00 - 04 Zone 1 Zone 2 Default = 01 Default = 02 I _ ______I _ ______I I _ ______I _ ______I Enter:...
- Page 22 Duration Timer: I _ ______I _ ______I _ ______l [99] Reset PC5502Z2 to Factory Default Programming NOTE: To reset the PC5502Z2 to factory default settings, there must be no alarms in memory. PC5502Z2 Keypad Zone Assignment (5.1 “Assigning the PC5502Z2 to a Keypad Zone” on page 14) Program the keypad zone assignment in the main panel Installer’s programming at the system...
- Page 23 F C C C O M P LI A N C E S TAT E M E NT CAUTION: Changes or modifications not expressly approved by Digital Security Products Ltd. could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 24 ©1999 Digital Security Controls Ltd. 1645 Flint Road, Downsview, Ontario, Canada M3J 2J6 (416) 665-8460 • Fax (416) 665-7498 • 1-800-387-3630 www.dscgrp.com Printed in Canada 29004461 R001...
