OPERATOR'S MANUAL
MODEL #100423
WIRELESS REMOTE START GENERATOR
or visit championpowerequipment.com
READ AND SAVE THIS MANUAL. This manual contains important safety precautions which should be read and understood before operating the product.
Failure to do so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
This product is rated in accordance with PGMA (Portable Generator Manufacturers' Association) standard PGMA G300 (Standard for Testing and Validating
Performance of Portable Generators).
Made in China - REV 20170227
Champion Power Equipment, Inc., Santa Fe Springs, CA USA
Advertisement
Table of Contents
Related Manuals for Champion 100423
Summary of Contents for Champion 100423
- Page 1 Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice. This product is rated in accordance with PGMA (Portable Generator Manufacturers’ Association) standard PGMA G300 (Standard for Testing and Validating Performance of Portable Generators). Made in China - REV 20170227 Champion Power Equipment, Inc., Santa Fe Springs, CA USA...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 100423 - WIRELESS REMOTE START GENERATOR TABLE OF CONTENTS Short Term Storage (up to 1 year) ...... -
Page 3: Introduction
100423 - WIRELESS REMOTE START GENERATOR INTRODUCTION SAFETY DEFINITIONS Congratulations on your purchase of a Champion Power The purpose of safety symbols is to attract your attention to Equipment (CPE) product. CPE designs, builds, and supports possible dangers. The safety symbols, and their explanations, all of our products to strict specifications and guidelines. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 100423 - WIRELESS REMOTE START GENERATOR IMPORTANT SAFETY INSTRUCTIONS DANGER Generator produces powerful voltage. WARNING DO NOT touch bare wires or receptacles. California Proposition 65: This product contains chemicals and produces exhaust known to the State of California to DO NOT use electrical cords that are worn, damaged or cause cancer, birth defects and other reproductive harm. -
Page 5: Fuel Safety
IMPORTANT SAFETY INSTRUCTIONS 100423 - WIRELESS REMOTE START GENERATOR WARNING WARNING Rapid retraction of the starter cord will pull hand and arm Medical and life support uses. towards the engine faster than you can let go. In case of emergency, call 911 immediately. - Page 6 IMPORTANT SAFETY INSTRUCTIONS 100423 - WIRELESS REMOTE START GENERATOR – Flammable gas under pressure can cause a fire or explosion When operating the generator: if ignited. DO NOT move or tip the generator during operation. – LPG is heavier than air and can settle in low places while DO NOT tip the generator or allow fuel or oil to spill.
-
Page 7: Safety Labels
100423 - WIRELESS REMOTE START GENERATOR Safety Labels These labels warn you of potential hazards that can cause serious injury. Read them carefully. If a label comes off or becomes hard to read, contact Champion Power Equipment’s customer service department for possible replacement. Side... -
Page 8: Controls And Features
CONTROLS AND FEATURES 100423 - WIRELESS REMOTE START GENERATOR CONTROLS AND FEATURES Read this operator’s manual before operating your generator. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Generator 1. Gasoline Tank – 4 gal. (15.1 L) 7. -
Page 9: Generator Panel
CONTROLS AND FEATURES 100423 - WIRELESS REMOTE START GENERATOR Generator Panel 1. Ignition Switch – Used to START or STOP the generator. Receptacles 2. Voltmeter – Used to display voltage output. 120V AC, 30A Locking (NEMA L5-30R) May be used to supply electrical power for 3. -
Page 10: Generator Panel Symbols
Meaning start (6) times. The RCM controls the Auto Choke during each attempt to start. If the generator does not start, call Champion Customer Care team for assistance at 1-877-338-0999. To stop the generator by Remote Control, press the “STOP”... -
Page 11: Parts Included
CONTROLS AND FEATURES 100423 - WIRELESS REMOTE START GENERATOR Parts Included FCC Statement for Remote Control Device 1. This device complies with Part 15 of the FCC Accessories Rules. Operation is subject to the following two Remote Key Fob ..............1 conditions: (1) This device may not cause harmful Oil Funnel ................ -
Page 12: Assembly
ASSEMBLY 100423 - WIRELESS REMOTE START GENERATOR ASSEMBLY Your generator requires some assembly. This unit ships from our factory without oil. It must be properly serviced with fuel and oil before operation. If you have any questions regarding the assembly of your generator, call our help line at 1-877-338-0999. -
Page 13: Add Fuel: Gasoline
ASSEMBLY 100423 - WIRELESS REMOTE START GENERATOR CAUTION Recommended Oil Type / Tipo de aceite recomendado / Type d’huile recommandé 10W-30 The engine is equipped with a low oil shut-off and will stop when the oil level in the crankcase falls below the threshold... -
Page 14: Grounding
OPERATION 100423 - WIRELESS REMOTE START GENERATOR Grounding 5. Screw on the gasoline cap and wipe away any spilled fuel. Your generator must be properly connected to an appropriate CAUTION ground to help prevent electric shock. Use regular unleaded unleaded gasoline with a minimum... -
Page 15: Grounding: Neutral Floating
OPERATION 100423 - WIRELESS REMOTE START GENERATOR Starting the Engine WARNING 1. Make certain the generator is on a flat, level surface. Do not operate or store the generator in rain, snow, or wet 2. Disconnect all electrical loads from the generator. Never weather. -
Page 16: Battery
OPERATION 100423 - WIRELESS REMOTE START GENERATOR NOTICE NOTICE Keep choke lever in “CHOKE” position for only 1 pull of the The supplied 12V 9AH battery does re-charge while the recoil starter. After first pull, move choke lever to the “RUN”... -
Page 17: Stopping The Engine
Volts x Amps = Watts To alleviate high altitude issues other than the natural power loss, Champion Power Equipment can provide a high altitude To prolong the life of your generator and attached devices, carburetor main jet. The alternative main jet and installation follow these steps to add electrical load: instructions can be obtained by contacting Customer Support. -
Page 18: Cleaning The Generator
MAINTENANCE 100423 - WIRELESS REMOTE START GENERATOR WARNING OIL DIP STICK VARILLA DEL ACEITE Improper maintenance will void your warranty. JAUGE D'HUILE NOTICE DRAIN BOLT PERNO DE DRENAJE BOULON DE VIDANGE Maintenance, replacement, or repair of emission control devices and systems may be performed by any non-road engine repair establishment or individual. -
Page 19: Cleaning The Spark Arrestor
MAINTENANCE 100423 - WIRELESS REMOTE START GENERATOR 3. Wash in liquid detergent and water. Squeeze thoroughly dry The air-fuel mixture is not adjustable. Tampering with the in a clean cloth. governor can damage your generator and your electrical devices and will void your warranty. CPE recommends that you contact 4. -
Page 20: Storage
Replace fuel line* be sure to properly dispose of the drained gasoline according to local regulations or guidelines. * To be performed by knowledgeable, experienced owners or Champion Power 7. Option 2: Run Dry (gasoline type models ONLY): Equipment certified dealers. -
Page 21: Long Term Storage (Over 1 Year)
STORAGE 100423 - WIRELESS REMOTE START GENERATOR 12. Clean the generator according to Cleaning the Generator. 7. If the generator includes a battery, connect according to Connect the Battery. 13. Store the generator in a cool, dry place out of direct sunlight. -
Page 22: Specifications
..........4-Stroke OHV Your Champion Power Equipment product is designed and rated for continuous operation at ambient temperatures up to 40°C Oil Specifications... -
Page 23: Parts Diagram
SPECIFICATIONS 100423 - WIRELESS REMOTE START GENERATOR Parts Diagram... -
Page 24: Parts List
SPECIFICATIONS 100423 - WIRELESS REMOTE START GENERATOR Parts List Part Number Description Qty. Part Number Description Qty. 27.601.35 Engine Flange Bolt M6 x 20, 34 1.5789.0620.1 Black 122.190005.00 Rubber, Fore-Cover, B 35 24.070800.00 Reversal Valve 122.190005.01 Rubber, Fore-Cover, A 36 2.06.006 Clamp Ø7 x Ø1... - Page 25 SPECIFICATIONS 100423 - WIRELESS REMOTE START GENERATOR Part Number Description Qty. Red Wire, 190 mm, 71 5.1900.010 Battery Jacket, 9AH Battery, 72 122.200013.01.3 Jacket, 9AH Battery, 73 122.200013.01.1 Black Black Wire, 190 mm, 5.1900.011 Battery 75 122.210002.26 Control Box 76 1.5789.0615.1 Bolt M6 x 15, Black 77 1.818.0514.2...
-
Page 26: Engine Parts Diagram
SPECIFICATIONS 100423 - WIRELESS REMOTE START GENERATOR Engine Parts Diagram... -
Page 27: Engine Parts List
SPECIFICATIONS 100423 - WIRELESS REMOTE START GENERATOR Engine Parts List Part Number Description Qty. Part Number Description Qty. 38 21.127000.02 1.5789.0608 Flange Bolt M6 x 8 Oil Level Sensor 39 26.010100.01 Cylinder Head, 224cc Cover, Recoil Starter, 22.061100.00.2 Black 40 27.050200.00 Connecting Rod 21.061005.00... - Page 28 SPECIFICATIONS 100423 - WIRELESS REMOTE START GENERATOR Part Number Description Qty. Part Number Description Qty. 78 23.040017.00 Oil Seal, Valve, Iron Connecter, Choke 113 26.130015.24 Valve Axis 79 21.040003.00 Spring, Valve Support, Stepper Retainer, Exhaust 114 26.130005.24 80 21.040007.00 Motor Valve Spring 115 45.132200.01...
-
Page 29: Wiring Diagram
SPECIFICATIONS 100423 - WIRELESS REMOTE START GENERATOR Wiring Diagram... -
Page 30: Troubleshooting
TROUBLESHOOTING 100423 - WIRELESS REMOTE START GENERATOR TROUBLESHOOTING Problem Cause Solution No fuel. Add fuel. Generator will not start. Faulty spark plug. Replace spark plug. Unit loaded during start up. Remove load from unit. Fill crankcase to the proper level. - Page 31 Warranty Registration Card and a copy of your sales – Problems caused by parts that are not original Champion Power receipt from one of CPE’s retail locations as proof of purchase. Equipment parts.
- Page 32 United States Environment Protection Agency (U.S. EPA) Emission Control System Warranty Your Champion Power Equipment (CPE) engine complies with U.S. EPA emission regulations. YOUR WARRANTY RIGHTS AND OBLIGATIONS: The US EPA AND CPE are pleased to explain the Federal Emission Control Systems Warranty on your 2017 small off-road engine and engine powered equipment.
- Page 33 EMISSION CONTROL SYSTEM WARRANTY The following are specific provisions relative to your Emission Control System (ECS) Warranty Coverage. 1. APPLICABILITY: This warranty shall apply to 1997 and later model year small off-road engines. The ECS Warranty Period shall begin on the date the new engine or equipment is delivered to its original, end-use purchaser, and shall continue for 24 consecutive months thereafter.
- Page 34 You must take your CPE engine or the product on which it is installed, along with your warranty registration card or other proof of original purchase date, at your expense, to any Champion Power Equipment dealer who is authorized by Champion Power Equipment, Inc. to sell and service that CPE product during his normal business hours.
