7.6 MARKING THE NFC READING AREA
The following instructions are not relevant for the LOGIClink Personal Lite. If you are installing a LOGIClink
Personal Lite, continue at the next chapter.
1.
Locate the NFC Reading Area on the table top. The Reading Area should be a 60 x 6o mm square
directly over the LOGIClink, 10 mm from the back edge (Fig. 7).
2.
Ensure the Reading Area is positioned properly. There should be no metal parts in or around it.
3.
Use a suitable material (e.g. Adhesive Film) to mark the NFC Reading Area.
Fig. 7:
Marking the NFC Reading Area
LOGICLINK - MANUAL // PAGE 23
NFC
Reading
Area
Front Edge
