7.2 CONNECTION VARIANTS

There are three connection options for LOGIClink:
Standard Option:
You require the standard installation variant if the following statements apply:
• Your LOGICDATA Control Box has "Works with LOGIClink" on its type plate (see Chapter 7.1)
• LOGIClink is used as the only control element.
• No additional Handset is connected.
• The Control Box Type Plate reads "Works with LOGIClink"
Instructions for the Standard Option can be found in Chapter 7.3 on page 19
INFO
Retrofit Option:
Use this system setup if one or more of the following conditions apply:
• You will connect an additional Handset to the LOGIClink
• You will connect the LOGIClink to a COMPACT-e or SMART-e Control Box was produced before April
2017 and is therefore not compatible with its factory settings.
• You will install the LOGIClink to a fixed workstation with an external Power Converter
Instructions for the Retrofit Option can be found in Chapter 7.4 on page 20
INFO
DYNAMIC MOTION system Option:
You require the DYNAMIC MOTION system installation variant if the following statements apply:
• You will connect the LOGIClink to the DYNAMIC MOTION system
Instructions for the DYNAMIC MOTION system Option can be found in Chapter 7.5 on
INFO
page 22
LOGICLINK - MANUAL // PAGE 18
