5.2 DIMENSIONS

Length
Width
Height (to underside of Table Top)
* NOTE: The drawing below is an example (LOGIClink Personal Standard). The design of the shutter depends
on the configuration of the LOGIClink you have ordered. The outer dimensions of the LOGIClink are the
same for all variants. Consult your Product's Datasheet for more information.
5.406 "
137,3 mm
Fig. 2: Product Dimensions
LOGICLINK - MANUAL // PAGE 12
137.3 mm | 5.406 "
108.0 mm | 4.253 "
23.1 mm | 0.910 "
4.253 "
108,0 mm
