- Page 1 User Guide V20i v2...
-
Page 2: Notice
Notice The illustrations in this user’s manual are for reference only. Actual product specifications may vary with territories. The information in this user’s manual is subject to change with- out notice. THE MANUFACTURER OR RESELLER SHALL NOT BE LI- ABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSE- QUENTIAL DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE OR USE OF THIS MANUAL. -
Page 3: Table Of Contents
TABLE OF CONTENTS Notice ....................2 Preface .....................5 1.1 Regulations Information ...........5 1.2 Safety Instructions............6 1.3 Notes for this Manual ............7 1.4 Release History ..............7 Getting to know the basics ...............8 2.1 Product Specification ............8 2.2 Preparing your AIO PC ..........11 2.3 Product Overview ............12 2.3.1 Front View ............12 2.3.2 Rear View .............14... - Page 4 3.4 VESA mounting to the wall (Optional) ......21 3.5 How to use Touch Panel (Optional) .......23 BIOS SETUP ..................24 4.1 About BIOS Setup ............24 4.1.1 When to Use BIOS Setup ?........24 4.1.2 How to Run BIOS Setup ?........24...
-
Page 5: Preface
Preface 1.1 Regulations Information CE compliance • This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. If your AIO PC comes with the TV tuner card, •... -
Page 6: Safety Instructions
1.2 Safety Instructions The following safety precautions will increase the life of the Computer. Follow all Precautions and instructions. Do not place this device underneath heavy loads or in an unstable position. Do not use or expose this device around magnetic fields as magnetic interference may affect the performance of the device. -
Page 7: Notes For This Manual
1.3 Notes for this Manual CAUTION! Important information that must be followed for safe operation. NOTE: Information for special situations. 1.4 Release History Date Version Revision Note 08.2015 First Released... -
Page 8: Getting To Know The Basics
Getting to know the basics 2.1 Product Specification This User’s Manual provides instructions and illustrations on how to operate this AIO PC. It is recommended to read this manual carefully before using this AIO PC. ・Physical Characteristic Dimension 486 x 342 x 39.8mm Weight 3.03 Kg (depend upon the actually shipping product) - Page 9 ・Storage 2.5” SATA HDD (7mm or 9.5mm) support Card reader Support SD/MS/MS Pro Memory Card Internal storage (Optional) eMMC 32G ・Optical Device 9.5mm SATA ODD support ・I/O Port DC-in USB2.0 x 5 +USB3.0 x1 RJ45 Phone jacks x 2 (Microphone/ Headphone) Card Reader x 1 (SD/MS/MS pro) HDMI...
-
Page 10: Communication Port
・Display 19.5” HD Monitor, 16:9 LED, resolution 1600 x 900 / 1366 x 768 ・Communication Port 10/100/1000 Mbits/Sec Network Proxy-Remote Wake Supports S3/S4/S5 wake ON LAN (WOL) feature Sleep mode or LPM <10W IEEE802.11b/g/n support Wireless LAN Wireless LAN + Bluetooth IEEE802.11b/g/n support, BT 4.0, USB interface (Optional) ・Webcam... -
Page 11: Preparing Your Aio Pc
2.2 Preparing your AIO PC 1. Install and adjust the stand for 19, 13 and 7 degrees from the vertical. 19°±3 13°±3 7°±3 2. Plug the AC adapter cable into the DC power connector. Connect one end of the power cable to the supplied power adapter and the other end to a wall outlet. -
Page 12: Product Overview
2.3 Product Overview This section provides the description of basic aspects of the AIO NOTE: The product’s color, I/O port, indicator location, and specifi- cation will depend upon the actually shipping product. 2.3.1 Front View Refer to the following illustration to identify the components on this side of the AIO PC. - Page 13 Top Side Components Function Description The built-in Webcam allows picture Webcam taking or video recording. Microphone Built-in microphone. LCD screen Displays of your AIO PC. Stereo speakers Produce stereo sound. Turns on the power of your AIO PC. Power Button The HDD indicator shows the HDD HDD Status LED status.
-
Page 14: Rear View
2.3.2 Rear View Refer to the following illustration to identify the components on this side of the computer. - Page 15 Top Side Components Function Description Card Reader SD/MS/MS Pro Memory Card Adjust the stand for stability and best viewing Stand angle. Connects an USB device (such as USB Zip USB 2.0 Ports drive, keyboard or mouse) into this jack. Connects amplified speakers or Headphone jack headphones into this jack.
-
Page 16: Right Side View
2.3.3 Right Side View Refer to the following illustration to identify the components on this side of the computer. Function Description Top Side Components Vent Thermal Vent. Connects an USB device (such as USB Zip USB3.0 Port drive, keyboard or mouse) into this jack. Connects an USB device (such as USB Zip USB2.0 Port drive, keyboard or mouse) into this jack. -
Page 17: Left Side View
2.3.4 Left Side View Refer to the following illustration to identify the components on this side of the computer. Top Side Components Function Description Optical drive Slot for inserting a disc. Eject button Ejects the CD/DVD disc. -
Page 18: Getting Started
Getting Started 3.1 Placing on the desktop 1. Place the AIO PC on a flat surface such as a table or desk. 2. Install the stand and check that it is properly aligned, carefully push down the stand until it snaps into the hooks. 19°±3 13°±3 7°±3... - Page 19 3. You can reattach the stand to as you see fit. Back Stand Angle: 19°±3 13°±3 7°±3...
-
Page 20: Ac Adapter
3.2 AC Adapter Please be noted that it is strongly recommended to connect the AC adapter and use the AC power while using this AIO PC for the first time. When the AC adapter is connected, the battery is being charged immediately. Note that the AC adapter included in the package is approved for your AIO PC;... -
Page 21: Cleaning The Screen
3.3 Cleaning the screen Follow these rules for cleaning the outside and handling your screen on the computer : 1. Turn off the system and disconnect all cables. 2. Use a damp or cleaning cloth, soft, lint-free cloth with gentle water only and gently wipe the screen surface. - Page 22 2. Secure the four wall mount screws (M4 x 9L) to the rear panel holes. Screw (M4 x 9L) 4pcs Standard VESA to let user guide of the wall/arm mount kit you bought to install it. NOTE: AIO PC can be mounted on a wall using a VESA compatible 100mm x 100mm wall/arm bracket.
-
Page 23: How To Use Touch Panel (Optional)
3.5 How to use Touch Panel (Optional) Touch panel brings digital life for an easy touch experience. Experience the ease of managing your digital life with a few touches. Your touch functions like a mouse device and all you need to interact with the touch panel. -
Page 24: Bios Setup
BIOS SETUP 4.1 About BIOS Setup The default BIOS (Basic Input/Output System) is already properly configured and optimized, there is normally no need to run this utility. 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: ・... - Page 25 ・ When OS support is Windows 10 : 1. Click the Start menu and select Settings. 2. Select Update and Security. 3. Click Recovery 4. Under Advanced startup, click Restart now. The system will restart and show the Windows 10 boot menu. 5.
