    Rugged E3 l User’s Manual Table of Contents Prefaces ....................04 Revision ..........................04 Disclaimer .......................... 04 Copyright Notice ....................... 04 Trademarks Acknowledgment................... 04 Environmental Protection Announcement ............... 04 Safety Precautions ......................05 Technical Support and Assistance ..................06 Conventions Used in this Manual ..................06 Chapter 1 Product Introductions ……………………………………………………..…...
  • Page 3 Rugged E3 l User’s Manual Chipset ......................45 3.4.1 System Agent (SA) Configuration ............45 3.4.2 PCH-IO Configuration ................47 Security ......................50 3.5.1 Administrators Password ............... 50 3.5.2 Users Password ..................50 Boot ........................51 3.6.1 Setup Prompt Timeout ................51 3.6.2 Bootup NumLock State ................

  • Page 4: Prefaces

    All specifications and information in this User’s Manual are believed to be accurate and up to date. Tangent Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Tangent Inc.

  • Page 5: Safety Precautions

    Preface Rugged E3 l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions:  Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage.  The power outlet shall be installed near the equipment and shall be easily accessible.

  • Page 6: Technical Support And Assistance

    Preface Rugged E3 l User’s Manual Technical Support and Assistance 1. Visit the Tangent Inc. website at www.tangent.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.

  • Page 7: Chapter 1 Product Introductions

    Product Introductions...

  • Page 8: Overview

    ® G3900TE (2.3GHz, Dual Core) Desktop processor, Rugged E3 is an extreme features integration, outstanding system performance, versatile I/O connections, and rugged reliability fanless embedded systems. It offers dramatically enhanced CPU and graphics performance, wide power and feature scalability, and advanced features, modularize expansion I/O, rich connectivity interfaces, wide range (9~48V) DC power input, and high reliability even operating in temperature extremes (-25 °...

  • Page 9: Hardware Specification

    Rugged E3 l User’s Manual Chapter 1: Product Introductions 1.2 Hardware Specification • 6x Antenna Hole • 1x Power Switch Processor System • 1x AT/ATX Switch • Support 6th Gen Intel® Core™ i3 / i5 / i7 / Pentium ®...

  • Page 10: System I/O

    Rugged E3 l User’s Manual Chapter 1: Product Introductions 1.3 System I/O 1.3.1 Rugged E3 Front Panel Universal I/O Bracket ATX power on/off switch Used to customized I/O output Press to power-on or power-off the system HDD port Reset switch Removable 2.5"...
  • Page 11 Chapter 1: Product Introductions Rugged E3 l User’s Manual Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out...

  • Page 12: Mechanical Dimension

    Rugged E3 l User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions 1.4.1 Rugged E3 Unit: mm...

  • Page 13: Chapter 2 Switches And Connectors

    Switches and Connectors...

  • Page 14: Switch And Connector Locations

    Chapter 2: Switches and Connecto Rugged E3 l User’s Manual 2.1 Switch and Connector Locations 2.1.1 Top View...

  • Page 15: Bottom View

    Chapter 2: Switches and Connecto Rugged E3 l User’s Manual 2.1.2 Bottom View...
  • Page 16 Rugged E3 l User’s Manual Chapter 2: Switches and Connecto 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch CLR_CMOS1 Clear BIOS Switch PWR_SW1 Power Switch RESET1 Reset Switch USB3_1,USB3_2 USB 3.0 Port...

  • Page 17: Connector / Switch Definition

    Chapter 2: Switches and Connecto Rugged E3 l User’s Manual 2.3 Switches Definitions AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) AT Power Mode 2-3 (Right) ATX Power Mode（Default） CLR_CMOS1: Clear BIOS Switch Switch Definition Normal Status (Default) Clear BIOS 2.4 Connectors Definitions...
  • Page 18 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors USB2_1: USB3.0 Connector, Type A Definition USB2_D7- USB2_D7+ USB2_2: USB3.0 Connector, Type A Definition USB2_D8- USB2_D8+ USB2_CN1: USB2.0 Ports Connector Type: 2X5 10-pin box header, 2.0mm pitch Definition Definition USB2_D9+...
  • Page 19 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors SIM3：SIM Card Socket Definition Definition UIM3_PWR UIM3_RESET UIM3_VPP UIM3_CLK UIM3_DATA SIM4：SIM Card Socket Definition Definition UIM4_PWR UIM4_RESET UIM4_VPP UIM4_CLK UIM4_DATA COM1_2_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub...
  • Page 20 Chapter 2: Switches and Connectors Rugged E3 l User’s Manual COM3_1： RS232 / RS422 / RS485 Connector Connector Type: 2X5 10-pin box header, 2.54mm pitch COM3_1 RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD3 TX3-...
  • Page 21 Chapter 2: Switches and Connectors Rugged E3 l User’s Manual DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN Chassis GND DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0-...
  • Page 22 Chapter 2: Switches and Connectors Rugged E3 l User’s Manual DP2: DisplayPort Connector Definition Definition DP2_LANE0_P DP2_LANE3_N DP2_LANE0_N DP2_LANE1_P DP2_AUX_P DP2_LANE1_N DP2_LANE2_P DP2_AUX_N DP2_HPD DP2_LANE2_N DP2_LANE3_P DP2_PWR SPK_OUT1 : Speaker-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L...
  • Page 23 Chapter 2: Switches and Connectors Rugged E3 l User’s Manual DIO1: Digital Input / Output Connector Connector Type: Terminal Block 2X9 18-pin, 3.5mm pitch Definition Definition DC INPUT...
  • Page 24 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors Digital Input Wurung Digital Output Wurung PWR_SW2 : Remote Power Switch Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition Power Button...
  • Page 25 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors CN1: LAN1 and USB3.0 Ports Connector Type: RJ45 port with LEDs and dual USB3.0 ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+ LAN1_MDI1P LAN1_MDI2P USB3_RX1- USB3_RX2- LAN1_MDI2N USB3_RX1+...
  • Page 26 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors LAN3, LAN4, LAN5, LAN6, LAN7, LAN8, LAN9, LAN10 : RJ45 with LEDs Port Connector Type: RJ45 Connector LAN3~LAN10 LAN3~LAN10 Definition Definition LAN_MDI0P LAN_MDI2N LAN_MDI0N LAN_MDI1N LAN_MDI1P LAN_MDI3P LAN_MDI2P LAN_MDI3N Link LED Status...
  • Page 27 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors Definition Definition Definition WAKE# +3.3V +3.3V USB2_D11+ +3.3V MINIPCIE RST# MINIPCIE_RXN11 +3.3V +1.5V +3.3V CLKREQ0# MINIPCIE_RXP11 USIM1_VCC USIM1_DATA +1.5V MINIPCIE_CLKN0 USIM1_CLK SMB_CLK +1.5V MINIPCIE_CLKP0 MINIPCIE_TXN11 USIM1_RST SMB_DATA MINIPCIE_TXP11 USIM1_VPP +3.3V...
  • Page 28 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors Definition Definition Definition WAKE# +3.3V +3.3V USB_D13+ +3.3V MINIPCIE RST# MINIPCIE_RXN4 +3.3V (SATA_RXN4) +1.5V +3.3V MINIPCIE_RXP4 CLKREQ1# (SATA_RXP4) USIM3_VCC USIM3_DATA +1.5V MINIPCIE_CLKN4 USIM3_CLK SMB_CLK +1.5V MINIPCIE_TXN4 MINIPCIE_CLKP4 (SATA_TXN4) USIM3_RST SMB_DATA...
  • Page 29 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors SATA1, SATA2: SATA with Power Connector SATA1 SATA1 SATA2 SATA2 Definition Definition Definition Definition SATA_TXP0 SATA_TXP1 SATA_TXN0 SATA_TXN1 SATA_RXN0 SATA_RXN1 SATA_RXP0 SATA_RXP1 +3.3V +3.3V +3.3V +12V +3.3V +12V +3.3V +12V +3.3V...
  • Page 30 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors POWER1, POWER2, POWER3, POWER4: Power Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V PCIE1: PCI-Express X1 Socket Connector Type: PCI-Express X1 Slot Definition Definition +12V +12V +12V +12V +12V...
  • Page 31 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors PCIE1: PCI-Express X16 Socket Connector Type: PCI-Express X16 Slot Definition Definition Definition Definition PCIE_PRSNT1 +12V PEG_TXN6 +12V PEG_RXP6 +12V +12V PEG_RXN6 +12V PEG_TXP7 SMB_CLK PEG_TXN7 PEG_RXP7 SMB_DATA PEG_RXN7 PRSNT2_3 +3.3V +3.3V...
  • Page 32 Rugged E3 l User’s Manual Chapter 2: Switches and Connectors PWR_LED1: Power LED Status Definition POWER LED+ POWER LED- HDD_LED1: HDD Access LED Status Definition HDD LED+ HDD LED- WDT_LED1: Watchdog LED Status Definition WATCHDOG LED+ WATCHDOG LED- GPIO_LED1: GPIO LED Status...

  • Page 33: Chapter 3 Bios Setup

    Setup BIOS...

  • Page 34: Bios Introduction

    Chapter 3: BIOS Setup Rugged E3 l User’s Manual 3.1 BIOS Introduction The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset.

  • Page 35: Main Setup

    Chapter 3: BIOS Setup Rugged E3 l User’s Manual 3.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu.

  • Page 36: Advanced Setup

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 3.3.1 ACPI Settings ■ Enable ACPI Auto Configuration...

  • Page 37: Amt Configuration

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.3.2 AMT Configuration Intel Active Management Technology (AMT) is hardware-based technology for remotely managing and securing PCs out-of-band. ■ Intel AMT This item allows users to enable or disable Intel AMT BIOS extension.

  • Page 38: Nct6106D Super Io Configuration

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.3.3 NCT6106D Super IO Configuration ■ Serial Port 1 Configuration  Serial Port This item will allow users to enable or disable serial port.  Change Settings This setting is used to change the address & IRQ settings of the specified serial port.
  • Page 39 Chapter 4: BIOS Setup Rugged E3 l User’s Manual  Serial Port This item will allow users to enable or disable serial port.  Change Settings This setting is used to change the address & IRQ settings of the specified serial port.

  • Page 40: Nct6106D Hw Monitor

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual ■ Serial Port 4 Configuration  Serial Port This item will allow users to enable or disable serial port.  Change Settings This setting is used to change the address & IRQ settings of the specified serial port.

  • Page 41: Cpu Configuration

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.3.5 Serial Port Console Redirection ■ Console Redirection This item allows users to enable or disable console redirection. 3.3.6 CPU Configuration ■ Hyper-Threading This item allows you to enable or disable the Intel Hyper-Threading Technology.

  • Page 42: Serial Port Console Redirection

    Rugged E3 l User’s Manual Chapter 4: BIOS Setup ■ CPU C states This item allows you to set the power saving of the CPU states.  Enhanced C State This item allows your CPU reduce power consumption ■ Package C State limit Select Auto for the AMI BIOS to automatically set the limit on the C-State package register.

  • Page 43: Csm Configuration

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.3.9 CSM Configuration ■ CSM Support This item allows you to enable or disable CSM support. ■ GateA20 Active This item allows you to select <Upon Request> or <Always>. Upon Request: GA20 can be disabled using BIOS services.

  • Page 44: Usb Configuration

    Rugged E3 l User’s Manual Chapter 4: BIOS Setup 3.3.10 USB Configuration ■ Legacy USB Support This item allows you to select <Enabled>, <Disabled> or <Auto>. Enabled: To enable legacy USB support. Disabled: To keep USB devices available only for EFI specification, Auto: To disable legacy support if no USB devices are connected.

  • Page 45: Chipset

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 3.4.1 System Agent (SA) Configuration ■...
  • Page 46 Chapter 4: BIOS Setup Rugged E3 l User’s Manual ■ Graphic Configuration  Detect Non-Compliance Device Detect Non-Compliance PCI Express Device. If enable, it will take more time at POST time.  GTT Size This item allows you to change the GTT size.

  • Page 47: Pch-Io Configuration

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.4.2 PCH-IO Configuration This section allows you to configure the chipset. ■ PCI Express Configuration...
  • Page 48 Chapter 4: BIOS Setup Rugged E3 l User’s Manual   PCI Express Root Port 1 / 3 / 4 / 5 / 6 / 7 / 8 / 9  PCI Express Port 1 / 3 / 4 / 5 / 6 / 7 / 8 / 9 This item allows you to enable or disable PCI Express Port 1 / 3 / 4 / 5 / 6 / 7 /8 / 9 in the chipset.
  • Page 49 Chapter 4: BIOS Setup Rugged E3 l User’s Manual ■ HD Audio Configuration  HD Audio Control detection of the HD-Audio device. This item allows you to select <Enabled>, <Disabled> or <Auto>. Disabled: Azalia will be unconditionally be disabled. Enabled: Azalia will be unconditionally be enabled.

  • Page 50: Security

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.5 Security Security menu allow users to change administrator password and user password settings. 3.5.1 Administrator Password This item allows you to set Administrator Password. 3.5.2 User Password This item allows you to set User Password.

  • Page 51: Boot

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.6 Boot This menu allows you to setup the system boot options. 3.6.1 Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. 3.6.2 Bootup NumLock State This item selects the keyboard NumLock state.

  • Page 52: Save & Exit

    Chapter 4: BIOS Setup Rugged E3 l User’s Manual 3.7 Save & Exit This setting allows users to configure the boot settings. 3.7.1 Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.
  • Page 53 Copyright 2016 Tangent Inc. All Rights Reserved www.tangent.com...
