Page 1: Quick Reference
Quick Reference FRDM-STBC-AGM04 Sensor Toolbox Development Platform for MMA8652FC 3-axis digital accelerometer, FXAS21002C 3-axis digital angular rate gyroscope, and MAG3110 3-axis digital magnetometer SENSOR TOOLBOX SHIELD DEVELOPMENT BOARD... - Page 2 Quick Reference GET TO KNOW THE FRDM-STBC-AGM04 MMA8652FC 3-axis, 12-bit, digital accelerometer MAG3110 3-axis, digital magnetometer 10-pin DFN (2 mm x 2 mm x 1 mm) 10 DFN (2 mm x 2 mm x 0.85 mm) 6 – I2C_SCL1 5 – I2C_SDA1 IN1_8652 –...
- Page 3 Figure 2: Connect board to computer www.nxp.com/sensortoolbox www.nxp.com NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective owners. © 2016 NXP B.V. Document Number: FRDM-STBC-AGM04 REV 0 Agile Number: 920-29415 REV A...
