Spectrum Digital eZdsp R2812 USB Technical Reference page 25

The definition of P5/P9 signals are shown in the table below.
Table 8: P5/P9, Analog Interface Connector
P5
Signal
Pin #
1 ADCINB0
2 ADCINB1
3 ADCINB2
4 ADCINB3
5 ADCINB4
6 ADCINB5
7 ADCINB6
8 ADCINB7
9 ADCREFM
10 ADCREFP
* Connect VREFLO to AGND or VREFLO of target system for proper ADC operation.
P9
Signal
Pin #
1 GND
3 GND
5 GND
7 GND
9 GND
11 GND
13 GND
15 GND
17 GND
19 GND
Spectrum Digital, Inc
P9
Signal
Pin #
2 ADCINA0
4 ADCINA1
6 ADCINA2
8
ADCINA3
10
ADCINA4
12 ADCINA5
14 ADCINA6
16 ADCINA7
18 VREFLO *
20 No connect
2-13
